GQZ FF-2010 Single Row Flat Cage Linear Needle Roller Assembly 32×10×2mm For Linear Sliding Guide

FF-2010 belongs to standard FF series flat linear needle roller assembly. It consists of cylindrical needle rollers installed inside a flat nylon retainer, single row arrangement.

This component works between two flat raceway surfaces to realize reciprocating linear sliding movement. It only bears vertical radial load, not suitable for rotary motion. The retainer keeps rollers evenly spaced, avoids roller friction collision and maintains stable sliding performance.

ZW represents double-row type; base model FF is single-row structure. Widely adopted for precision moulds, automation linear guide structures, testing equipment and low-speed flat reciprocating machinery.

Formal quotation will be sent within 24 hours upon your inquiry.

Model

FF-2010

Overall length L

32 mm

Assembly width b

10 mm

Roller diameter Dw

2 mm

Roller effective length Lw

6.8 mm

Quantity of rollers

7 pcs

Net weight

approx 0.002 kg

Structure

Single row flat needle roller with nylon cage

Roller material

GCr15 bearing steel

Cage material

Reinforced nylon

Dynamic load Cr

21300 N

Static load C0r

61900 N

Complete dimension drawings and load data available on request.

1. Flat strip compact structure, saves installation space for planar sliding mechanisms
2. High load capacity under low-speed reciprocating linear motion
3. Nylon retainer separates each roller, reduces friction and prevents roller disorder
4. Standard industry dimension, fully interchangeable with mainstream brand FF series
5. Simple installation, can be combined end-to-end to extend sliding travel
6. Customizable: stainless steel roller version, steel cage, OEM laser marking, P6 precision grade

• Precision mould planar sliding and mold guiding structures
• Automation equipment reciprocating linear sliding guide assemblies
• Precision testing instruments and optical machinery
• Light-duty machine tool flat guide rail components
• Low-speed heavy-load reciprocating flat sliding mechanisms

25 years professional bearing manufacturer, products exported globally.

Strict dimensional sorting for needle rollers to guarantee sliding smoothness.

Stable nylon cage forming process, not easy to deform under load.

24-hour technical support for length combination and model selection.

Ample stock for machinery distributors.

Precise dimensions and stable service performance.

GCr15 roller quenching & tempering hardness inspection

Needle roller dimensional tolerance and surface roughness testing

Cage flatness and assembly clearance inspection

Whole set sliding smoothness test

If you need FF-2010 flat needle roller assemblies:

Send inquiry to obtain below supports:

• Quick quotation within 24 hours
• Double row FFZW series alternative consultation
• Stainless steel roller version solution
• Competitive factory direct price
  Contact our sales team for full datasheets and formal offer.
