GQZ NJ324E.M1 Single Row Cylindrical Roller Bearing 120×260×55mm With Solid Brass Cage For Heavy Load Reducers

NJ324E.M1 is single row cylindrical roller bearing of NJ design. E stands for enhanced optimized internal geometry to achieve higher dynamic load rating; M1 refers to solid machined brass cage. It can withstand heavy radial load and limited one-way axial load. The inner ring assembly including rollers and cage is separable from outer ring, bringing great convenience for installation, disassembly and maintenance. Widely used in heavy-duty reducers, mining equipment, metallurgical machinery and large industrial transmission systems.

Formal quotation will be sent within 24 hours upon your inquiry.

Model: NJ324E.M1

Dimensions: d120 mm, D260 mm, B55 mm

Net weight: approx 14.3 kg

Dynamic load rating Cr: 712 kN

Static load rating Cor: 835 kN

Limiting speed: Grease 2100 rpm, Oil 2700 rpm

Structure: Single row cylindrical roller, NJ type, E reinforced internal design

Cage: M1 solid machined brass cage

Material: GCr15 bearing chrome steel

Clearance: Standard CN clearance; C3, C4 clearance optional

Precision class: P0, P6, P5 available

Complete dimension drawings and load data available on request.

1. E-type optimized roller layout, larger load rating and excellent fatigue resistance under continuous heavy load
2. NJ structural design: carries heavy radial load and realizes unidirectional axial positioning
3. M1 machined brass cage runs stably under high temperature, vibration and medium-high speed working conditions
4. Separable inner roller assembly, easy for independent mounting, inspection and component replacement
5. Optimized surface finish reduces friction heat and prolong service life under long-time operation
6. Customizable options: OEM laser marking, special clearance, anti-rust strengthening treatment
   Greatly reduce failure risk for heavy industrial transmission assemblies.

• Heavy-duty industrial gearboxes and speed reducers
• Mining crushers, bulk material conveying machinery
• Metallurgical and steel mill equipment supporting shafts
• Large industrial fans, pumps and compressors
• Construction machinery and heavy engineering equipment transmission parts
• Mechanical systems requiring high radial load and one-way axial restraint

• 25 years professional bearing manufacturer
• Products exported to over 50 countries worldwide
• Strict inspection on raw material hardness, surface finish, load capacity and rotational smoothness before delivery
• 24-hour professional technical support for clearance selection and installation guidance
• Sufficient bulk stock for machinery and industrial distributors
• We supply stable dimensional accuracy, reliable heavy-load performance and long-term cooperative support.

• GCr15 raw material chemical composition and hardness inspection
• Complete quenching & tempering heat stabilization treatment
• Precision superfinishing grinding for bearing rings and rollers
• Brass cage precision machining and deburring processing
• Full dimension tolerance, static & dynamic load and rotational performance testing

If you need NJ324E.M1 cylindrical roller bearings:

Send inquiry to obtain below supports:

• Quick formal quotation within 24 hours
• Professional installation and clearance selection suggestion
• Custom marking and special technical specifications available
• Competitive factory direct price
  Contact our sales team for full technical datasheets and formal offer.
