B37-9AUR Open UR Groove Auto Gearbox Deep Groove Bearing

B37-9AUR non-standard open deep groove ball bearing, dimension 37mm bore × 85mm outer diameter × 13mm width, specially matched for passenger car automatic and manual gearbox auxiliary shafts and differential assemblies. Open design without rubber seals, outer ring integrated UR snap ring groove for axial positioning, fitted with stamped steel cage and standard C0 clearance. It bears radial load and slight bidirectional axial load, runs stably and quietly under long-term high-speed shifting vibration. Made of fully quenched GCr15 chrome bearing steel with precise dimensional tolerance, fully interchangeable with original B37-9AUR. Complete formal quotation will be provided within 24 hours upon inquiry.

• Open structure enables full circulation of gearbox oil, excellent heat dissipation, no rubber seal aging or swelling risk under long-time high-temperature oil immersion
• Outer ring built-in UR retaining ring groove, install circlip directly for axial limit, simplify assembly without extra limiting components
• Superfinished deep groove raceway reduces rolling friction, stable operation under continuous gear shift impact
• High-hardness purified GCr15 steel delivers outstanding wear and anti-fatigue performance to extend gearbox service life
• OEM matching overall dimension, direct replacement without modifying gearbox housing and shaft parts
• Light stamped steel cage lowers rotation inertia, adapts to continuous medium-high speed transmission working conditions
• Standard P0 precision grade, customizable P6/C3 clearance to meet vehicle OEM assembly standards

Passenger car automatic & manual gearbox intermediate shafts, vehicle differential assemblies, light commercial vehicle reducers, small agricultural machinery transmission components.

Model: B37-9AUR Open Deep Groove Ball Bearing
Inner bore d: 37 mm
Outer diameter D: 85 mm
Width B: 13 mm
Outer ring feature: UR precision snap ring groove for circlip positioning
Seal structure: Open type, oil lubrication only
Cage: Stamped low carbon steel cage
Internal clearance: C0 standard clearance, C3 optional
Material: GCr15 chrome bearing steel
Basic dynamic load: 31.5 kN
Basic static load: 20.8 kN
Max oil lubrication limiting speed: 4500 r/min
Net weight: 0.37 kg
Working temperature range: -20℃ ~ +130℃
Accuracy grade: P0 standard, P6 customizable
Cross reference: B37-9, B37-9AUR
Dimension drawings and technical spec sheets available on request.

25+ years professional manufacturer of UR groove non-standard automotive gearbox bearings. All finished bearings pass high-speed continuous rotation test, shock load test and long-cycle fatigue durability test before delivery. Support customized anti-rust surface coating and special high-temperature gearbox lubricant filling service. One-on-one professional installation technical guidance and formal quotation within 24h for all RFQs. Stable mass production capacity meets bulk OEM and global distributor orders, factory direct selling price, stable consistent quality and punctual batch delivery.

• Raw GCr15 steel hardness & chemical composition incoming inspection
• High-precision raceway superfinishing roughness detection
• UR snap ring groove dimensional tolerance full inspection
• Open bearing gear oil circulation high-temperature aging test
• Continuous vibration load rotation fatigue life test
• Full dimension sorting inspection
• 100% visual appearance marking check before packaging
• Random sampling high-speed performance test before shipment
• All B37-9AUR bearings pass multi-process strict factory inspection.

Send bulk inquiry for B37-9AUR open UR groove transmission bearings and receive the following support:

1. Complete formal detailed quotation within 24 hours
2. Standard dimension drawings & press-fit installation operation guidance
3. Custom anti-rust surface treatment and special transmission lubricant filling service
4. Exclusive long-term bulk wholesale factory price without intermediate markup

Large-volume OEM cooperation is welcome anytime.

Q1: What does suffix UR mean on B37-9AUR?

A1: UR stands for precision circlip groove machined on outer ring, used together with retaining ring to restrict bearing axial displacement inside gearbox housing.

Q2: Difference between open B37-9AUR and rubber sealed bearings?

A1: Open design has no rubber seals, relies on circulating gear oil for lubrication and heat dissipation for internal gearbox positions; rubber sealed bearings apply to external dusty shafts with grease lubrication.

Q3: Can B37-9AUR replace original OEM bearings directly?

A3: Yes, inner bore, outer diameter, width and UR groove sizes are fully consistent, no modification to gearbox components required during replacement.
