Name: VU140325 ball bearing slewing ring Four Point Contact 270x380x35 mm
Brand: Optional
SKU: CSXU090-2RS
Rating: 4.6 (112 reviews)

Features Gallery Product Description Request A Quote

Features

Specifications

Size: 270x380x35 Mm

Stock: 280.pcs

Precision: P0 , P6, P5 ,P4 ,P2

Material: Bearing Steel ; Others

Operating Temp: -25°C ~ +120°C

Type: Four Point Contact Thin Section Ball

Highlight:

Slim Section Bearings

Thin Wall Ball Bearings

Basic Infomation

Place of Origin: Optional

Brand Name: Optional

Certification: ISO9001

Model Number: CSXU090-2RS

Payment & Shipping Terms

Packaging Details: Standard Carton Box / Wooden Pallet Case.

Delivery Time: Within 3 Working Days

Payment Terms: T/T, Western Union, Paypal

Gallery

VU140325 ball bearing slewing ring Four Point Contact 270x380x35 mm

Product Description

VU140325 ball bearing slewing ring Four Point Contact 270x380x35 mm

1.Type:Four Point Contact Slewing Bearing
2. Discription:
(1) seals on both sides
(2) Without gear teeth
3. Feature:
(1) High Precision:P0,P6,P5,P4 we can offer
(2) Quality Guarantee:1 years quality guarantee
(3) Prompty Delivery

VU140325 ball bearing slewing ring Four Point Contact 270x380x35 mm 0
Specification

Type	d	D	B	Size	Mass
Type	mm			Size	Kg
VLU200414	304	518	56	304x518x56 mm	23.5
VLU200514	434	648	56	434x648x56 mm	31
VLU200614	534	748	56	534x748x56 mm	36.5
VLU200714	634	848	56	634x848x56 mm	42.5
VLU200814	734	948	56	734x948x56 mm	48
VLU200914	834	1048	56	834x1048x56 mm	54
VLU201094	984	1198	56	984x1198x56 mm	62.5
VSU200414	342	486	56	342x486x56 mm	29
VSU200544	472	616	56	472x616x56 mm	37
VSU200644	572	716	56	572x716x56 mm	44
VSU200744	672	816	56	672x816x56 mm	52
VSU200844	772	916	56	772x916x56 mm	60
VSU200944	872	1016	56	872x1016x56 mm	67
VSU201094	1022	1166	56	1022x1166x56 mm	77
VSU250755	655	855	63	655x855x63 mm	90
VSU250855	755	955	63	755x955x63 mm	101
VSU250955	855	1055	63	855x1055x63 mm	115
VSU251055	955	1155	63	955x1155x63 mm	128
VU140179	124.5	234	35	124.5x234x35 mm	7
VU200220	138	302	46	138x302x46 mm	16
VU130225	200	290	24	200x290x24 mm	5.4
VU200260	191	329	46	191x329x46 mm	15
VU140325	270	380	35	270x380x35 mm	12
VU250380	275	485	55	275x485x55 mm	44
VU200405	336	474	46	336x474x46 mm	25
VU250433	344	522	55	344x522x55 mm	41
VU300574	468	680	68	468x680x68 mm	82
VU360680	565	795	79	565x795x79 mm	120
XSU080168	130	205	25.4	130x205x25.4 mm	3.3
XSU080188	150	225	25.4	150x225x25.4 mm	3.7
XSU080218	180	255	25.4	180x255x25.4 mm	4.3
XSU080258	220	295	25.4	220x295x25.4 mm	5.1
XSU080318	280	355	25.4	280x355x25.4 mm	6.3
XSU080390	360	435	25.4	360x435x25.4 mm	7.8
XU050077	40	112	22	40x112x22 mm	1.4
XU060094	57	140	26	57x140x26 mm	2.4
XU060111	76.2	145.79	15.87	76.2x145.79x15.87 mm	1.2
XU080120	69	170	30	69x170x30 mm	4
XU080149	101.6	196.85	22.22	101.6x196.85x22.22 mm	3.6
XU120179	124.5	234	35	124.5x234x35 mm	7
XU120222	140	300	36	140x300x36 mm	12
XU160260	191	329	46	191x329x46 mm	16
XU080264	215.9	311	25.4	215.9x311x25.4 mm	6.9
XU160405	336	474	46	336x474x46 mm	25
XU080430	380	480	26	380x480x26 mm	12
XU300515	384	646	86	384x646x86 mm	115
XV30	30	75	15	30x75x15 mm	0.37
XV40	40	85	15	40x85x15 mm	0.44
XV50	50	100	17	50x100x17 mm	0.67
XV60	60	110	17	60x110x17 mm	0.75
XV70	70	120	17	70x120x17 mm	0.84
XV80	80	135	19	80x135x19 mm	1.18
XV90	90	145	19	90x145x19 mm	1.29
XV100	100	170	23	100x170x23 mm	2.31
XV110	110	180	23	110x180x23 mm	2.48

VU140325 ball bearing slewing ring Four Point Contact 270x380x35 mm 1
