GQZ 7208 Single Row Open Angular Contact Ball Bearing 40×80×18mm Suitable For Duplex Paired Installation

Name: GQZ 7208 Single Row Open Angular Contact Ball Bearing 40×80×18mm Suitable For Duplex Paired Installation
Brand: Wuxi Guangqiang Bearing Trade Co.,Ltd
SKU: 7208
Price: 509.10 USD
Availability: InStock

Brand Name:	GQZ
Model Number:	7208
MOQ:	100.PCS
Price:	negotiation
Delivery Time:	5 working days
Payment Terms:	T/T,Western Union,Paypal,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO9001/ISO14001/GJB9001

Features:

High Speed

Bore Size:

11.992 - 12 Mm

Outerdiameter:

Varies (e.g., 30mm - 200mm)

Bearingtype:

Rolling Element Bearing

Structure:

Deep Groove

Vibration:

V,V1,V2,V3,V4

Warranty:

12 Months

Cage Material:

Metal|Brass

Precisiongrade:

Standard (ABEC 1, 3, 5, Etc.)

Oringin:

Wuxi China

Outer Diameter:

320mm

Bearing Material:

G20Cr2Ni4A Or GCr15SiMn

Lubriexcavatore:

Oil Grease

Precision Rating:

ABEC-5,7,9

Sample:

2-3 Working Days

Standard:

ISO 9001

Seals Type:

2RS

Innerring:

Single Or Double Piece

Feature:

Long Life,High Speed,low Noise,durable

Dimension:

50*90*20mm

Number:

32TM03 NX C3

Salt Spay Test:

168 Hours

Performance:

High Speed

Precision:

P0, P6, P5, P4

Noise Standard:

Zv1 Zv2 Zv3

Precision Level:

P0,P6,P5,P4,P2

Quality:

ABEC-3/ABEC-5

Certifiexcavatorion:

ISO:9001

Size:

35*72*17mm

Inner Diameter:

55mm

Rows Number:

Single

Speedrating:

High Speed Capability

Productname:

Deep Groove Ball Bearing

Original:

LuoYang China

Dynamic Load:

1970N

Seals:

Open

Row:

Double Row

Item:

Deep Groove Ball Bearing

Availability:

Have Stocks

Retainer:

Special Steel

Market:

Global

Feture:

Angle >45, But Incl. Angle = 40

Outerside Diameter:

170mm

Clearance:

C0,C2,C3,C4,C5...

Angle:

C/AC/A5/E/A

Seal:

Steel Shield

Delivery:

In Stock

Rotational Speed:

60000RPM-68000RPM

Preload:

Light Preload

Noise:

Z1, Z2, Z3, Z4

Seal Type:

Open Or Seals

Borediameter:

Various (e.g., 20mm, 25mm, 30mm)

Packaging Details:

Standard Carton Box

Supply Ability:

1000.pcs / Month

Product Description

1. Product Overview

7208 is single row open angular contact ball bearing. It can withstand combined radial load and unidirectional axial thrust. This bearing is commonly arranged in duplex sets including UA universal match, DB back-to-back and DF face-to-face configurations to balance opposite axial forces. Multiple contact angle versions optional: C(15°), AC(25°), B(40°). Open design facilitates re-lubrication and routine maintenance. Widely used on industrial gearboxes, screw compressors, centrifugal pumps, machine tool spindles and medium-high speed rotary machinery.

Formal quotation will be sent within 24 hours upon your inquiry.

2. Technical Specifications

Model: 7208
Dimensions: d40 mm, D80 mm, B18 mm
Net weight: approx 0.472 kg
Structure: Single row angular contact ball bearing
Material: GCr15 bearing steel, pressed steel cage or machined brass cage optional
Optional variants: 7208C / 7208AC / 7208B with different contact angles
Duplex options: UA, DB, DF matched bearing sets available; Complete dimension drawings and load data available on request.

3. Core Advantages

Supports mixed radial load and one-way axial load for transmission assemblies
Flexible duplex pairing choices to resist bidirectional axial forces
Precision ground raceway reduces vibration and temperature rise during high-speed running
Multiple contact angle options satisfy diverse load and speed requirements
Standard ISO metric size for convenient global aftermarket replacement
Customizable: OEM laser marking, high-temperature special grease

4. Application Scenarios

Industrial gearboxes and medium-duty reduction drive assemblies
Screw air compressors and small centrifugal pump shafts
Machine tool spindles and automation rotary equipment
Light-duty mining machinery and industrial blower units
Mechanical systems requiring paired bearing layout to balance axial thrust

5. Why Choose GQZ Bearing

25 years professional bearing manufacturer, products exported globally.
Strict raw material inspection and precision grinding process.
24-hour technical support for contact angle selection and duplex matching.
Ample stock for machinery distributors.
Precise dimensions and stable service performance.

6. Quality Control Process

GCr15 raw material quenching & tempering treatment
Precision superfinishing for bearing rings and steel balls
Contact angle, internal clearance and duplex matching inspection
Dimension tolerance and rotational performance testing

7. Request Quotation

If you need 7208 angular contact ball bearings:

Send inquiry to obtain below supports:

Quick quotation within 24 hours
Contact angle variant consultation
Optional matched duplex bearing sets
Competitive factory direct price
Contact our sales team for full datasheets and formal offer.

Wholesale High Speed Deep Groove Ball Bearings Hybrid Ceramic Ball Bearing 625 Bearings 2RS ZZ for Mechanical 1 GQZ 7208 Single Row Open Angular Contact Ball Bearing 40×80×18mm Suitable For Duplex Paired Installation

8. FAQ

Q1: Main dimensions of 7208?: 40×80×18 mm single row angular contact ball bearing.
Q2: Suffix meaning:: C=15° contact angle; AC=25° contact angle; B=40° contact angle.
Q3: Installation tip:: Normally applied in pairs to counteract opposite axial loads.
