    Product Details:

    Place of Origin: Japan
    Brand Name: NSK/OEM
    Certification: ISO9001:2008
    Model Number: NN3026MBKRCC1P5

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pcs
    Price: negotiation
    Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
    Delivery Time: 3 working days after received your payment
    Payment Terms: T/T or western Union or PayPal
    Supply Ability: 3,000pcs per month
    Contact Now
    Detailed Product Description
    Structure: Cylindrical Type: Roller
    Material: Chrome Steel Application: Vibration Machinary,CNC Machine And So On
    Weight: 4.04kg Cage: Brass Cage

    Import NSK precision spindle Cylindrical roller bearing NN3026MBKRCC1P5 NSK Cylindrical Roller Bearing​



    Bearing name :bearing for CNC machine cylindrical roller bearing

    Model : NN3026MBKRCC1P5

    Size : 130*182*52 mm

    Weight : 5.88 KG

    Material : GCR-15

    Precision : P5

    Quality : ISO9001:2008 approved

    OEM service: Offer



    Types of cylindrical roller bearing:

    .Single row cylindrical roller bearing: NU, NJ, NUP, NUB series

    .Double row cylindrical roller bearings:NNU series

    .Four row cylindrical roller bearing:FC series

    .Single row full complement cylindrical roller bearing:SL18 series, SL 19 series

    .Double row full complement cylindrical roller bearing

    .SL01 series, SL02 series, SL18 series.





    Bearing type Cage symbol Specification Available size
    NN MB Roller guided machined brass cage

    NN3005,NN3026-NN3040

    NN3920-NN3956,NN4920-NN4940

    TB Roller guided PPS resin cage NN3006-NN3024
    NNU MB Roller guided machined brass cage NNU4920-NNU4940
    N MR Roller guided machined brass cage N1006-N1028
    TP Outer ring guided PEEK resin cage N1009-N1017



    Import NSK precision spindle Cylindrical roller bearing NN3026MBKRCC1P5 design draft :

    Import NSK precision spindle Cylindrical roller bearing NN3026MBKRCC1P5 NSK Cylindrical Roller Bearing



    Cylindrical roller bearings NN3026MBKRCC1P5

    Bearing number : NN3026MBKR

    Size (mm) : 130x182x52

    Brand : NSK

    Bore Diameter (mm) : 130

    Outer Diameter (mm) : 182

    Width (mm) : 52

    Bearing dimensions and specification in brand catalogue :

    d - 130 mm

    D - 200 mm

    E - 182 mm

    B - 52 mm

    C - 52 mm

    r min. - 2 mm

    Weight - 5,88 Kg

    Basic dynamic load rating (C) - 284 kN

    Basic static load rating (C0) - 475 kN

    (Grease) Lubrication Speed - 4 600 r/min



    (Oil) Lubrication Speed - 5 500 r/min





    Dimension

    (mm)

    Weight (kg)

    Rated load

    ( KN)

    Limiting speed

    (r/min)

    Type
    d D B r min F E Cr Cor Grease oil
    100 140 40 1.1 113 137 1.88 125 244 4300 5100 NNU4920
    150 37 1.5 -- 146 245 4000 4800 NN3020
    105 145 40 1.1 118 146 1.96 132 270 4100 4800 NNU4921
    160 41 2 -- 2.96 192 310 3800 4100 NN3021
    110 150 40 1.1 123 155 2.04 132 258 3900 4600 NNU4922
    170 45 2 -- 3.76 226 365 3600 4300 NN3022
    120 165 45 1.1 134.5 165 2.76 170 328 3600 4200 NNU4924
    200 80 1.112 141 11 -- -- -- -- NNU4124
    180 46 2 -- 4.1 232 390 3300 3900 NN3024
    130 180 50 1.5 146 182 3.79 187 368 3300 3900 NNU4926
    200 52 2 -- 6.04 284 475 3100 3600

    NN3026
