GQZ UCP205 Two-Bolt Pillow Block Bearing Unit 25mm Shaft Cast Iron Housing Equipped With UC205 Insert Bearing

Name: GQZ UCP205 Two-Bolt Pillow Block Bearing Unit 25mm Shaft Cast Iron Housing Equipped With UC205 Insert Bearing
Brand: Wuxi Guangqiang Bearing Trade Co.,Ltd
SKU: UCP205
Price: 188.00 USD
Availability: InStock

Brand Name:	GQZ
Model Number:	UCP205
MOQ:	100.PCS
Price:	negotiation
Delivery Time:	5 working days
Payment Terms:	T/T,Western Union,Paypal,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO9001/ISO14001/GJB9001

Car Make:

Toyota

Precision:

P0 P6 P5 P4 P2

Rows Number:

Single

Transport Package:

Natral

Color:

Blue Black Green

Outside:

Stardard Size

Mounting Type:

Flange Mounted

Samples Available:

Bearing Unit UCF207,UCF 208, UCF209

Bearing:

Wheel Bearing

Housing Material:

Cast Iron HT200

Lubrication:

Grease / Oil

Outer Diameter:

Varies By Model

Speed:

3000RMP

Quality:

High-Quality

Abs:

Without ABS

Bore Type:

Round

Material Of Pillow:

HT200

Seals Type:

Sealed

Applications:

Conveyor Systems, Agricultural Machinery, Industrial Equipment

Row Number:

Double Row

Hardness:

60-64HRC

Main Market:

Europe America Africa

Bore:

65 Mm

Temperaturerange:

-20°C To 120°C

Origin:

Ningbo

Packing:

Customer Requirement

Sample:

Available,free Provide

Delivery:

1~15days

Stock:

Large Ex-stock

Port Name:

Shanghai / Ningbo

Net Weight:

1.12 Kg

Locking Type:

Set Screw Locking

Expansion Type:

Non-Expansion Bearing (Fixed)

Huosing Material:

Cast Steel|cast Iron

Express:

DHL, UPS, FEDEX, TNT, EMS, Etc

Model No:

DAC35680033

Outerdiameter:

80mm

Loadcapacity:

5000 N

Pillow Block Bearingmodel:

Pillow Block Bearing UCP213

Packaging Details:

Standard Carton Box

Supply Ability:

1000.pcs / Month

Product Description

1. Product Overview

The UCP205 is heavy-duty two-bolt pillow block bearing assembly, composed of UC205 spherical outer insert ball bearing and P205 cast iron housing with double set screw locking. It mainly bears radial loads and tolerates minor axial loads. Spherical outer ring offers self-aligning capability to compensate shaft installation misalignment, widely adopted for base mounting of rotary equipment under dusty and humid operating environments.

👉 Get a quote within 24 hours for your project

2. Technical Specifications

Model: UCP205
Inner Shaft Diameter (d): 25 mm
Base Length (L): 140 mm
Mounting Hole Spacing (J): 105 mm
Center Height (H): 36 mm
Insert Bearing Width (B): 43.7 mm
Mounting Bolt Size: M10
Structure: Two-bolt pillow block bearing unit
Insert Bearing Material: GCr15 bearing steel
Housing Material: High strength HT200 cast iron
Locking Method: Double set screw locking
Seal Type: Double lip rubber contact seal
Relubricable: With M6 grease nipple
Basic Dynamic Load Cr: 14000 N
Basic Static Load C0r: 8100 N
Limiting Speed (Grease): 6600 rpm
Approx Net Weight: 0.85 kg

👉 Full technical data and drawings available upon request

3. Key Advantages

Self-aligning spherical outer ring offsets minor shaft installation misalignment
Dual set screw locking firmly grips shaft to prevent slipping during heavy load operation
Thick integrated cast iron base housing delivers high rigidity and shock resistance
Double lip rubber seals block dust, water mist and fine particulate contaminants
Pre-filled long service grease, grease nipple supports convenient periodic re-lubrication
Custom options: stainless steel housing, high temperature grease, OEM branding

👉 Lower maintenance costs and improve continuous running stability of machinery

4. Applications

This bearing unit is widely used in:

Conveyor belt roller base support assembly
Industrial fans, blowers and ventilation equipment
Grain processing machinery, feed production equipment
Agricultural machinery and light construction auxiliary equipment

👉 Ideal for customers looking for reliable and long-life bearing solutions

5. Why Choose GQZ Bearing

25+ years experience in mounted bearing unit manufacturing
Exported to 50+ countries worldwide
Rich experience in OEM & custom pillow block bearing projects
Strict full-process quality inspection before shipment
Fast response within 24 hours for technical consultation
Stable bulk supply for machinery aftermarket distributors

👉 We focus on quality, reliability, and long-term partnership

6. Quality Control

Raw material hardness inspection for bearing steel & cast iron
Precision grinding & superfinishing of bearing raceway
Heat treatment hardness and metallurgy control
Self-aligning clearance & rotation smoothness testing
Final dimensional and appearance inspection before delivery

👉 Ensuring consistent stable performance for every bearing unit

7. Get a Quote Now

Looking for a reliable bearing supplier?

👉 Send your inquiry to get:

Fast quotation within 24 hours
Professional engineer technical support
Custom bearing unit solution suggestions
Competitive factory direct price

👉 Click “Send Inquiry” or contact us now

Wholesale High Speed Deep Groove Ball Bearings Hybrid Ceramic Ball Bearing 625 Bearings 2RS ZZ for Mechanical 1 GQZ UCP205 Two-Bolt Pillow Block Bearing Unit 25mm Shaft Cast Iron Housing Equipped With UC205 Insert Bearing

8. FAQ

Q1: Can you provide custom bearings?

Yes, we support OEM and custom production based on drawings and load requirements.

Q2: What is your delivery time?

Standard models: 7–15 days

Custom products: depending on specifications

Q3: Do you support large bulk orders for machinery aftermarket?

Yes, we provide stable mass supply for long-term cooperative distributors.
