Deep Groove Ball Bearing
Created with Pixso. GQZ 6926 C3 Thin Section Deep Groove Ball Bearing 130×180×24mm For Precision Rotary Transmission Equipment

GQZ 6926 C3 Thin Section Deep Groove Ball Bearing 130×180×24mm For Precision Rotary Transmission Equipment

Brand Name: GQZ
Model Number: 6926 C3
MOQ: 100.PCS
Price: negotiation
Delivery Time: 5 working days
Payment Terms: T/T,Western Union,Paypal,MoneyGram
Detail Information
Place of Origin:
CHINA
Certification:
ISO9001/ISO14001/GJB9001
Delivery:
1~15days
Retainer:
Nylon. Iron
Productname:
Deep Groove Ball Bearing
Trademark:
BUGAO/NBKT
Applicable Models:
Auto Parts
Inventory:
Enough For Regular Sizes
Rolling Element:
Balls
Cagematerial:
Pressed Steel / Polyamide
Material:
Chrome Steel (GCr15)
Size:
8*22*7mm
Supply:
30000 Set/Sets Per Month
Outside:
Stardard Size
Feature:
Long Life .durable.high Temperature
Roller:
Bearing Steel
Quality Standard:
ISO9001:2008
Packaging Details:
Standard Carton Box
Supply Ability:
1000.pcs / Month
Product Description
1. Product Overview

6926 C3 belongs to 69 series thin-wall single row deep groove ball bearing. C3 means enlarged radial internal clearance. Its slim radial profile saves installation space and reduces overall equipment weight. This bearing can carry radial load and minor bidirectional axial load simultaneously. Featuring low friction and stable rotation, it is widely adopted in automation machinery, textile equipment, packaging machines and light-load rotary assemblies requiring compact structural layout.

Formal quotation will be sent within 24 hours upon your inquiry.

2. Technical Specifications
Parameter Value
Model 6926 C3
Dimensions d130 mm, D180 mm, B24 mm
Net weight approx 1.70 kg
Dynamic load rating Cr 70.5 kN
Static load rating Cor 76.8 kN
Limiting speed Grease 3600 rpm, Oil 4400 rpm
Structure Thin section single row deep groove ball bearing
Material GCr15 bearing chrome steel, stamped steel cage
Clearance C3 enlarged radial internal clearance
Optional versions Open type, metal shielded, rubber sealed configuration
Additional info Complete dimension drawings and load data available on request.
3. Core Advantages
  1. Thin wall slim construction, effectively reduce radial occupied space and optimize equipment design
  2. C3 extra clearance provides allowance for thermal expansion during continuous running
  3. Suitable for radial load together with small bidirectional axial load
  4. Low noise, low vibration and smooth operation under medium rotating speed
  5. Standard interchangeable dimensions, multiple sealing choices for different working environments
  6. Customizable options: OEM laser marking, anti-rust strengthening treatment, special grease formula Deliver reliable performance for compact precision rotating mechanical units.
4. Application Scenarios
  • Automated production equipment and robotic auxiliary rotary joints
  • Textile machinery, printing and packaging rotary components
  • Light-duty industrial fans and small mixing equipment
  • Precision testing instruments and optical equipment supporting positions
  • Light-load compact gear transmission assemblies
  • Rotary machinery with strict restrictions on outer installation dimension
5. Why Choose GQZ Bearing
  • 25 years professional bearing manufacturer
  • Products exported to over 50 countries worldwide
  • Strict inspection on raw material hardness, surface finish, load capacity and rotational smoothness before delivery
  • 24-hour professional technical support for clearance and sealing selection guidance
  • Sufficient bulk stock for automation and machinery distributors
  • We supply stable dimensional accuracy, reliable performance and long-term cooperative support.
6. Quality Control Process
  • GCr15 raw material chemical composition and hardness inspection
  • Complete quenching & tempering heat stabilization treatment
  • Precision superfinishing grinding for rings and steel balls
  • Cage forming and deburring processing
  • Full dimension tolerance, clearance testing and rotational performance inspection
7. Request Quotation

If you need 6926 C3 deep groove ball bearings:

Send inquiry to obtain below supports:

  • Quick formal quotation within 24 hours
  • Professional sealing and clearance selection suggestions
  • Custom marking and special technical requirements available
  • Competitive factory direct price Contact our sales team for full technical datasheets and formal offer.

Wholesale High Speed Deep Groove Ball Bearings Hybrid Ceramic Ball Bearing 625 Bearings 2RS ZZ for Mechanical 1Wholesale High Speed Deep Groove Ball Bearings Hybrid Ceramic Ball Bearing 625 Bearings 2RS ZZ for Mechanical 1GQZ 6926 C3 Thin Section Deep Groove Ball Bearing 130×180×24mm For Precision Rotary Transmission Equipment GQZ 6926 C3 Thin Section Deep Groove Ball Bearing 130×180×24mm For Precision Rotary Transmission Equipment GQZ 6926 C3 Thin Section Deep Groove Ball Bearing 130×180×24mm For Precision Rotary Transmission Equipment

8. FAQ
Q1: What does C3 stand for?
C3 = radial internal clearance larger than standard normal clearance group.
Q2: Main dimensions of 6926 C3?
130×180×24 mm thin section deep groove ball bearing.
Q3: Load characteristics?
Primarily bears radial load, can withstand slight bidirectional axial load.
