X-135006 Non-Standard Auto Transmission One Way Clutch Bearing

X-135006 single-row non-standard one way clutch bearing, dimension 54.572×71.211×20.5mm. Professional unidirectional locking structure, transmits torque in one rotation direction and free overrunning in reverse. Fully interchangeable with original NSK X-135006, specially matched for shift control mechanism inside Asian passenger car automatic transmissions. Open structure without rubber seals, stamped steel retainer, standard clearance as default, customized clearance available. Stable low-noise operation under frequent torque switching and high-temperature circulating gear oil environment inside transmission housing. Manufactured with fully quenched high-purity GCr15 chrome bearing steel and strict micron-level dimensional tolerance, direct OEM plug-and-play replacement without modifying gearbox housing or shaft. Complete formal quotation will be offered within 24 hours upon inquiry.

• Open through design for full gear oil circulation, continuous efficient heat dissipation, eliminate hidden troubles of seal aging and oil leakage
• Precision wedge locking structure, reliable unidirectional torque transmission, stable overrunning performance without slipping
• Thick-wall high-hardness inner and outer rings, excellent wear resistance and impact resistance under frequent shifting impact load
• Unified OEM installation dimensions, no structural modification required during gearbox assembly replacement
• Optimized stamped steel retainer reduces rotation resistance, adapts to long-term frequent forward-lock & reverse-free rotation working cycle
• Standard P0 precision grade, P6 upgraded precision and customized clearance can meet various OEM assembly matching demands
• Stable mass production with sufficient spot stock, high cost performance for aftermarket repair and bulk OEM supporting orders

Asian passenger car automatic transmission shift control one-way clutch, vehicle transmission overrunning assembly, light commercial vehicle transmission torque limit parts, construction and agricultural machinery unidirectional power transmission components.

Dimension drawings and full technical spec sheets available on request.

25+ years professional manufacturer of non-standard auto transmission one way bearings. All finished bearings pass cycle lock-overrun test, impact torque test and long-term durability aging test before delivery. Custom anti-rust coating and high-temperature anti-wear gear grease filling service supported. One-on-one professional transmission installation guidance and fast formal quotation for all RFQs. Stable bulk supply capacity, factory direct selling price, consistent stable quality and punctual batch delivery.

• Raw GCr15 steel hardness & chemical composition incoming inspection
• Wedge raceway superfinishing roughness detection
• High-temperature gear oil circulation aging durability test
• Continuous lock-overrun cycle fatigue test
• Full dimension tolerance sorting inspection
• 100% visual appearance marking check before packaging
• Random torque performance sampling test before shipment

All X-135006 bearings pass multi-step strict factory inspection.

Inquire bulk X-135006 transmission one way clutch bearings to get full support:

1. Complete formal detailed quotation within 24 hours
2. Standard dimension drawings & shaft press-fit installation guide
3. Custom anti-rust surface treatment & dedicated high-temperature gear lubricant filling service
4. Exclusive long-term factory wholesale price without intermediate markup

Large-volume OEM cooperation is warmly welcomed.

Q1: Working principle of one way clutch bearing X-135006?
A1: Wedge structure locks inner and outer ring to transmit torque in one direction; wedge releases to allow free overrunning in reverse rotation.

Q2: Difference between open one way bearing and sealed bearings?
A2: Open bearing installed inside gearbox with circulating gear oil lubrication; sealed one way bearings used for external independent mechanical equipment with pre-filled grease.

Q3: Can X-135006 replace original NSK bearing directly?
A3: Yes, overall installation dimension and internal wedge clutch structure fully consistent, no modification to gearbox parts needed during assembly.
