GQZ UCP204 Two-Bolt Pillow Block Bearing Unit 20mm Shaft Cast Iron Housing Equipped With UC204 Insert Bearing

The UCP204 is a standard two-bolt pillow block bearing assembly, consisting of UC204 self-aligning insert ball bearing and P204 cast iron housing with double set screw locking structure. It mainly bears radial load and withstands slight axial load. The spherical outer ring provides self-aligning capability to compensate minor shaft misalignment, widely adopted for base mounting of various rotary machinery under dusty and humid working conditions.

👉 Get a quote within 24 hours for your project

Model

UCP204

Inner Shaft Diameter (d)

20 mm

Base Length (L)

127 mm

Mounting Hole Spacing (J)

95 mm

Center Height (H)

33.3 mm

Insert Bearing Width (B)

31 mm

Mounting Bolt Size

M10

Structure

Two-bolt pillow block bearing unit

Insert Bearing Material

GCr15 bearing steel

Housing Material

High strength HT200 cast iron

Locking Method

Double set screw locking

Seal Type

Double lip rubber contact seal

Relubricable

With M6 grease nipple

Basic Dynamic Load Cr

12800 N

Basic Static Load C0r

6650 N

Limiting Speed (Grease)

5200 rpm

Net Weight

Approx 0.63 kg

👉 Full technical data and drawings available upon request

• Self-aligning spherical outer ring offsets minor shaft installation misalignment
• Dual set screw locking tightly grips shaft to prevent slipping during operation
• Integrated cast iron base housing features high rigidity and impact resistance
• Double lip rubber seals block dust, water splash and fine contaminants
• Pre-filled long service grease, grease nipple supports convenient re-lubrication
• Custom options: stainless steel housing, high temperature grease, OEM branding

👉 Helps reduce maintenance cost and improve machine running stability

This bearing unit is widely used in:

• Conveyor belt roller base support assembly
• Industrial cooling fans, blowers and ventilation equipment
• Textile machinery, packaging transmission equipment
• Small agricultural machinery and light food processing machines

👉 Ideal for customers looking for reliable and long-life bearing solutions

• 25+ years experience in mounted bearing unit manufacturing
• Exported to 50+ countries worldwide
• Rich experience in OEM & custom pillow block bearing projects
• Strict full-process quality inspection before shipment
• Fast response within 24 hours for technical consultation
• Stable bulk supply for machinery distributors

👉 We focus on quality, reliability, and long-term partnership

• Raw material hardness inspection for bearing steel & cast iron
• Precision grinding & superfinishing of bearing raceway
• Heat treatment hardness and metallurgy control
• Self-aligning clearance & rotation smoothness testing
• Final dimensional and appearance inspection before delivery

👉 Ensuring consistent stable performance for every bearing unit
