JP8049/JP8010 Metric Single Row Tapered Roller Bearing 80x125x24mm Cone Cup Assembly

JP8049/JP8010 is standard metric single-row separable tapered roller bearing set, composed of inner cone JP8049 and outer cup JP8010. Overall dimensions: 80mm inner bore × 125mm outer diameter × 24mm total assembly width.

This bearing simultaneously bears heavy radial load and unidirectional axial thrust load. Separable cone and cup design allows flexible preload adjustment during assembly to match different equipment clearance and rigidity demands. All rolling components adopt fully quenched GCr15 bearing steel, with precision super-ground tapered raceways and rollers to form uniform contact stress distribution, stable operation under shock, vibration and intermittent heavy impact loads. Widely applied to medium & heavy truck wheel hubs, metallurgical auxiliary transmission equipment, construction machinery, heavy-duty gear reducers, agricultural large tractors and off-road vehicles with high composite radial-axial load requirements.

Mounting shoulder dimension drawings, preload adjustment operation guides and load performance test reports can be provided on customer demand.

• Separable cone and cup integrated set, easy independent disassembly, installation and on-site preload adjustment, greatly reducing heavy vehicle and industrial equipment maintenance difficulty.
• Excellent high composite load bearing capacity, stable operation under heavy radial load and unidirectional axial thrust, outstanding anti-shock performance for metallurgy, construction and heavy vehicle working conditions.
• Ultra-precision grinding process for raceways and tapered rollers, smooth contact surface, low running noise, uniform contact area to avoid local overheating and premature raceway peeling.
• High hardness fully quenched GCr15 steel, stable internal metallographic structure, superior contact fatigue resistance and wear resistance, extending service life under long-term cyclic heavy impact load.
• Reinforced stamped steel cage, firmly fix each tapered roller position, prevent roller deflection and dislocation under large vibration and heavy impact.
• Standard metric interchangeable size, fully compatible with global same model bearing sets, direct replacement without modifying shaft and housing installation structure.
• Strict taper angle tolerance control, consistent contact pattern after installation, effectively reduce friction heat generation and abnormal wear during continuous heavy load operation.
• Multiple customizable options: P0/P6 precision grade, anti-rust surface coating, OEM laser marking on cone and cup, neutral export anti-rust carton packaging, high temperature resistant special grease filling.

JP8049/JP8010 metric single row tapered roller bearing set is heavy-duty separable rotary spare part for 80mm shaft with high composite radial-axial load support demand:

• Medium and heavy commercial truck, large trailer wheel hub bearing assemblies
• Metallurgical conveying equipment, rolling mill auxiliary transmission shaft units
• Large farm tractors, heavy harvesters agricultural machinery axle assemblies
• Medium-size heavy construction machinery, off-road vehicle rotary support positions
• Heavy-duty industrial gear reducer input and intermediate shaft supporting points

Aftermarket interchangeable JP8000 series metric tapered roller bearing

High load impact resistant bearing solution for heavy vehicle parts factories, metallurgical equipment OEM manufacturers and heavy industry equipment bulk maintenance procurement.

• We have 25 years of professional production experience in metric size single row tapered roller bearings including JP8049/JP8010 matched sets.
• Our JP8049/JP8010 bearing sets maintain fully interchangeable dimensions consistent with international standard products, unified dynamic and static load parameters, taper angle and dimensional tolerance standards.
• Complete OEM and ODM customized service support, covering multi-precision grades, surface anti-corrosion treatment and special temperature resistant grease filling requirements.
• Strict pre-delivery quality inspection process: GCr15 raw material composition and hardness test, roller sorting screening, long cycle heavy impact rotation aging test, assembly contact pattern inspection.
• Professional tapered roller bearing technical team provides one-to-one combined load calculation, preload adjustment scheme and installation torque guidance within 24 working hours.
• Large standardized heavy bearing production workshop provides competitive factory direct bulk wholesale price, stable long-term supply for global heavy truck, metallurgical and general heavy machinery spare parts purchasers.
• We focus on separable metric series tapered roller bearings, precise taper angle production control and universal interchangeable standard dimensions, committed to long-term win-win cooperation with heavy-duty vehicle and metallurgical transmission equipment suppliers.

• Raw material chemical composition, internal crack defect and hardness inspection for GCr15 cone, cup and tapered roller blanks
• Precision turning processing, multiple stress relief tempering, ultra-precision superfinishing grinding for tapered raceway and roller surfaces
• Tapered roller high temperature quenching, mirror polishing and high precision automatic sorting production line
• Stamped steel cage stamping and riveting process, cone and cup matching inspection, contact pattern detection during assembly
• Targeted performance testing: JP8049/JP8010 set long cycle heavy impact rotation aging test, composite radial axial load fatigue wear detection
• Comprehensive re-inspection of overall dimensional tolerance, taper angle and surface finish before anti-rust oil coating and export moisture-proof carton packaging.

Each production batch of JP8049/JP8010 bearing sets undergoes vehicle wheel hub and metallurgical equipment simulation cycle rotation test to ensure stable anti-impact heavy load rotary support performance for heavy-duty axle and transmission systems.

If you need JP8049/JP8010 metric tapered roller bearing sets for heavy truck axle, metallurgical machinery manufacturing, equipment assembly and machinery maintenance bulk matching, send your purchase demand directly.

Complete professional supporting services after sending inquiry:

• Formal official quotation reply within 24 working hours
• One-to-one radial and axial combined load calculation, preload adjustment and bearing installation technical support from professional bearing engineers
• Customized bearing performance upgrade options including multi-precision grades and special temperature resistant grease
• Favorable factory direct bulk wholesale price for large quantity single model orders of JP8049/JP8010

Please provide purchase quantity, working conditions (heavy impact, vibration, continuous operating temperature) to obtain complete official quotation documents.
