Steel Four Row Cylindrical Industrial Roller Bearings SFCP5274220 For Rolling Mill , ISO

1 piece
MOQ
USD 7.00-15.00 per piece
Price
Steel Four Row Cylindrical Industrial Roller Bearings SFCP5274220 For Rolling Mill , ISO
Features Gallery Product Description Request A Quote
Features
Specifications
ID: 260 Mm
OD: 370 Mm
Thickness: 220 Mm
Material: Chrome Steel
Type: Four Row Cylindrical Roller Bearing
Weight: 76.5 Kgs
Cage: Nylon Or Steel
Application: Rolling Mill
High Light:

Cam Follower Bearing

,

axial thrust bearing

Basic Infomation
Place of Origin: China
Brand Name: GQZ or OEM
Certification: ISO
Model Number: SFCP5274220
Payment & Shipping Terms
Packaging Details: Single NSK original packing box
Delivery Time: within 3 days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000 piece per day
Product Description

SFCP5274220 Four Row Cylindrical Roller Bearing for Rolling Mill

1. Description

This kind of bearing has four row cylindrical rollers, with a good radial load capacity. However,it can

not collect strength along axis.Moreover,it can be installed with inside ring and outside ring parts(with whole set of rolling and retainer) separately.This kind of bearing includes following 3 types:FCtype,FCDtype and FCDP type.It mainly used in working roll and supporting roll of these machine,such as cold and hot rolling mill and so on.

GQZ offers types of four row cylindrical roller bearings to meet the different occasions.


2.Specification:

Brand: GQZ or other brand
Series: four row cylindrical roller bearing
Model No.: SFCP5274220
Inside diameter: 260 (mm)
Outer diameter 370 (mm)
Thickness: 220 (mm)
Bearing Feature: rolling mill bearing
Stock 12 piece in stock


3.Feature:
(1) Four-row cylindrical roller bearing
(2) Steel,nylon or brass cage
(3) rolling mill application
(4) Long use life
(5) Competitive price
(6) OEM acceptable
(7) 1 year's quality guarantee

4. Bearing picture:
Steel Four Row Cylindrical Industrial Roller Bearings SFCP5274220 For Rolling Mill , ISO 0

Steel Four Row Cylindrical Industrial Roller Bearings SFCP5274220 For Rolling Mill , ISO 1


5. We also supply following rolling mill bearing:

Dimensions(mm) Weight Designations
d D B Kg
105 150 71 4.1 319148B
125 180 100 7.9 BC4B319768K30
140 210 155 17 313900B
151.5 230 168 24 314024C
151.5 230 168 24 505467
151.5 230 168 23 BC4B467334C
151.5 230 168 23 803431
160 240 175 35.2 313436
160 240 175 35.2 507509
160.69 260 178.7 34 BC4B466949
162 230 130 16 312863
162 230 130 16 500861
170 260 160 29.5 313423A
175 260 180 32 BC4B457919VCA
181 260 180 29.5 314874A
181 260 180 29.5 509665
181 260 180 28 BC4B452683A
181.5 260 168 27.9 314023A
181.5 260 168 27.9 505466
181.5 260 168 27 BC4B467333B
182 260 168 28 312942
183.33 280 200 43 BC4B457920VCA
190 280 200 40 313583
190 280 200 40 503745
190 290 180 41 313422
190 290 180 41 507508
192 270 170 28.5 313153
192 270 170 28.5 502284
200.833 310 230 62.5 BC4B457922VAB
202 290 192 39.5 313152
202 290 192 39.5 502279
202 290 207 42.5 312858
202 290 202.23 49 BC4B467419
205 310 225 58 313584K
205 310 225 58 503742
228.33 325 200 48.5 BC4B461839
230 330 220 57.5 313438A
230 330 220 57.5 506743A
231 330 235 59 312943C
231 330 235 59 500857A
246.67 380 280 115 BC4B457927
255 370 249 82 312860
260 400 250 110 313439
260 400 250 110 522518A
260 400 285 125 313532A
260 400 285 125 507518
266.25 400 285 120 BC4B457929VCA
320 480 350 215 505356
320 480 350 215 BC4B316345A
340 520 300 215 315767K
356.67 550 400 335 510302A
356.67 550 400 335 BC4B457939VAA
365 540 300 230 313041C
382.5 590 450 425 319352
412.335 650 488 565 BC4B467373VCA
412.335 650 488 576 314964
412.335 650 488 576 527181
412.5 630 450 490 BC4B457945VCA
440 650 355 400 313032
485 740 540 830 315523
485 740 540 830 577938
511.584 780 580 915 BC4B457956VCE
551.667 830 580 1070 BC4B457960VCA
571.627 870 640 1335 BC4B319446
571.667 870 640 1170 BC4B457962VCA
606.667 920 640 1525 315526
633.334 960 680 1675 BC4B457969
773.334 1120 800 2715 BC4B319991/HA4
811.692 1180 850 2980 BC4B457984VCA
918.354 1330 950.125 4380 BC4B457995VCA
950 1360 1000 4830 314520CK30


If you want to buy this bearing,jus contact us!
