GQZ NUKR90 Concentric Stud Type Track Roller Bearing 90mm OD Double Row Full Complement Cylindrical Roller

Name: GQZ NUKR90 Concentric Stud Type Track Roller Bearing 90mm OD Double Row Full Complement Cylindrical Roller
Brand: Wuxi Guangqiang Bearing Trade Co.,Ltd
SKU: NUKR90
Price: 57.50 USD
Availability: InStock

Brand Name:	GQZ
Model Number:	NUKR90
MOQ:	100.PCS
Price:	negotiation
Delivery Time:	5 working days
Payment Terms:	T/T,Western Union,Paypal,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO9001/ISO14001/GJB9001

Oil Rotation Speed:

56000

Limited Speed:

3950RPM

Warranty:

12 Months

Delivery:

1~15days

Internal Diameter:

The Whole Volume:

0.0263 CBM

Vibration Level Code:

V1,V2.V3

Material:

Chrome Steel

Sample Available:

Available

Innerdiameter:

10mm - 500mm

Seal:

With Seals

Packing:

Customer Requirement

Rows Number:

Single

Outside Diameter:

76.2 Mm

Main Material:

High Carbon Chromium Steel

Bore Size:

34.925 Mm

Lead Time:

Stock Or 15-30days

Precisiongrade:

P0, P6, P5, P4, P2

Outer Diameter:

80 Mm

Materila:

Gcr15 Chrome Steel

Thickness:

21mm

Certifiexcavatorion:

ISO9001:2008

Noise:

Z1, Z2, Z3, Z4

Other Materials:

Available

Tolerance Codes:

ABEC-1,ABEC-3,ABEC-5

Roller Bearing Type:

Inch Bearing

Outside:

Stardard Size

Bearing:

ZKLF2068-2RS

Port:

SHANGHAI/NINGBO

Certifiexcavatore:

ISO/TS16949

Factory Type:

Trade+ Factory

Load Direction:

Radial Bearing

Vibration Level:

Z1V1 Z2V2 Z3V3

Other Number:

90368-34001

Noise Level:

Z1,Z2

Type:

Taper Roller Bearing

Grease Lubrication:

750 R/min

Operatingtemperaturerange:

-30°C To +120°C

Product:

Tapered Roller Bearing

Payment Term:

T/T,paypal,Western Union

Parameters:

70x125x24 Mm

External Form Change:

K, W33

Innerring:

Tapered

Source:

China Cheap Tapered Roller Bearings

Vibration And Noise:

Z0V0 / Z1V1 / Z2V2 / Z3V3

Operating Temper:

-25°C ~ +120°C

Free Sample:

Available

Color:

Black, Grey, White, Red, Green

Weight:

3.5 KG

Trade Terms:

FOB,CFR,CIF,EXW

Lubrication:

Grease Or Oil

Sample:

Avaliable

Separated:

Separated

Hs Code:

8482200000

Application:

Textile Machinery

Precison:

Loadtype:

Radial And Axial Load

Number:

40KW01

Seals Type:

OPEN ZZ 2RS

Package:

Original Package

Rolling Body:

Roller Bearings

Dimension:

40*80*24.75mm

Inch:

69,85x116,98x63,88

Speedrating:

High Speed Capability

Dynamicloadrating:

Varies By Size (e.g., 10kN - 500kN)

Bearingtype:

Rolling Element Bearing

Mass:

1.00KG

Service:

OEM Customized Services

Precision:

P0, P5, P6

Specification:

Open, Z, ZZ, RZ, 2RZ, RS, 2RS

Bearing Width:

64.5 Mm

Feature:

Low Noise. Long Life

Width:

9mm - 150mm

Mountingtype:

Press Fit

Number Of Row:

Single Row,Double Row

Series:

Qw Series

Stock:

Great Supplying Ability

Dimensions:

25590/25520 25590/20

Bearing Material:

Chrome Steel

Row:

Single Row

Vibration:

Z1V1,Z2V2 And Z3V3

Character:

Full Complement , Double Seal

Seal Type:

2RS; 2Z

Corrosionresistance:

Standard Or Stainless Steel Options

Part Number:

81140M

Inner Diameter:

30 Mm

Model No:

TR090.0200

Packaging Details:

Standard Carton Box

Supply Ability:

1000.pcs / Month

Product Description

1. Product Overview

NUKR90 is metric concentric bolt-type track roller bearing (cam follower).

NUKR: Concentric stud design, without eccentric collar; eccentric version marked NUKRE90
Double row full complement cylindrical rollers, no cage, maximum roller quantity for outstanding radial load capacity
Thick-walled outer ring, standard crowned outer running surface; flat cylindrical surface optional (suffix X)
Integral threaded stud M30×1.5, built-in hexagon socket for easy mounting
Both-side labyrinth seals, equipped with re-lubrication channel on stud

Designed to roll directly on guide rails, cam surfaces. It withstands heavy radial loads and tolerates moderate axial loads caused by deflection or misalignment. Widely used on automated conveyor lines, printing machinery, packaging equipment, textile machinery, heavy cam transmission and low-medium speed linear motion systems.

Formal quotation will be sent within 24 hours upon your inquiry.

2. Technical Specifications

Model:: NUKR90
Outer ring diameter D:: 90 mm
Stud diameter d1:: 30 mm
Overall length B:: 100 mm
Outer ring width C:: 35 mm
Thread specification:: M30×1.5
Net weight:: approx 1.94 kg
Structure:: Double row full complement cylindrical roller track roller
Material:: GCr15 bearing steel
Sealing:: Double-sided labyrinth seal
Lubrication:: Re-lubricatable through stud
Limiting speed (grease):: 1800 rpm
Dynamic load Cr:: 80000 N
Static load C0r:: 123000 N

Complete dimension drawings and load data available on request.

3. Core Advantages

Full complement roller arrangement delivers extremely high static & dynamic radial load capability
Concentric bolt structure, simple installation; distinguish from eccentric NUKRE90
Thickened outer ring improves rigidity, resists surface deformation under heavy load
Built-in re-lubrication channel supports long-term continuous heavy-duty operation
Labyrinth seals block dry dust and retain internal grease
Standard metric dimension direct cross reference to international mainstream brands
Customizable: cylindrical outer ring (NUKR90X), black oxide coating, special heavy-load grease, OEM laser marking

4. Application Scenarios

Automated production lines and heavy-duty conveyor guide rollers
Printing, paper-making and packaging machinery cam drive assemblies
Textile equipment, woodworking machinery linear moving units
Hydraulic machinery, engineering auxiliary transmission structures
Low & medium speed machinery running on straight or curved guide rails

5. Why Choose GQZ Bearing

25 years professional bearing manufacturer, products exported globally.
Strict raw material hardness and heat treatment control.
Precision grinding for outer ring raceway and running surface.
24-hour technical support for NUKR / NUKRE model selection consultation.
Ample stock for machinery distributors.
Precise dimensions and stable service performance.

6. Quality Control Process

GCr15 raw material quenching & tempering hardness inspection
Precision superfinishing for raceway and roller contact surface
Thread accuracy, hexagon socket and surface roughness testing
Seal assembly, grease filling and rotational smoothness inspection

7. Request Quotation

If you need NUKR90 track roller bearings:

Send inquiry to obtain below supports:

Quick quotation within 24 hours
NUKRE90 eccentric version and NUKR90X flat outer ring alternative consultation
Competitive factory direct price
Contact our sales team for full datasheets and formal offer.

8. FAQ

Q1: Model difference: NUKR90 = concentric stud (no eccentric);; NUKRE90 = with eccentric adjusting collar.
Q2: Main dimensions of NUKR90?: Outer diameter 90 mm, stud thread M30×1.5, overall length 100 mm.
Q3: Full complement characteristic: No cage, more rollers for higher load capacity, not suitable for high-speed working conditions.
