7311-B-MP Double Row Angular Contact Ball Bearings 55 KN Basic Static Load Rating
1. Angular Contact Ball Bearing Specification:
| Bearing model | 7311-B-MP |
| Material | Gcr15 |
| Type | Angular Contact Ball Bearing |
| Size (mm) | 55*120*29 |
| Basic dynamic load rating | 79.3 KN |
| Basic static load rating | 55 KN |
| Fatigue load limit | 2.3 KN |
| Mass (KG ) | 1.4 KG |
2. Application
used in many areas of large steel mills, papermaking and speed reducer,aviation,aerospace,marine,railway,metallurgy,steel, mining,electricity,machinery manufacturing,printing, electronics,textiles,food,chemical,automoti,spindle, internal combustion engines, generators, gas turbines, reducer11
3. Our products
| Bearing No. | d | D | B |
| 7000C | 10 | 26 | 8 |
| 7000AC | 10 | 26 | 8 |
| 7001C | 12 | 28 | 8 |
| 7001AC | 12 | 28 | 8 |
| 7002C | 15 | 32 | 9 |
| 7002AC | 15 | 32 | 9 |
| 7003C | 17 | 35 | 10 |
| 7003AC | 17 | 35 | 10 |
| 7004C | 20 | 42 | 12 |
| 7004AC | 20 | 42 | 12 |
| 7005C | 25 | 47 | 12 |
| 7005AC | 25 | 47 | 12 |
| 7006C | 30 | 55 | 13 |
| 7006AC | 30 | 55 | 13 |
| 7007C | 35 | 62 | 14 |
| 7007AC | 35 | 62 | 14 |
| 7008C | 40 | 68 | 15 |
| 7008AC | 40 | 68 | 15 |
| 7009C | 45 | 75 | 16 |
| 7009AC | 45 | 75 | 16 |
| 7010C | 50 | 80 | 16 |
| 7010AC | 50 | 80 | 16 |
| 7011C | 55 | 90 | 18 |
| 7011AC | 55 | 90 | 18 |
| 7012C | 60 | 95 | 18 |
| 7012AC | 60 | 95 | 18 |
| 7013C | 65 | 100 | 18 |
| 7013AC | 65 | 100 | 18 |
| 7014C | 70 | 110 | 20 |
| 7014AC | 70 | 110 | 20 |
