SL183022 Full Complement Cylindrical Roller Bearing 110x170x45mm Semi-Locating Open Heavy Load Bearing

1. Product Overview

SL183022 is single row cage-free full complement cylindrical roller bearing, dimension 110×170×45mm, semi-locating structural design with two inner ribs and one outer rib. Max quantity rollers installed without cage to achieve maximum radial load capacity. Open structure supports side re-lubrication; semi-locating feature limits shaft axial displacement in single direction, compatible with heavy low-to-medium speed equipment. Equivalent model NCF3022, widely applied to textile machinery, wind power auxiliary parts, heavy conveyors, mining equipment and paper industry calender rollers.

2. Technical Specifications

Model: SL183022
d:110mm, D:170mm, B:45mm
Min fillet r:2mm, axial clearance s:5.5mm
E:156.7mm, D1:149.3mm, d1:127.3mm
Dynamic load Cr:280kN, Static load C0r:385kN
Grease limiting speed:2350r/min
Net weight:3.5kg
Structure: Single row full roller, open semi-locating, no cage
Material: GCr15 vacuum smelting bearing steel, hardness HRC60-65
Clearance: Standard CN, C3/C4 customizable
Precision: P0 / P5 optional
Operating temperature: -30℃ ~ 120℃
Dimension drawings and durability test reports available on request.

3. Core Advantages

• Cage-free full roller layout, ultra-high dynamic & static radial load capacity
• Semi-locating rib structure controls unidirectional axial movement, simplify shaft layout
• Open end design allows regular supplementary lubrication to extend service life
• Thickened raceway and roller surface, strong wear resistance for continuous heavy load operation
• Compact outer dimension reduces overall equipment weight and installation space
• Standard interchangeable size, cross replaceable with NCF3022 series bearing
• Custom high-temperature tempering, large clearance grade and outer ring laser marking available

4. Application Scenarios

• Textile industry: Large spinning frames, textile calender heavy rollers
• New energy: Wind turbine auxiliary transmission, fan heavy spindle supports
• Conveying & mining: Mine heavy belt conveyors, stone crusher auxiliary shafts
• Paper machinery: Paper making drying rollers, calender rotating assemblies
• General heavy machinery: Large gearbox low-speed heavy load positions

Fit OEM assembly and aftermarket replacement of heavy radial load low-medium speed industrial equipment.

5. Why Choose GQZ Bearing

25 years production experience of SL18 series full complement cylindrical roller bearings. Vacuum smelting high-purity GCr15 steel with complete quenching and tempering heat treatment. Full OEM & ODM customization for clearance grade, high-temperature treatment and special heavy-load grease. Strict full-process inspection includes raw material hardness test, ultra-precision raceway grinding, roller sorting and heavy-load vibration aging test. 24-hour professional technical support for semi-locating shaft layout design, axial displacement allowance calculation and periodic re-lubrication maintenance plans. Factory direct bulk price, stable heavy-duty bearing spot inventory for global textile, wind power and mining machinery buyers.

6. Quality Control

1. Raw material chemical composition and hardness inspection
2. Integral quenching, tempering and stress relief to eliminate internal residual stress
3. CNC ultra-precision inner and outer ring cylindrical raceway mirror grinding
4. High-precision cylindrical roller screening and dimensional classification
5. Dust-free assembly with heavy-load mechanical grease filling options
6. Continuous rotation aging and heavy radial load durability cycle testing
7. Full dimension inspection, anti-rust oil coating, neutral moisture-proof export carton packaging

Each batch completes temperature rise and vibration test to guarantee stable long-time heavy-load operation.

7. Get A Quote

Send inquiries for SL183022 full roller bearings used on textile machines, wind power equipment and mining conveyors.
Services after inquiry:

1. Standard quotation delivered within 24 working hours
2. Technical guidance for semi-locating shaft layout and lubrication cycle arrangement
3. Upgrade options: P5 high precision grade, C4 super loose clearance, high-temperature anti-oxidation grease
4. Competitive factory bulk unit price for large quantity orders

Please state order quantity, working load, rotating speed and site environment for complete quotation documents.
