Contact Sngle 25° Agular Contact Ball Bearing 3803-B-TVH High Precision

Contact Sngle 25° Agular Contact Ball Bearing 3803-B-TVH High Precision

    • Contact Sngle 25° Agular Contact Ball Bearing 3803-B-TVH High Precision
    • Contact Sngle 25° Agular Contact Ball Bearing 3803-B-TVH High Precision
  • Contact Sngle 25° Agular Contact Ball Bearing 3803-B-TVH High Precision

    Product Details:

    Place of Origin: Optional
    Brand Name: Optional
    Certification: ISO9001
    Model Number: 3803-B 3803-B-TVH

    Payment & Shipping Terms:

    Minimum Order Quantity: 1.pcs
    Packaging Details: Standard Carton Box / Wooden Pallet Case
    Delivery Time: 2 ~ 5 working days
    Payment Terms: T/T, Western Union,Paypal,
    Contact Now
    Detailed Product Description
    Size: 17x26x7mm Stock Quantity: 580.pcs
    Type: Double Row Angular Contact Precision: P6, P5 ,P4 ,P2
    Contact Angle: 25° Open Temperature: –30 °C ~ +150 °C

    Contact Sngle 25° Agular Contact Ball Bearing 3803-B-TVH High Precision







    BearingModel 3803-B-TVH
    Contact Angle 25°
    Type Double Row Angular Contact Ball Bearing
    d (mm)  17
    D (mm) 26
    B (mm) 7
    Mass (KG) 0.015
    Precision

    P6, P5 ,P4 ,P2



    We currently have 580.pcs of 3803-B-TVH Angular Contact Bearing In Stock.

    If you are interested,just feel free to contact us by E-mail or Phone.



    We'll assure you the best quality; the most competitive prices & the shortest delivery time.

    We also have Items given as below In Stock.For more details,just feel free to contact us.



    Bearing

    Model

    d

    (mm)

    D

    (mm)

    B

    (mm)

    3800-B-TVH 10 19 7
    3801-B-TVH 12 21 7
    3802-B-TVH 15 24 7
    3803-B-TVH 17 26 7
    3804-B-TVH 20 32 10
    3805-B-TVH 25 37 10
    3806-B-TVH 30 42 10
    3807-B-TVH 35 47 10
    3808-B-TVH 40 52 10
    3809-B-TVH 45 58 10
    3810-B-TVH 50 65 12
    3811-B-TVH 55 72 13
    3812-B-TVH 60 78 14
    3814-B-TVH 70 90 15
    3816-B-TVH 80 100 15





    Suffix Description
    B Modified internal construction,contact angle α = 25°, without filling slot
    C2 Axial internal clearance C2
    C3 Axial internal clearance C3
    DA Inner ring split
    M Solid brass cage, ball-guided
    MA Solid brass cage,guidance on outer ring
    TVH Solid polyamide snap cage,ball-guided
    2RSR Lip seals on both sides
    2Z Gap seals on both sides



    Introduction



    Double row angular contact ball bearings are units with solid inner and outer rings and ball and cage assemblies with polyamide, sheet steel or brass cages. Their construction is similar to a pair of single row angular contact ball bearings in an O arrangement but they are narrower to a certain extent. They differ in the size of the contact angle and the design of the bearing rings.





    Sealing

    Series 38..-B, 30..-B, 32..-B and 33..-B with the suffix 2RSR are sealed by lip seals on both sides. Contact seals are suitable for giving protection against dust, contamination and damp atmospheres.
    Series with the suffix 2Z have gap seals on both sides.


    Lubrication

    Sealed bearings are greased with a high quality grease and are lubricated for life.





    Operating temperature



    Open bearings are suitable for operating temperatures from –30 °C to +150 °C.
