GQZ UCP216 Two-Bolt Pillow Block Bearing Unit 80mm Shaft Cast Iron Housing Equipped With UC216 Insert Bearing

Name: GQZ UCP216 Two-Bolt Pillow Block Bearing Unit 80mm Shaft Cast Iron Housing Equipped With UC216 Insert Bearing
Brand: Wuxi Guangqiang Bearing Trade Co.,Ltd
SKU: UCP216
Price: 188.00 USD
Availability: InStock

Brand Name:	GQZ
Model Number:	UCP216
MOQ:	100.PCS
Price:	negotiation
Delivery Time:	5 working days
Payment Terms:	T/T,Western Union,Paypal,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO9001/ISO14001/GJB9001

Supply:

30000 Set/Sets Per Month

Operatingtemperature:

-30°C To 120°C

Outer Ring:

Spherical OD For Self-Aligning Mounting

Customized:

Acceptable

Outerdiameter:

Varies (e.g., 47mm - 150mm)

Cage:

Steel Cage.Brass Cage.Nylon Cage

Shaft Diameter:

28 Mm

Free Samples:

Available

Materila:

Gcr15 Chrome Steel

Parameter:

Rolling Colummn Number:

Double Row

Noise Level:

Z1,Z2,Z3,Z4

Operatingspeed:

Suitable For Medium To High Speeds

Quality Standard:

ISO9001:2000

Package:

Original Packing

Mountingtype:

Press Fit / Slip Fit

Accuracy:

P5 Or P4

Number Of Row:

Single Row

Sealingtype:

Rubber Seal

Precisiongrade:

P5, P6, P0

Thickness:

18.288/12mm

Row Type:

Single Row

Precision Class:

P0 / P6

Seal Type:

Open,double Seals,double Shields

Size:

Various Sizes Available

Temperaturerange:

-30°C To 120°C

Durability:

High Durability For Harsh Environments

Sealing:

2S (Double Lip Contact Seal)

Holder:

Bakelite Holder

Widthrange:

4mm To 60mm

Row:

Double Row

Market:

Europe Or USA Or Russia Or Japan

Loadcapacity:

High Load Capacity

Ouside Diameter:

380mm

Lubrication:

Pre-lubricated Or Grease-packed

Usage:

Industrial,machinery,bearing Housing

Retainer:

Nylon/steel

Bore Diameter:

17 Mm

Viberation Level:

V1,V2,V3,V4

Cor:

120.273 Lbs

Load Capacity:

High Radial And Axial Load

Row Number:

Double Row

Characteristic:

High Speed And High Rigidity

Apilication:

Farm Machinery

Cage Material:

Steel

Grease Fitting:

Integrated, Standard M6 Thread

Installation:

Easy Installation

Housing:

F218

Precision Rating:

Hs Code:

8482200000

Applicable Industries:

Machinery Repair Shops, Other

Housing Type:

Split Plummer Block

Packing:

Singe Carton Packing

Locking Type:

Eccentric Locking Collar

Dynamic Load Rating:

10.8 KN

Main Market:

Southeast Asia,Europe,us,South America

Vibration:

V1 V2 V3 V4

Bore:

158.75 Mm

Installationtype:

Press-fit Or Bolt-on

Outerring:

Yes

Materical:

GCr15

Seals Type:

OPEN ZZ 2RS

Certifiexcavatore:

ISO9001:2000 TS16949

Ring Separation:

Separable Ring

Center Height:

80 Mm

Productname:

Pillow Block Bearing

Weight:

2.97kg

External Diameter:

180

Innerring:

Chrome Steel

Port:

Shanghai Port

Precision:

P0, P6,P5

Expansion Type:

Non-Expansion Bearing (Fixed)

Duty Type:

Normal Duty

Speedrating:

3000 RPM

Old Model:

3518

Packaging Details:

Standard Carton Box

Supply Ability:

1000.pcs / Month

Product Description

1. Product Overview

The UCP216 is heavy-duty two-bolt pillow block bearing assembly, composed of UC216 spherical outer insert ball bearing and P216 cast iron housing with double set screw locking. It mainly bears radial loads and tolerates minor axial loads. Spherical outer ring offers self-aligning capability to compensate shaft installation misalignment, widely adopted for base mounting of large rotary equipment under dusty and humid operating environments.

👉 Get a quote within 24 hours for your project

2. Technical Specifications

Model: UCP216
Inner Shaft Diameter (d): 80 mm
Base Length (L): 292 mm
Mounting Hole Spacing (J): 230 mm
Center Height (H): 90 mm
Insert Bearing Width (B): 108 mm
Mounting Bolt Size: M20
Structure: Two-bolt pillow block bearing unit
Insert Bearing Material: GCr15 bearing steel
Housing Material: High strength HT200 cast iron
Locking Method: Double set screw locking
Seal Type: Double lip rubber contact seal
Relubricable: With M6 grease nipple
Basic Dynamic Load Cr: 108000 N
Basic Static Load C0r: 72200 N
Limiting Speed (Grease): 2600 rpm
Approx Net Weight: 11.5 kg

👉 Full technical data and drawings available upon request

3. Key Advantages

Self-aligning spherical outer ring offsets minor shaft installation misalignment
Dual set screw locking firmly grips shaft to prevent slipping during heavy load operation
Thick integrated cast iron base housing delivers high rigidity and shock resistance
Double lip rubber seals block dust, water mist and fine particulate contaminants
Pre-filled long service grease, grease nipple supports convenient periodic re-lubrication
Custom options: stainless steel housing, high temperature grease, OEM branding

👉 Lower maintenance costs and improve continuous running stability of machinery

4. Applications

This bearing unit is widely used in:

Large conveyor belt roller base support assembly
Industrial fans, blowers and ventilation equipment
Mining machinery, grain processing and feed equipment
Agricultural heavy machinery and construction auxiliary equipment

👉 Ideal for customers looking for reliable and long-life bearing solutions

5. Why Choose GQZ Bearing

25+ years experience in mounted bearing unit manufacturing
Exported to 50+ countries worldwide
Rich experience in OEM & custom pillow block bearing projects
Strict full-process quality inspection before shipment
Fast response within 24 hours for technical consultation
Stable bulk supply for machinery aftermarket distributors

👉 We focus on quality, reliability, and long-term partnership

6. Quality Control

Raw material hardness inspection for bearing steel & cast iron
Precision grinding & superfinishing of bearing raceway
Heat treatment hardness and metallurgy control
Self-aligning clearance & rotation smoothness testing
Final dimensional and appearance inspection before delivery

👉 Ensuring consistent stable performance for every bearing unit

7. Get a Quote Now

Looking for a reliable bearing supplier?

👉 Send your inquiry to get:

Fast quotation within 24 hours
Professional engineer technical support
Custom bearing unit solution suggestions
Competitive factory direct price

👉 Click “Send Inquiry” or contact us now

Wholesale High Speed Deep Groove Ball Bearings Hybrid Ceramic Ball Bearing 625 Bearings 2RS ZZ for Mechanical 1 GQZ UCP216 Two-Bolt Pillow Block Bearing Unit 80mm Shaft Cast Iron Housing Equipped With UC216 Insert Bearing

8. FAQ

Q1: Can you provide custom bearings?

Yes, we support OEM and custom production based on drawings and load requirements.

Q2: What is your delivery time?

Standard models: 7–15 days

Custom products: depending on specifications

Q3: Do you support large bulk orders for machinery aftermarket?

Yes, we provide stable mass supply for long-term cooperative distributors.
