B24-8.NX Open Mini CVT Control Shaft Precision Bearing

1. Product Overview

B24-8.NX non-standard single-row open deep groove ball bearing, dimension 24mm inner × 36mm outer × 8mm ultra-narrow width. Suffix NX = upgraded precision tolerance + anti-deformation structural optimization. Fully interchangeable with NSK B24-8.NX, matched for Asian passenger car CVT tiny hydraulic control valve micro shafts. Open structure without rubber seals, stamped low-carbon steel cage, standard C0 clearance, C3 customizable. Carries light radial load and slight bidirectional axial load, silent stable ultra-high-speed operation under high-temperature CVT oil environment. Made of fully quenched GCr15 steel with micron tight tolerance, direct OEM plug-and-play replacement. Formal quotation within 24h after inquiry.

2. Key Advantages

• Open through design for full CVT oil circulation, efficient heat dissipation, no rubber seal aging or oil leakage
• Smooth superfinished raceway reduces friction, less heat buildup during long continuous high-speed running
• NX optimized precision structure, smaller dimensional tolerance, better anti-deformation performance under frequent micro torque fluctuation
• High-hardness integrated thin-wall inner/outer rings, excellent wear & fatigue resistance, extend CVT service life
• Compact unified OEM mounting size, no modification to gearbox housing or micro shaft during installation
• Ultra-light stamped steel cage minimizes rotation inertia, fits long-term steady ultra-high-speed working of miniature control components
• P0 standard precision, P6 / C3 clearance customizable, stable mass production, cost-effective for aftermarket & bulk OEM orders

3. Applications

Asian passenger car CVT hydraulic control valve micro shafts, compact car gearbox miniature auxiliary shafts, light commercial vehicle tiny precision reducers, small agricultural machinery fine transmission moving parts.

4. Technical Specifications

5. Why Choose GQZ Bearing

25+ years professional manufacturer of B-series non-standard CVT bearings. All finished bearings pass high-speed rotation, shock and fatigue durability test before delivery. Custom anti-rust coating & high-temperature CVT dedicated grease filling supported. Professional transmission installation guidance and fast quotation for all RFQs. Stable bulk supply, factory direct price, consistent quality & on-time batch delivery.

6. Quality Assurance

• Raw steel hardness & chemical composition incoming inspection
• Raceway superfinishing roughness detection
• High-temperature CVT oil circulation aging durability test
• Vibration fatigue rotation cycle test
• Full dimension tolerance sorting inspection
• 100% visual appearance marking check before packaging
• Random high-speed performance sampling test before shipment

All B24-8.NX bearings pass multi-step strict factory inspection.

7. CTA

Inquire bulk B24-8.NX miniature CVT control shaft bearings to get full support:

1. Complete formal quotation within 24 hours
2. Standard dimension drawings & micro shaft press-fit installation guide
3. Custom anti-rust surface treatment & dedicated CVT lubricant filling service
4. Exclusive long-term factory wholesale price without middleman markup

Welcome large-volume OEM cooperation.

8. FAQ

Q1: What does suffix NX stand for?
A1: N = upgraded precision tolerance; X = reinforced anti-deformation optimized internal structure, better stability under frequent tiny load fluctuation.

Q2: Difference between open B24-8.NX and sealed bearings?
A2: Open bearing installed inside closed gearbox with circulating CVT oil lubrication; sealed bearings for external dusty shafts with independent grease lubrication.

Q3: Can it replace original NSK bearing directly?
A3: Yes, full consistent dimensions, no modification required during assembly.
