GQZ 2215 Double Row Self-Aligning Ball Bearing 75×130×31mm For Fans And Processing Equipment

2215 is double row self-aligning ball bearing with straight cylindrical bore. The spherical raceway of outer ring provides reliable self-aligning ability to compensate shaft deflection and housing misalignment. It can bear radial load and minor bidirectional axial load at the same time. Simple structure, low friction and stable rotation characteristics. Widely applied in ventilation fans, textile machinery, belt conveyors, agricultural equipment and various rotary assemblies prone to alignment deviation.

Formal quotation will be sent within 24 hours upon your inquiry.

Model: 2215

Dimensions: d75 mm, D130 mm, B31 mm

Net weight: approx 1.51 kg

Dynamic load rating Cr: 62.2 kN

Static load rating Cor: 28.8 kN

Limiting speed: Grease 4600 rpm, Oil 5500 rpm

Structure: Double row self-aligning ball bearing, cylindrical bore

Material: GCr15 bearing chrome steel, stamped steel cage

Optional variant: tapered bore version available on request

Complete dimension drawings and load data available on request.

1. Excellent self-aligning capacity to adapt shaft bending and assembly misalignment
2. Capable of bearing radial load plus slight bidirectional axial load
3. Low friction torque, smooth and quiet medium-speed continuous operation
4. Straight bore design for direct mounting on standard solid shafts
5. Robust double row ball layout, suitable for light alternating impact loads
6. Customizable options: OEM laser marking, anti-rust treatment, special lubrication formula
   Reduce abnormal wear risk for shafts with poor coaxiality.

• Industrial ventilation fans, blowers and air handling equipment
• Textile machinery, printing and packaging rotary components
• Belt conveyors and light processing machinery
• Agricultural machinery and construction auxiliary equipment
• General rotating shafts prone to deflection
• Medium-speed equipment requiring tolerance for installation deviation

25 years professional bearing manufacturer

Products exported to over 50 countries worldwide

Strict inspection on raw material hardness, surface finish, load capacity and rotational smoothness before delivery

24-hour professional technical support for installation and alignment guidance

Sufficient bulk stock for machinery distributors

We supply stable dimensional accuracy, reliable performance and long-term cooperative support.

GCr15 raw material chemical composition and hardness inspection

Complete quenching & tempering heat stabilization treatment

Precision superfinishing grinding for raceways and steel balls

Cage forming and deburring processing

Full dimension tolerance, clearance testing and rotational performance testing

If you need 2215 self-aligning ball bearings:

Send inquiry to obtain below supports:

• Quick formal quotation within 24 hours
• Professional assembly and alignment suggestion
• Tapered bore alternative solutions
• Competitive factory direct price
  Contact our sales team for full technical datasheets and formal offer.
