GQZ CFH3S Inch Stud Type Cam Follower Track Roller Bearing 76.2×38.1mm Full Complement Needle Roller

CFH3S (CFH-3-S) is ANSI standard inch-size bolt-type cam follower (track roller bearing).

• S: Standard version, inner hex socket on stud end, built-in lubrication hole for periodic re-greasing
  Full complement needle roller structure without retainer, realizing ultra-high load carrying capacity. Thick-walled outer ring directly rolls on cam surfaces or guide tracks. Integrated threaded stud simplifies installation and fixing.
  Model variant note: CFH3SB comes with built-in contact seals for dust protection. Widely used for printing machinery, automated production lines, cam transmission structures, packaging equipment and heavy-duty linear guide roller mechanisms.
  Formal quotation will be sent within 24 hours upon your inquiry.

Model

CFH3S (CFH-3-S)

Roller outer diameter D

76.2 mm (3 inch)

Roller width C

38.1 mm (1.5 inch)

Stud thread

1-1/2-12 UNF

Net weight

approx 2.10 kg

Structure

Full complement needle roller cam follower, open type, hex socket stud

Material

GCr15 bearing steel, black oxide anti-rust treatment

Basic dynamic load Cr

157000 N

Basic static load C0r

221500 N

Limiting speed (grease)

1800 rpm

Complete dimension drawings and load data available on request.

1. Full complement needle roller design delivers superior heavy load and shock resistance
2. Thickened outer ring improves rigidity, effectively prevents deformation under impact load
3. Internal lube hole supports convenient regular grease replenishment without disassembly
4. Inner hexagon socket enables simple installation and torque adjustment
5. Standard inch dimension, fully interchangeable with MCGILL CFH-3-S series
6. Customizable: sealed CFH3SB variant, stainless steel material, OEM laser marking, extreme pressure grease

• Printing machinery, textile equipment and large cam driving mechanisms
• Automated assembly lines and heavy-duty linear track roller units
• Packaging machinery, conveyor guide roller assemblies
• Machine tool auxiliary transmission and mold cam structures
• Low-speed heavy-load equipment with reciprocating cam motion

25 years professional bearing manufacturer, products exported globally.

Precision grinding for outer raceway and needle rollers, strict contact surface inspection.

Standard black oxide anti-corrosion treatment process.

24-hour technical support for installation torque and lubrication guidance.

Ample stock for machinery distributors.

Precise dimensions and stable service performance.

• GCr15 raw material quenching & tempering hardness inspection
• Precision superfinishing for outer ring raceway and needle rollers
• Internal clearance measurement and rotational smoothness testing
• Thread tolerance, surface roughness and appearance defect inspection

If you need CFH3S cam follower bearings:
Send inquiry to obtain below supports:

• Quick quotation within 24 hours
• Sealed CFH3SB model alternative consultation
• Cross reference interchange data
• Competitive factory direct price
  Contact our sales team for full datasheets and formal offer.
• 8. FAQ

  Q1: Model explanation

  CFH = Inch series full complement cam follower; S = standard open type; SB = sealed type.

  Q2: Main dimensions of CFH3S?

  Roller OD 76.2 mm, width 38.1 mm, thread 1-1/2-12 UNF.

  Q3: Installation tip

  Apply proper locking torque on the stud to avoid loose rotation during operation.
