GQZ 71814 Thin Section Single Row Angular Contact Ball Bearing 70×90×13mm Open Type Precision Rolling Bearing

71814 (standard designation 70014) belongs to 718 series thin-wall angular contact ball bearing.

Open structure design, available variants: 71814A (25° contact angle), 71814C (15° contact angle).

It bears combined radial load and one-way axial load. Ultra-slim cross-section greatly reduces radial installation space. Widely used in pairs (DB / DF / DT arrangement) to withstand bidirectional axial force. Perfect for high-precision equipment with strict dimensional restrictions. Common applications include precision machine tool rotary tables, testing equipment, robotic joints and high-speed precision spindles.

Formal quotation will be sent within 24 hours upon your inquiry.

Model:

71814

Dimensions:

d70 mm, D90 mm, B13 mm

Min chamfer r:

0.6 mm

Net weight:

approx 0.18 kg

Structure:

Single row thin-wall angular contact ball bearing

Contact angle:

C=15° / A=25° optional

Material:

GCr15 bearing steel, pressed steel cage (brass cage optional)

Basic dynamic load Cr:

24500 N

Basic static load C0r:

29000 N

Limiting speed (grease):

6300 rpm

Complete dimension drawings and load data available on request.

1. Ultra-thin cross-section, effectively saves radial mounting space for compact machinery layout
2. Optional 15° / 25° contact angles to balance high-speed performance and axial load capacity
3. Can be combined into duplex sets to meet different rigidity and preload requirements
4. Precision grinding ensures low vibration and stable running accuracy
5. Standard ISO metric dimension, fully interchangeable with mainstream global brands
6. Customizable: P6/P5/P4 precision grade, different cage types, OEM laser marking, high-speed grease

• Precision machine tool rotary tables and light-duty spindle assemblies
• Automated equipment, robotic joint rotary mechanisms
• Optical testing instruments and precision positioning equipment
• Light-load high-speed rotary machinery with limited radial space
• Packaging automation and precision rotary indexing equipment

25 years professional bearing manufacturer, products exported globally.

Precision superfinishing for raceway surfaces and steel balls.

Strict noise, runout and clearance grouping inspection.

24-hour technical support for duplex bearing pairing and preload selection.

Ample stock for machinery distributors.

Precise dimensions and stable service performance.

GCr15 raw material quenching & tempering hardness inspection

Precision superfinishing for inner and outer raceways

Contact angle detection, internal clearance and rotational runout testing

Dimensional tolerance and surface roughness inspection

If you need 71814 angular contact ball bearings:

Send inquiry to obtain below supports:

• Quick quotation within 24 hours
• 71814C / 71814A variant consultation
• Precision grade and duplex matched bearing solution
• Competitive factory direct price
• Contact our sales team for full datasheets and formal offer.

Q1: Equivalent model

71814 = simplified marking; complete standard designation 70014.

Q2: Main dimensions of 71814?

70×90×13 mm thin-wall angular contact ball bearing.

Q3: Installation reminder

Single bearing only carries one-way axial load; adopt matched sets for bidirectional thrust.
