6205‑2Z/C3 Deep Groove Ball Bearing 25x52x15mm for Industrial Rotating Shaft

Name: 6205‑2Z/C3 Deep Groove Ball Bearing 25x52x15mm for Industrial Rotating Shaft
Brand: Wuxi Guangqiang Bearing Trade Co.,Ltd
SKU: 6205‑2Z/C3
Price: 0.05 USD
Availability: InStock

Brand Name:	GQZ /OEM
Model Number:	6205‑2Z/C3
MOQ:	1 PCS
Price:	USD 0.05-0.08
Delivery Time:	3-5 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001:2015

Bearing Model:

6205‑2Z/C3

Number Of Row:

Single Row

Width（B）:

15mm

Outer Diameter（D）:

52mm

Precision Rating:

P0/P6

Material:

GCr15 Chrome Bearing Steel

Inner Diameter（d）:

25mm

Seal Type:

2Z Double Metal Shield

Packaging Details:

in individual packing box

Supply Ability:

100000 Sets per month

Highlight:

6205-2Z/C3 deep groove ball bearing

25x52x15mm industrial ball bearing

deep groove ball bearing for rotating shaft

Product Description

6205‑2Z/C3 Deep Groove Ball Bearing 25x52x15mm for Industrial Rotating Shaft

Product Overview

6205‑2Z/C3 is single‑row deep groove ball bearing fitted with double metal shields and C3 enlarged internal clearance.
It handles radial loads as well as bidirectional axial loads for general industrial rotating assemblies.
Pre‑greased at factory, double‑side metal shields block dust and dirt to cut daily maintenance work.
C3 clearance fits working conditions with higher operating temperature and minor shaft thermal expansion.
Made of standard bearing steel, it delivers steady running performance for motor and transmission equipment.

*Need a quick quote? Just send us your bearing model & quantity — we’ll get back to you fast.

Key Specifications

Item	Specification
Bearing Model	6205‑2Z/C3
Bearing Type	Deep Groove Ball Bearing
Bore(d)	25 mm
Outer Diameter(D)	52 mm
Width(B)	15 mm
Basic Dynamic Load(Cr)	14.8 kN
Basic Static Load(C0r)	7.8 kN
Limiting Speed(Grease)	14000 r/min
Seal Type	2Z Double Metal Shields
Cage Material	Sheet Steel Cage
Material	GCr15 Chrome Bearing Steel
Tolerance Class	P0
Number Of Row	Single Row
Internal Clearance	C3
Weight	0.13 kg

Main Features

2Z double metal shields offer reliable dust protection without contact friction loss.
C3 larger internal clearance accommodates thermal expansion under high‑temperature running.
Supports radial load and bidirectional axial load for multi‑direction force conditions.
Factory pre‑filled grease allows direct installation with no extra lubrication needed.
Sheet steel cage keeps rolling elements stable under continuous high‑speed rotation.
Robust standard structure, easy sourcing and cost‑effective for volume industrial matching.

Typical Applications

General‑purpose electric motors and driving motor assemblies
Conveyor systems and logistics transport machinery
Fans, blowers and high‑temperature running mechanical parts
Pumps and light‑duty industrial transmission units
General workshop machinery and rotating shaft support points

*Ready stock. Short lead time. Fast delivery. Send us your bearing list and let’s get started!

Why Choose GQZ Bearing

30 years professional bearing industry experience
ISO certified strict quality inspection
Flexible OEM & private label customization
3-5 days fast delivery for stocked bearings
Full bearing series, universal interchangeable size
Factory direct price & reliable after-sales service

6205‑2Z/C3 Deep Groove Ball Bearing 25x52x15mm for Industrial Rotating Shaft

FAQ

Q1: What do 2Z and C3 stand for?

A1: 2Z is double metal dust shields, C3 is enlarged clearance for high‑speed high‑temperature use.

Q2: Are 2Z/C3 bearings pre‑greased?

A2: Yes, factory pre‑lubricated for fast installation and less maintenance.

Q3: Why choose C3 clearance?

A3: It compensates shaft thermal expansion to prevent bearing jamming.

Q4: Is 2Z bearing waterproof?

A4: No, only dust‑proof. Choose 2RS for wet working conditions.

Q5: What loads can 2Z/C3 take?

A5: Mainly radial loads, plus moderate bidirectional axial loads.

*Need custom bearings? Share your drawings, specifications or requirements — we’ll find the right solution for you.
