Cast Iron Material FYH UCFB205J 3-bolt Flanged Pillow Block Ball Bearing UCFB205
  • name
  • name

Cast Iron Material FYH UCFB205J 3-bolt Flanged Pillow Block Ball Bearing UCFB205

MOQ: 1 pcs
Price: negotiation
Standard Packaging: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Period: 3 working days after received your payment
Payment Method: T/T or western Union or PayPal
Supply Capacity: 3,000pcs per month
Details Information
Product Description
Detail Information
Place of Origin
Japan
Brand Name
FYH
Certification
ISO
Model Number
UCFB205J
Product Name:
UCFB205J
Type:
Pillow Block
Housing Material:
Cast Iron
Housing Type:
FB205
Highlight:

Cast Iron Hanger Pillow Block Bearing

,

Plummer Pillow Block Bearing

,

OEM Pillow Block Bearing

Product Description

Cast Iron Material FYH UCFB205J Pillow Block Ball Bearing UCFB205



1. Description:



UCFB Pillow Block bearing are within a flanged housing are used when the bearing mounting surface is perpendicular to a shaft axis. They are commonly available in two, three, or four-hole configurations. Two-bolt flanged ball bearing units have a diamond or winged-shape with 2 holes for mounting. As with our 3-Bolt Flanged Bearing Units, 4-Bolt Flanged Bearing Units and our Flangette Series, the 2-bolt flanged bearing units have bearings that can be moved and aligned to better accomodate long shafts.



2. Specification:



Part number UCFB205J
Bearing Type Cast iron housing
Shaft Dia. (Fw) 25.0000
Housing Height (a) 116.0000
Housing Length 68.0000
Housing Number FB205
Weight (g) 700
Material Cast iron housing, chrome steel bearing



3. FYH Flange Pillow block bearing UCFL UCFL205 bearing pillow block models design:

Cast Iron Material FYH UCFB205J 3-bolt Flanged Pillow Block Ball Bearing UCFB205 0



4. Pillow Block Bearings(UCFL Series)



Bearing Number Shaft dia d(mm) H(mm) L(mm) L1(mm) A(mm) J(mm)
UCFL 201 12 113 60 66 25.5 90
UCFL 202 15 113 60 66 25.5 90
UCFL 203 17 113 60 66 25.5 90
UCFL 204 20 113 60 66 25.5 90
UCFL 205 25 130 68 73 27 99
UCFL 305 25 150 80 84 29 113
UCFL 206 30 148 80 84 31 117
UCFL 306 30 180 90 94 32 134
UCFL 207 35 161 90 94 34 130
UCFL 307 35 185 100 104 36 141
UCFL 208 40 175 100 104 36 144
UCFL 308 40 200 112 118 40 158
UCFL 209 45 188 108 113 38 148
UCFL 309 45 230 125 132 44 177
UCFL 210 50 197 115 120 40 157
UCFL 310 50 240 140 144 48 187
UCFL 211 55 224 130 134 43 184
UCFL 311 55 250 150 154 52 198
UCFL 212 60 250 140 144 48 202
UCFL 312 60 270 160 164 56 212
UCFL 213 65 258 155 157 50 210
UCFL 313 65 295 175 186 58 240
UCFL 214 70 265 160 163 54 216
UCFL 314 70 315 185 196 61 250
UCFL 215 75 275 165 168 56 225
UCFL 315 75 320 195 206 66 260
UCFL 216 80 290 180 188 58 233
UCFL 316 80 355 210 218 68 285
UCFL 217 85 305 190 198 63 248





UCP200 series
Pillow block bearing UCP201 UCP202 UCP203
Pillow block bearing UCP204 UCP205 UCP206
Pillow block bearing UCP207 UCP208 UCP209
Pillow block bearing UCP210 UCP211 UCP212
Pillow block bearing UCP213

UCF200 series
Pillow block bearing UCF201 UCF202 UCF203
Pillow block bearing UCF204 UCF205 UCF206
Pillow block bearing UCF207 UCF208 UCF209
Pillow block bearing UCF210 UCF211 UCF212
Pillow block bearing UCF213 UCF214 UCF215 UCF216
Pillow block bearing UCF217 UCF218

UCT200 series
Pillow block bearing UCT201 UCT202 UCT203
Pillow block bearing UCT204 UCT205 UCT206
Pillow block bearing UCT207 UCT208 UCT209
Pillow block bearingUCT210 UCT211 UCT212
Pillow block bearing UCT213 UCT214 UCT215
Pillow block bearing UCT216 UCT217



5. Pictures:

Cast Iron Material FYH UCFB205J 3-bolt Flanged Pillow Block Ball Bearing UCFB205 1Cast Iron Material FYH UCFB205J 3-bolt Flanged Pillow Block Ball Bearing UCFB205 2
