F-845889 BR2565DTA2 Double Row Tapered Roller Bearing Automotive Differential Pinion Bearing

1. Product Overview

F-845889 equivalent BR2565DTA2 is integrated double row tapered roller bearing specially designed for automobile differential pinion shaft. Double row back-to-back internal layout enables simultaneous bearing of large radial load and bidirectional axial thrust generated during vehicle acceleration, deceleration and turning.

All bearing rings and tapered rollers adopt high-purity quenched GCr15 bearing steel, ultra-precision superfinished raceway to reduce friction heat generation during high-speed rotation of transmission system. Built-in multi-layer composite contact seals block gear oil leakage and prevent metal debris, dust from entering bearing interior. Pre-filled high-temperature gearbox extreme pressure grease inside, stable anti-fatigue performance under long-time variable speed and variable load driving conditions. Compact integrated structure saves differential internal layout space, widely matched with passenger car, light commercial vehicle drive axle differential pinion transmission assembly.

2. Technical Specifications

Model: F-845889, Equivalent Model: BR2565DTA2
Structure: Double row back-to-back tapered roller bearing for auto differential pinion
Raw material: GCr15 high carbon chromium bearing steel for all rolling components
Basic dynamic radial load Cr: 68.5kN
Basic static radial load C0r: 106kN
Limiting rotating speed(grease lubrication): 6500 r/min
Single bearing net weight: 0.42kg
Operating temperature range: -35℃ ~ 125℃
Application Position: Drive axle differential pinion shaft support
Complete differential assembly installation drawings, variable load matching selection guide and long-cycle transmission vibration wear durability test reports can be provided upon customer request.

3. Core Advantages

• Double row back-to-back tapered roller integrated design, excellent bidirectional axial rigidity, effectively resist pinion shaft axial displacement under vehicle shifting and heavy load climbing.
• Equivalent interchange model F-845889 / BR2565DTA2 unified dimensional tolerance, direct replacement without modifying differential housing and pinion shaft.
• Built-in composite anti-oil-leakage sealing structure, effectively lock gearbox lubricating oil, avoid oil loss and bearing dry friction ablation.
• Optimized roller crown and raceway geometric profile, uniform stress distribution, greatly reduce contact pressure and extend service life under frequent start-stop working conditions.
• High-purity bearing steel overall forging and quenching, hardness reaches HRC60–65, outstanding anti-indentation and anti-contact fatigue performance.
• Pre-filled high-temperature shear-resistant extreme pressure grease, stable lubricating performance under continuous high-speed operation of transmission system.
• Compact monolithic structure simplifies differential assembly process, no complicated preload adjustment required during vehicle production line installation.
• Comprehensive customized service: P6 high precision upgrade, OEM laser marking on outer ring surface, neutral export carton anti-rust packaging, high temperature transmission grease pre-filling.

4. Application Scenarios

F-845889 BR2565DTA2 double row tapered roller pinion bearing is core heavy-load transmission spare part for automobile drive axle differential system:

• Compact passenger car front/rear drive axle differential pinion support bearing assemblies
• Light commercial vehicle, small pickup truck transmission differential matching units
• Urban SUV, crossover vehicle four-wheel drive power distribution differential positions
• Small logistics delivery van, mini cargo vehicle drive axle rotating components
• Modified passenger car, low-displacement sedan power transmission bearings

Aftermarket interchangeable BR series auto differential pinion double row tapered roller bearing
Cost-effective high-rigidity anti-fatigue auto transmission bearing solution for auto axle manufacturers, vehicle OEM and auto repair maintenance factories bulk procurement.

5. Why Choose GQZ Bearing

• 25 years professional manufacturing experience of auto differential pinion double row tapered roller bearings including F-845889 BR2565DTA2
• F-845889 BR2565DTA2 fully dimensionally interchangeable with international standard pinion bearings, consistent radial-axial load rating, oil sealing anti-leakage performance and transmission vibration tolerance standards.
• Complete OEM & ODM customization service supporting P6 precision grade and high-temperature gearbox special grease filling.
• Strict full pre-delivery inspection flow: GCr15 raw material metallographic & hardness test, tapered roller dimensional sorting screening, long-cycle transmission alternating load vibration aging test, repeated gear oil soaking sealing fatigue wear simulation test.
• Professional auto transmission bearing engineering team provides one-on-one radial-axial composite load calculation, differential housing matching selection and pinion shaft press-fit installation technical guidance within 24 working hours.
• Stable mass production workshop with competitive factory direct bulk wholesale price for large-volume single model orders, long-term stable supply for global passenger car and light commercial vehicle axle spare parts buyers.

We specialize in double row back-to-back tapered roller compact pinion bearing structure, built-in anti-leak composite sealing design, universal metric interchangeable differential mounting dimension standard and long-term win-win cooperation with automobile drive axle transmission equipment suppliers.

6. Quality Control

• Raw material chemical composition, internal flaw and hardness inspection for GCr15 bearing steel inner ring, outer ring and tapered roller blanks
• Bearing ring precision integral forging, multiple tempering stress relief, multi-step ultra-precision tapered raceway grinding process
• Tapered roller high-temperature quenching, mirror polishing and high-precision automatic dimensional sorting production line
• Composite oil-proof seal press fitting assembly process, strictly control sealing interference and anti-drop performance
• Targeted classified performance testing: F-845889 BR2565DTA2 long-cycle alternating axial-radial load rotation aging test, repeated gear oil immersion sealing durability test, continuous high-speed high-temperature anti-fatigue wear detection
• Full dimensional tolerance, surface crack and sealing tightness recheck before anti-rust oil coating and export carton moisture-proof packaging shipment

Every production batch of F-845889 BR2565DTA2 bearings undergoes full sampling automobile differential transmission vibration simulation rotation test to guarantee stable long-term high-rigidity anti-oil-leak rotating support performance in passenger car drive axle power transmission systems.

7. Get A Quote Now

If you need F-845889 BR2565DTA2 double row tapered roller differential pinion bearings for automobile drive axle manufacturing, passenger car assembly and auto repair maintenance bulk matching, send your purchase inquiry directly.

You will receive full professional supporting services after submitting inquiry:

• Fast official factory sealed formal quotation reply within 24 working hours
• One-on-one radial-axial composite load calculation, differential housing model matching and pinion shaft press-fit installation technical guidance from professional auto transmission bearing engineers
• Customized bearing performance solutions including P6 high precision upgrade and high-temperature gearbox extreme pressure grease options
• Competitive direct factory bulk wholesale price for large-volume F-845889 BR2565DTA2 single model orders

Provide your required purchase quantity, vehicle load weight and frequent start-stop driving working environment to obtain detailed formal quotation document.
