22312E Sealed Spherical Roller Bearings , C/CA /K/CK Steel Cage Bearing 60 x 130 x 46 mm

Spherical roller bearing types 22312E roller bearings 60x130x46mm C/CA /K/CK cage spherical roller bearing 22312

Spherical roller bearings are double row, self-retaining units comprising solid outer rings with a concave raceway, solid inner rings and barrel rollers with cages. The inner rings with cylindrical or tapered bores.

It has two rows of rollers, a common sphered outer ring raceway and two inner ring raceways inclined at an angle to the bearing axis. The centre point of the sphere in the outer ring raceway is at the bearing axis. Therefore, the bearings are self-aligning and insensitive to misalignment of the shaft relative to the housing, which can be caused, for example, by shaft deflection. They are designed to accommodate heavy radial loads, as well as heavy axial loads in both directions.

Cage types :

Spherical roller bearing types 22312E 22313E 22314E 22315E imperial roller bearings Basic specifications :
