N309E M1 roller bearing and ball bearing P0 P6 P5 P4 P2 fag thrust bearing

1
MOQ
1 USD
Price
N309E M1 roller bearing and ball bearing P0 P6 P5 P4 P2 fag thrust bearing
Features Gallery Product Description Request A Quote
Features
Specifications
Bearing Type: Cylindrical Roller Bearing
Cage Material: Brass Cage / Steel Cage
ID: 45 Mm
OD: 100 Mm
Clearance: C0,C2,C3,C4,C5
Precision Level: P0,P6,P5,P4,P2
High Light:

Cam Follower Bearing

,

roller thrust bearing

Basic Infomation
Brand Name: FAG / GQZ / AAA
Certification: ISO 9001
Model Number: NU303E
Payment & Shipping Terms
Packaging Details: single packing + standard export packing
Payment Terms: T/T, Western Union
Supply Ability: 1000 pcs / month
Product Description



N309E M1 roller bearing and ball bearing P0 P6 P5 P4 P2 fag thrust bearing

1. Cylindrical Roller Bearing  Specification :



Bearing type  Cylindrical Roller Bearing
Bearing Model  N309E .M1
Brand  FAG / GQZ / AAA
Size (mm) 45*100*25
MOQ 1 pcs
Stock  Enough
Lubrication Oil
Application Automobiles, Rolling Mill, Mining, Metallurgy




2. Advantage  :



1> manufacturer & exporter
2> competitive price
3>high quality material
4> advanced machine
5> Strictly QC system
6> experienced engineers and workers, good service
7> low noise and long usage life
8> professional management and team


3. Main products :



1.Taper roller bearing

2.Deep groove ball bearing

3.cylindrical roller bearing

3.spherical roller bearing

4.linear bearing

5.pillow block bearing

6 OEM all knid of famous brand

7. Non-standard bearing





4 .Shipping:


1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )



5. APPLICATION:



Mainly used in large and medium-sized motor, locomotives, spindle, internal combustion
engines, generators, gas turbines, reducer, rolling mill, vibrating screen and lifting transportation machinery, etc


6 . We have enough stock , following is our products in stock .



Designations Old spec Principal Dimensions (mm) Speed ratings (rpm) Weight(kg)
d D B Fw Grease Oil
NU 303 E 32303 E 17 47 14 24.2 14000 17000 0.12
NU 304 E 32304 E 20 52 15 27.5 12000 15000 0.15
NU 304 32304 20 52 15 28.5 12000 15000 0.15
NU 305 E 32305 E 25 62 17 34 9500 12000 0.24
NU 305 32305 25 62 17 35 9500 12000 0.24
NU 306 E 32306 E 30 72 19 40.5 9000 11000 0.36
NU 306 32306 30 72 19 42 9000 11000 0.36
NU 307 E 32307 E 35 80 21 46.2 8000 9500 0.48
NU 307 32307 35 80 21 46.2 8000 9500 0.48
NU 308 E 32308 E 40 90 23 52 6700 8000 0.65
NU 308 32308 40 90 23 53.5 6700 8000 0.65
NU 309 E 32309 E 45 100 25 58.5 6300 7500 0.9
NU 309 32309 45 100 25 58.5 6300 7500 0.9
NU 310 E 32310 E 50 110 27 65 5000 6000 1.15
NU 310 32310 50 110 27 65 5000 6000 1.15
NU 311 E 32311 E 55 120 29 70.5 4800 5600 1.45
NU 311 32311 55 120 29 70.5 4800 5600 1.45
NU 312 E 32312 E 60 130 31 77 4300 5000 1.8
NU 312 32312 60 130 31 77 4300 5000 1.8
NU 313 E 32313 E 65 140 33 82.5 4000 4800 2.25
NU 313 32313 65 140 33 83.5 4000 4800 2.25
NU 2214 E 32314 E 70 150 35 89 3600 4300 2.75
NU 2214 32314 70 150 35 90 3600 4300 2.75
NU 315 E 32315 E 75 160 37 95 3400 4000 3.3
NU 315 32315 75 160 37 95.5 3400 4000 3.3
NU 316 E 32316 E 80 170 39 101 3200 3800 3.95
NU 316 32316 80 170 39 108 3200 3800 3.95

NU 2304 E 32604 E 20 52 21 27.5 11000 14000 0.21
NU 2304 32604 20 52 21 28.5 11000 14000 0.21
NU 2305 E 32605 E 25 62 24 34 9000 11000 0.35
NU 2305 32605 25 62 24 35 9000 11000 0.35
NU 2306 E 32606 E 30 72 27 40.5 8000 9500 0.53
NU 2306 32606 30 72 27 42 8000 9500 0.53
NU 2307 E 32607 E 35 80 31 46.2 7000 8500 0.72
