GQZ RLS14 Imperial Deep Groove Ball Bearing 44.45×95.25×20.64mm For Inch Standard Transmission Equipment

RLS14 is single row imperial inch-size deep groove ball bearing. Dimensions: 1-3/4" × 3-3/4" × 13/16". It can bear radial load and minor bidirectional axial load simultaneously. Multiple sealing configurations including open type, double metal shielded and double rubber sealed can be supplied. Factory pre-filled grease option supports convenient direct assembly. Widely matched with inch standard shafts, commonly applied in industrial pumps, general motors, agricultural machinery, compressors and retrofit mechanical assemblies using imperial size components.

Formal quotation will be sent within 24 hours upon your inquiry.

Model:

RLS14

Dimensions:

d44.45 mm, D95.25 mm, B20.64 mm

Inch size:

1 3/4" × 3 3/4" × 13/16"

Net weight:

approx 0.66 kg

Dynamic load rating Cr:

64.5 kN

Static load rating Cor:

42.0 kN

Limiting speed:

Grease 4300 rpm, Oil 5200 rpm

Structure:

Single row deep groove ball bearing

Material:

GCr15 bearing chrome steel, stamped steel cage

Clearance:

Standard CN clearance; C3 clearance optional

Available variants:

Open / ZZ / 2RS

Complete dimension drawings and load data available on request.

1. Standard imperial inch dimension, ideal replacement for original inch specification equipment
2. Capable of bearing radial load plus slight bidirectional axial load
3. Multiple optional sealing structures to adapt dry, dusty and lightly humid working environments
4. Low friction, stable continuous medium-speed rotation performance
5. Global standard inch series, convenient interchange for overseas machinery maintenance
6. Customizable options: OEM laser marking, anti-rust treatment, special high-temperature grease
   Offer dependable rotary support for machinery equipped with inch-size shaft systems.

• Overseas industrial motors, centrifugal pumps and blower assemblies
• Imported agricultural machinery and processing equipment
• Air compressors and medium-speed transmission units with inch standard shafts
• Mechanical equipment retrofitting and maintenance replacement
• Rotary assemblies requiring imperial size rolling bearings
• Medium-load rotating positions with various dust and moisture conditions

• 25 years professional bearing manufacturer
• Products exported to over 50 countries worldwide
• Strict inspection on raw material hardness, surface finish, load capacity and rotational smoothness before delivery
• 24-hour professional technical support for inch model matching and sealing selection guidance
• Sufficient bulk stock for machinery maintenance distributors
• We supply stable dimensional accuracy, reliable performance and long-term cooperative support.

• GCr15 raw material chemical composition and hardness inspection
• Complete quenching & tempering heat stabilization treatment
• Precision superfinishing grinding for bearing rings and steel balls
• Shield / seal assembly and pre-lubrication processing
• Full dimension tolerance, clearance detection and rotational performance testing

If you need RLS14 deep groove ball bearings:

Send inquiry to obtain below supports:

• Quick formal quotation within 24 hours
• Professional sealing and clearance matching advice
• Optional open/shielded/sealed solutions
• Competitive factory direct price
  Contact our sales team for full technical datasheets and formal offer.

Q1: Is RLS14 metric or inch bearing?

RLS14 is imperial inch standard deep groove ball bearing.

Q2: Main dimensions of RLS14?

44.45×95.25×20.64 mm (1-3/4" × 3-3/4" ×13/16").

Q3: Available sealing types?

Open, ZZ double metal shield, 2RS double rubber seal.
