Angular Contact Ball Bearing
Created with Pixso. GQZ 7212B Angular Contact Ball Bearing 60×110×22mm For Gear Units & Compressor Equipment

GQZ 7212B Angular Contact Ball Bearing 60×110×22mm For Gear Units & Compressor Equipment

Brand Name: GQZ
Model Number: 7212B
MOQ: 100.PCS
Price: negotiation
Delivery Time: 5 working days
Payment Terms: T/T,Western Union,Paypal,MoneyGram
Detail Information
Place of Origin:
CHINA
Certification:
ISO9001/ISO14001/GJB9001
Features:
Highly Rigid|High Precision|high Speed
Model No:
F-583943 Bearing
Sealed Type:
Open
Tolerance:
ABEC-1,ABEC-3, ABEC-4
Borediameter:
Varies (e.g., 20mm, 25mm, 30mm)
Certifiexcavatorion:
ISO-9001
Cage Cage:
Nylon Holder
Holder:
Bakelite Holder
Cagematerial:
Steel, Brass, Polyamide
Cage Material:
Brass|Nylon
Origin:
Wuxi Jiangsu
Same Bearing:
KD120AR0 Bearing
Applications:
Machine Tools, Pumps, Gearboxes, Robotics
Part Number:
XKAH-00434
Noise Level:
Z1,Z2,Z3,Z4
Packaging Details:
Standard Carton Box
Supply Ability:
1000.pcs / Month
Product Description
1. Product Overview

7212B is single row angular contact ball bearing. Suffix B represents 40° contact angle. It can bear combined radial load and unidirectional axial load. Larger contact angle provides stronger axial bearing capacity compared to A and C variants. For bidirectional axial load requirements, bearings need to be installed in paired configurations. Widely applied in industrial gearboxes, air compressors, centrifugal pumps, fan assemblies and medium-heavy load rotary mechanical assemblies.

Formal quotation will be sent within 24 hours upon your inquiry.

2. Technical Specifications
Model
7212B
Dimensions
d60 mm, D110 mm, B22 mm
Net weight
approx 0.92 kg
Dynamic load rating Cr
82.5 kN
Static load rating Cor
65.2 kN
Limiting speed
Grease 4400 rpm, Oil 5300 rpm
Structure
Single row angular contact ball bearing, 40° contact angle
Material
GCr15 bearing chrome steel, stamped steel cage
Clearance
Standard CN clearance; C3 clearance optional
Optional arrangement
DB / DF / DT matched pairing available

Complete dimension drawings and load data available on request.

3. Core Advantages
  1. 40° large contact angle delivers excellent unidirectional axial load performance
  2. Able to sustain combined radial load and one-way axial thrust simultaneously
  3. Compact dimension, flexible for back-to-back, face-to-face and tandem mounting
  4. Stable medium-speed operation with good resistance to light impact loads
  5. Optimized internal structure reduces heat generation under continuous operation
  6. Customizable options: OEM laser marking, solid machined cage, high temperature lubricating grease
    Ideal supporting component for rotary machinery with remarkable axial force.
4. Application Scenarios
  • Medium-duty industrial gearboxes and speed reduction devices
  • Screw air compressors and centrifugal pump drive shafts
  • Ventilation fans and blower supporting assemblies
  • Agricultural and general processing mechanical transmission parts
  • Rotary equipment subjected to obvious unidirectional axial thrust
  • Precision machinery requiring paired angular contact bearing layout
5. Why Choose GQZ Bearing
  • 25 years professional bearing manufacturer
  • Products exported to over 50 countries worldwide
  • Strict inspection on raw material hardness, surface finish, load capacity and rotational smoothness before delivery
  • 24-hour professional technical support for pairing and installation guidance
  • Sufficient bulk stock for machinery distributors

We supply stable dimensional accuracy, reliable performance and long-term cooperative support.

6. Quality Control Process
  • GCr15 raw material chemical composition and hardness inspection
  • Complete quenching & tempering heat stabilization treatment
  • Precision superfinishing grinding for raceways and steel balls
  • Contact angle and geometry precision inspection
  • Full dimension tolerance, clearance testing and rotational performance testing
7. Request Quotation

If you need 7212B angular contact ball bearings: Send inquiry to obtain below supports:

  • Quick formal quotation within 24 hours
  • Professional pairing assembly suggestion
  • Solid cage alternative solutions
  • Competitive factory direct price
    Contact our sales team for full technical datasheets and formal offer.

Wholesale High Speed Deep Groove Ball Bearings Hybrid Ceramic Ball Bearing 625 Bearings 2RS ZZ for Mechanical 1 Wholesale High Speed Deep Groove Ball Bearings Hybrid Ceramic Ball Bearing 625 Bearings 2RS ZZ for Mechanical 1 GQZ 7212B Angular Contact Ball Bearing 60×110×22mm For Gear Units & Compressor Equipment GQZ 7212B Angular Contact Ball Bearing 60×110×22mm For Gear Units & Compressor Equipment GQZ 7212B Angular Contact Ball Bearing 60×110×22mm For Gear Units & Compressor Equipment

8. FAQ
Q1: What does B stand for?
B = 40° contact angle.
Q2: Main dimensions of 7212B?
60×110×22 mm single row angular contact ball bearing.
Q3: Installation tip?
Single bearing only bears one-way axial load; adopt matched pairs for bidirectional axial force.
