3204A-2RS1 Angular Contact Ball Bearing / Sealed Angular Contact Bearings

3204A-2RS1 Angular Contact Ball Bearing / Sealed Angular Contact Bearings

  • High Light

    Angular Contact Bearing

    ,

    Steel Cage Bearing

  • Bearing Model
    3204A-2RS1
  • Material
    Bearing Steel
  • Precision
    P0/P6/P5/P4/P2
  • Cage Stype
    Brass
  • Clearance
    C0 / C3/C4
  • Hardness
    60-65 HRC
  • Brand Name
    FAG / NTN / NSK
  • Model Number
    3204A-2RS1
  • Minimum Order Quantity
    1
  • Price
    1 USD
  • Packaging Details
    Single packing + standard export packing
  • Delivery Time
    5 working days
  • Payment Terms
    T/T, Western Union
  • Supply Ability
    10000 PCS / Month

3204A-2RS1 Angular Contact Ball Bearing / Sealed Angular Contact Bearings

3204A-2RS1 Angular Contact Ball Bearing / Sealed Angular Contact Bearings



1. Angular Contact Ball Bearing Specification:



Bearing model   3204A-2RS1
Material Gcr15
Type  Angular Contact Ball Bearing
Size (mm) 20*47*20.6
Basic dynamic load rating 20 KN
Basic static load rating 12 KN
Fatigue load limit 0.51 KN
Mass (KG )  0.16 KG



2. Application

used in many areas of large steel mills, papermaking and speed reducer,aviation,aerospace,marine,railway,metallurgy,steel, mining,electricity,machinery manufacturing,printing, electronics,textiles,food,chemical,automoti,spindle, internal combustion engines, generators, gas turbines, reducer11





3 . Competitive Advantage:

· More than 10 years of production experience

· China Leading bearing Technology

· Super High Quality

· Competitive Price

· Big Production Ability

· Fast Delivery

· Excellent Sale and After-sale Service

· OEM Available



4 .  Our products



Bearing No. d D B
7000C 10 26 8
7000AC 10 26 8
7001C 12 28 8
7001AC 12 28 8
7002C  15 32 9
7002AC 15 32 9
7003C 17 35 10
7003AC 17 35 10
7004C 20 42 12
7004AC 20 42 12
7005C 25 47 12
7005AC 25 47 12
7006C 30 55 13
7006AC 30 55 13
7007C 35 62 14
7007AC 35 62 14
7008C 40 68 15
7008AC 40 68 15
7009C 45 75 16
7009AC 45 75 16
7010C 50 80 16
7010AC 50 80 16
7011C 55 90 18
7011AC 55 90 18
7012C 60 95 18
7012AC 60 95 18
7013C 65 100 18
7013AC 65 100 18
7014C 70 110 20
7014AC 70 110 20
