Low Noise Chrome Steel Cylindrical Roller Bearing For Free End Bearing

Low Noise Chrome Steel Cylindrical Roller Bearing For Free End Bearing

    • Low Noise Chrome Steel Cylindrical Roller Bearing For Free End Bearing
    • Low Noise Chrome Steel Cylindrical Roller Bearing For Free End Bearing
  • Low Noise Chrome Steel Cylindrical Roller Bearing For Free End Bearing

    Product Details:

    Brand Name: FAG / NSK / GQZ / AAA
    Certification: ISO 9001
    Model Number: N2315E.M1.C3

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: 1 USD
    Packaging Details: single packing + standard export packing
    Payment Terms: T/T, Western Union
    Supply Ability: 1000 pcs / month
    Contact Now
    Detailed Product Description
    Bearing Type: Cylindrical Roller Bearing Precision Level: P0,P6,P5,P4,P2
    Material: GCr15 D: 160
    D: 75 Vibration: Z1V1, Z2V2, Z3V3



    1. Cylindrical Roller Bearing  Specification :



    Bearing type  Cylindrical Roller Bearing
    Bearing Model   N2315E.M1.C3
    Brand   FAG / NSK / GQZ / AAA
    Size (mm)   75*160*55
    Weight (kg)   5.3 KG
    Stock  Enough
    Lubrication Oil
    Application Automobiles, Rolling Mill, Mining, Metallurgy



    2. Cylindrical Roller Bearing ​:


    We can supply many kinds of cylindrical roller bearings.
    Single row: N, NU, NJ, NF, NUP, NCF and NJG
    Double row: NNU, NN, NNC, NNCF and NNCL.
    Four rows:SL series



    3 . Cylindrical Roller Bearing Features :


    1. The roller and raceway for the line contact or offline contact, radial bearing capacity big, apply to under heavy load and impact load.
    2. The friction coefficient is small, suitable for high speed, the limit speed close to the deep groove ball bearings.
    3. The N type and NU type axial movement, can adapt to shaft caused by thermal expansion or installation error and shell the change of relative position, can be used for free end bearing.
    4. On the shaft or hole of the processing and the demand is higher, bearing outer axis relative deflection after installation to be kept under strict control, so as not to cause contact stress concentration.
    5. The inner ring or outer ring separable, easy to install and disassemble.



    4 . Competitive Advantage:


    1. Bearing manufacturer
    2. ISO 9000/9001/9004/19011: 2000
    3. Produce by customer's needs
    4. High speed, low noise
    5. Bearing steel
    6. The most competitive price



    5. APPLICATION:

    Bearing can be used for: Annealing furnace, special machine, conveyor, mixer, rock drill, corrosion-resistant pumps, welding machines, monitoring equipment, ceramic building materials processing equipment, packaging auxiliary equipment, sewing machine parts, machine tool rest, forestry machinery, reaction equipment, hot-pressing machine, screw refrigerating machine, printing machines, cars, and so on.


    6 .  We also can offer following bearings :



    Designations Principal Dimensions (mm) Basic load rating (kN) Speed ratings (rpm) Weight(kg)
    d D B Dynamic Staitc Grease Oil
    NNU4920 100 140 40 125 244 4300 5100 1.88
    NN3020 100 150 37 146 245 4000 4800 1.96
    NNU4921 105 145 40 132 270 4100 4800 1.96
    NN3021 105 160 41 192 310 3800 4100 2.96
    NNU4922 110 150 40 132 258 3900 4600 2.04
    NN3022 110 170 45 226 365 3600 4300 3.76
    NNU4924 120 165 45 170 328 3600 4200 2.76
    NNU4124 120 200 80 -- -- -- -- 11
    NN3024 120 180 46 232 390 3300 3900 4.1
    NNU4926 130 180 50 187 368 3300 3900 3.79
    NN3026 130 200 52 284 475 3100 3600 6.04
    NNU4928 140 190 50 188 394 3000 3600 4.11
    NN3026 140 210 53 297 515 2800 3300 6.48
    NNU4930 150 210 60 325 655 2800 3300 6.2
    NN3030 150 225 56 330 570 2600 3100 7.88
    NNU4932 160 220 60 330 653 2500 2900 6.53
    NN3032 160 240 60 369 635 2600 3100 9.57
    NNU4934 170 230 60 336 672 2500 2900 6.85
    NN3034 170 260 67 440 775 2300 2700 13
    NNU4936 180 250 69 380 830 2300 2700 10.2
    NN3036 180 280 74 561 994 2200 2600 17
    NNU4938 190 260 69 402 856 2200 2600 10.6
    NN3038 190 290 75 580 1040 2000 2400 18
    NNU4940 200 280 80 484 1010 2100 2400 14.9
    NN3040 200 310 82 644 1140 1900 2300 23
    NNU4944 220 300 80 510 1140 1900 2200 16.2
    NN3044 220 340 90 800 1460 1700 2100 32.9
    NNU4948 240 320 80 528 1160 1700 2000 17.4
    NNU4148 240 400 160 -- -- -- -- 85
    NN3048 240 360 92 835 1688 1600 1900 --
    NNU4176 240 620 243 -- -- -- -- 285
    NNU4952 260 360 100 745 1800 1600 1800 30.2
    NN3052 260 440 104 -- -- -- -- 110
    NN3052 260 400 104 1020 1910 1500 1700 48
    NNU4956 280 380 100 764 1710 1400 170 32.2
