16012 60x95x11mm Thin Section Single Row Open Deep Groove Ball Bearing

1. Product Overview

16012 belongs to 16000 series thin section single row open deep groove ball bearing, standard dimension 60×95×11mm, old model number 7000112. Ultra-narrow width thin wall structure saves installation space and reduces overall equipment weight. Open type design supports continuous oil/grease circulation lubrication, smooth deep raceway bears radial load and bidirectional light axial load simultaneously, featuring low noise, low friction and stable high-speed rotation performance. Adopt super-finished raceway and high precision steel balls, long service life under continuous light-medium load operation. Widely matched for textile high-speed spindles, printing machine rollers, precision automation equipment, small industrial motors, optical testing instruments and light conveyor machinery.

2. Technical Specifications

Model: 16012
d=60mm, D=95mm, B=11mm
Min fillet r=0.6mm
Dynamic load Cr=19.9kN, Static load C0r=17.5kN
Grease limiting speed=6900r/min, Oil limiting speed=8100r/min
Net weight=0.224kg
Structure: Single row deep groove, open type without shield/seal, stamped steel cage
Material: Vacuum smelting GCr15 bearing steel, hardness HRC60-65
Clearance: Standard CN, C2/C3 customizable
Precision: P0 standard, P6/P5/P4 optional
Operating temperature: -30℃ ~ 120℃
Dimension drawings and high-speed durability test reports available on request.

3. Core Advantages

• 16012 ultra-thin cross-section design, narrow width 11mm, effectively save axial installation space for compact equipment
• Open structure allows free lubricant circulation, easy centralized oil supply for long-time continuous production lines
• Super-finished raceway surface reduces friction and running noise, stable performance at long-term high-speed operation
• Light weight thin wall structure lowers equipment overall load, suitable for lightweight automation and precision instruments
• Standard metric interchangeable size, universal replacement for mainstream textile, printing and automation OEM spare parts
• Multiple custom options: nylon/brass cage, C3 loose clearance, stainless steel anti-corrosion version, special high-speed low-viscosity grease
• Strict dimensional tolerance control, small runout to guarantee precision rotation for testing and optical equipment

4. Application Scenarios

• Textile machinery: High-speed spinning spindles, loom transmission rollers, winding machine rotating parts
• Printing & packaging equipment: Printing press paper feeding rollers, packaging machine light rotating assemblies
• Precision automation: Robotic auxiliary shafts, semiconductor wafer handling equipment, automated conveyor rollers
• Motor & power equipment: Small high-speed industrial motors, cooling fans, generator light load rotating parts
• Optical & testing instruments: Measuring turntables, medical diagnostic equipment, laboratory precision rotating mechanisms

Fit OEM assembly and aftermarket replacement of compact light-load high-speed precision rotating machinery.

5. Why Choose GQZ Bearing

25 years professional production of 16000 series thin section deep groove ball bearings. High-purity vacuum smelting GCr15 steel with complete quenching and tempering heat treatment, stable anti-fatigue performance under continuous high-speed light load. Full OEM & ODM customization for cage material, clearance grade, precision class and special lubricant. Strict full-process inspection flow: raw material hardness test, CNC ultra-precision raceway superfinishing, high-grade steel ball sorting and high-speed rotation aging test. 24-hour professional technical support for thin-wall shaft fit tolerance and circulating lubrication scheme design. Factory direct bulk price, sufficient 16012 bearing spot stock for global textile, printing and automation machinery manufacturers.

6. Quality Control

1. Raw material chemical composition and hardness inspection
2. Integral quenching and stress relief tempering to eliminate internal residual stress
3. CNC ultra-precision inner and outer ring raceway mirror superfinishing
4. High-precision steel ball screening and stamped steel cage stamping forming
5. Dust-free assembly with low-drag high-speed mechanical grease pre-filling
6. Continuous high-speed rotation aging and wear resistance cycle testing
7. Full dimension inspection, anti-rust oil coating, neutral moisture-proof export carton packaging

Each batch completes rotation smoothness and noise test to guarantee stable long-time high-speed precision operation for compact industrial equipment.

7. Get A Quote

Send inquiries for 16012 thin section open deep groove ball bearings used on textile spindles, printing rollers and precision automation motors.
Services after inquiry:

1. Standard formal quotation document delivered within 24 working hours
2. Technical guidance for thin-wall shaft fit tolerance and circulating lubrication layout
3. Upgrade options: P5 high precision grade, C3 loose clearance, nylon cage, low-noise synthetic high-speed grease
4. Competitive factory bulk unit price for large quantity orders

Please state order quantity, rotating speed and working environment for complete quotation documents.
