products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Automotive Bearings
Created with Pixso. Cylindrical Roller Bearing RN205M 25X45X15mm
  • name
  • name
  • name
  • name
  • name

Cylindrical Roller Bearing RN205M 25X45X15mm

Brand Name: GQZ
Model Number: RN205M
MOQ: 1
Price: $10
Delivery Time: 5 days
Payment Terms: T/T
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
ISO9001
Lead Time:
Within 3 Days
Packing:
Individual Packing Box
Clearance:
C3 , C4 , C0
Bore:
55 Mm
Port:
Shanghai
Noiselevel:
Low Noise Design
Application:
Wheel Hubs, Transmission, Engine Components, Steering Systems
Productname:
Automotive Bearings
Service:
OEM Customized Services
Packaging Details:
standard export box
Supply Ability:
1000/month
Highlight:

Cylindrical Roller Bearing RN205M

,

25X45X15mm Automotive Bearing

,

RN205M Cylindrical Bearing with Warranty

Product Description
tem Standard Parameter
Model RN205M
Bearing Type Single-row no-outer-ring cylindrical roller bearing, small-torque cycloidal reducer special eccentric unit
Boundary Dimensions d=25mm, D=45mm, B=15mm
Basic Dynamic Load Rating (Cr) 17.2kN
Basic Static Load Rating (Cor) 10.4kN
Material Inner ring, rollers: GCr15 bearing steel, vacuum quenching
Cage Machined brass cage (M suffix standard); stamped steel cage optional
Seal Type Open-type, no seal, gear-oil splash / circulating oil lubrication
Precision Class P0 standard; P6 / P5 optional for precision low-vibration reducer
Internal Clearance Special radial clearance matched for small-size cycloidal pin-wheel reducer eccentric cam shaft
Operation Temperature -30ºC ~ +120ºC
Lubrication Reducer gear-oil splash lubrication
Feature Outer ring omitted; housing bore acts as functional raceway; only bears heavy radial load, no axial load capacity; separable inner assembly
Weight 0.085kg
Bearing No. Size
d B rs/min D2 max a
RN204 20 14 1 37.3 3.75
RN205 25 15 1 42.3 4.25
RN206 30 16 1 50.5 4.25
RN207 35 17 1.1 59 4
RN208 40 18 1.1 66.2 4
RN209 45 19 1.1 71.2 4.5
RN210 50 20 1.1 77 5
RN21 l 55 21 1.5 85 5
RN212 60 22 1.5 93.2 5
RN213 65 23 1.5 101 5
RN214 70 24 1.5 105.8 5.5
RN215 75 25 2 111.4 5.5
