LYF213-2F 4-Bolt Flange Bearing, Eccentric Lock, Double 2F Mud-Proof Seals

LYF213-2F four-bolt square cast iron flange bearing unit, matched with YEL213-2F double extended inner ring eccentric lock insert bearing. Double-sided 2F composite seal adopts metal flinger + NBR lip two-stage barrier to block mud, crop debris and cooling water splashes. Eccentric locking collar tightly clamps double extended inner ring for stable single-direction rotation under long heavy vibration. Spherical outer ring provides ±2.5° self-alignment to compensate shaft assembly misalignment. Side grease nipple supports periodic supplementary lubrication. Widely used for large grain harvesters, heavy belt conveyors, grain sorting equipment and textile heavy transmission rollers.

Get quotation within 24 hours

• Dual 2F anti-fouling sealing system: Outer metal flinger throws mud clumps via centrifugal force; inner rubber lip blocks fine dust and water mist, far better anti-mud performance than single 2S rubber seals.
• Eccentric collar delivers uniform full-circle clamping force, anti-loose under continuous vibration, no scratch on shaft surface, ideal for fixed single rotation equipment.
• HT200 grey cast iron square flange housing, high structural rigidity, quick bolt mounting & disassembly, compact size saves equipment layout space.
• ±2.5° self-aligning spherical outer ring eliminates assembly offset stress, reduces abnormal bearing wear and running noise.
• Reserved grease fitting for regular lubrication, extend service life and cut equipment maintenance downtime.
• GCr15 fully heat-treated bearing steel, stable heavy radial load capacity, excellent wear & impact resistance for long-hour heavy-duty operation.
• Standard unified metric dimensions, fully interchangeable with single-seal LYF213 for direct mud-proof sealing upgrade.

Reduce maintenance workload and guarantee stable operation of heavy agricultural & industrial machinery

• Large grain harvesters, field rotary tillers
• Heavy-duty belt conveyors, grain drying & sorting production lines
• Feed processing equipment, textile heavy transmission rollers
• Dusty, humid, muddy indoor and semi-outdoor production equipment

Dimension drawings and spec sheets can be provided upon request

• 25+ years professional manufacturer of 2F sealed eccentric lock four-bolt flange bearing units.
• Every batch passes mud resistance aging, vibration endurance and heavy load durability tests before delivery.
• Support OEM custom anti-rust coating, housing paint color and sealing upgrade schemes.
• Fast formal quotation and one-on-one professional installation technical support within 24h for all RFQs.
• Stable mass production capacity to meet long-term bulk order demands from global machinery manufacturers.

Factory direct price, consistent quality and on-time batch delivery for overseas buyers

• Raw bearing steel hardness & chemical composition inspection
• High-precision raceway grinding surface roughness test
• 2F double composite seal mud splash cycle aging durability test
• Eccentric collar anti-slip vibration impact test
• Low-noise continuous rotation heavy load performance test
• Full dimension sorting & 100% visual appearance inspection before packing

All LYF 213 2F bearing units pass multi-process strict quality inspection before shipment

Q1: What’s the advantage of 2F seal over single 2S rubber seal?
2F two-stage composite seal first repels large mud blocks by metal flinger, then isolates tiny dust and water mist with rubber lip, outstanding protection for muddy outdoor agricultural equipment.

Q2: What machinery fits LYF 213 2F?
Heavy equipment with 4-hole flat mounting base running in fixed single rotation, such as large harvesters, heavy conveyors and grain processing machines working in muddy field environments.

Q3: Can LYF 213 2F replace ordinary single-seal LYF213?
Yes, inner bore, outer diameter and flange mounting dimensions follow unified international metric standards, no modification to equipment mounting base during replacement.
