SL045020PP2NR Double Row Full Complement Cylindrical Roller Bearing 100x150x67mm Sealed Locating Bearing

SL045020PP2NR double row full complement locating bearing, interchangeable with NNF5020ADA-2LSV, dimension 100×150×67mm.

Code Definition

• SL045020: Medium heavy full complement roller base model
• PP: Double-sided contact rubber seal against dust, mud and water splash
• 2NR: Dual outer ring snap ring grooves for axial housing locking

Triple inner ribs + single outer central rib form integrated locating structure. Cage-free full roller layout maximizes radial load capacity, supports heavy radial load plus moderate bidirectional axial thrust. Pre-filled heavy-duty lithium grease; side relubrication port enables maintenance without disassembly. Designed for low-speed heavy-load rotary units including medium crane pulleys, port lifting rollers and mining light conveyors.

Drawings and heavy-load durability test reports available on request.

1. Cage-free full roller design delivers high radial load capacity
2. Integrated rib structure prevents axial shifting under heavy thrust
3. Double PP lip seal blocks outdoor dust, rainwater and metal debris
4. Dual snap ring grooves simplify axial fixation without extra housing shoulders
5. Side grease port supports convenient on-site relubrication
6. Compact cross-section reduces hub installation space
7. Standard interchangeable dimensions for direct one-to-one replacement
8. Customizable clearance, high-temp grease, laser marking and neutral export packaging

• Medium mobile & tower crane wire rope pulley bearings
• Port small gantry crane, reach stacker lifting roller assemblies
• Mining light-duty belt conveyor tension rollers
• Metallurgical small steel coil transport auxiliary rollers
• Marine deck small lifting winch rotary positioning components
• Low-speed heavy-load medium industrial hoist support bearings

Suitable for OEM production and aftermarket maintenance of medium lifting, port and mining machinery.

25 years specialized production of SL04 series sealed full complement roller bearings including SL045020PP2NR medium crane pulley models.

Global unified dimensional standards, fully interchangeable with imported equivalent bearings.

Complete OEM & ODM custom service for clearance adjustment, high-temperature grease, anti-corrosion treatment and outer ring marking.

Strict full-process inspection: raw material hardness test, roller sorting, heavy impact rotation aging and sealing tightness batch inspection.

Professional engineers provide load calculation, interference fit design and outdoor long-life lubrication guidance within 24 working hours.

Factory direct bulk pricing, stable continuous mass supply for global medium machinery spare part buyers.

• Raw material composition and hardness inspection for GCr15 rings and rollers.
• CNC forging, multi-cycle stress relief tempering and ultra-precision raceway superfinishing.
• Roller high-temp quenching, mirror polishing and automatic dimensional grouping sorting.
• Precise dual snap ring groove turning, quantitative heavy-duty grease filling and PP seal press-fitting.
• Performance verification: crane pulley impact cycle aging, dust-water mixed environment durability, axial anti-sliding stability test.
• Final full dimension, roundness and flatness reinspection before anti-rust treatment and export carton packaging.

Each batch undergoes continuous heavy load simulation test to guarantee stable sealed heavy-load operation performance.

Submit purchasing demand for SL045020PP2NR bearings applied to medium crane pulleys, port lifting equipment and mining light conveyors.

Full one-stop services after inquiry:

1. Official detailed quotation within 24 working hours
2. Technical support for load matching, shaft installation and long-term lubrication
3. Custom upgrades: C3 enlarged clearance, stainless steel passivation, high-temperature synthetic grease
4. Competitive factory bulk price for large-volume single model orders

Please state order quantity and actual working conditions (outdoor dust/water environment, continuous low-speed heavy impact operation) to receive complete standardized quotation documents.
