Slim Section Bearings Slewing Bearing with four point Four Point Contact

MOQ:	1.PCS
Standard Packaging:	Standard Carton Box / Wooden Pallet Case.
Delivery Period:	Within 3 Working Days
Payment Method:	T/T, Western Union, Paypal

Details Information

Product Description

Detail Information

Place of Origin

Optional

Brand Name

Optional

Certification

ISO9001

Model Number

1787/600G

Stock:

180.pcs

Precision:

P0 , P6, P5 ,P4 ,P2

Material:

Bearing Steel ; Others

Operating Temp:

-25°C ~ +120°C

Type:

Four Point Contact Thin Section Ball

SIZE:

786*600*72mm

Highlight:

Thin Wall Ball Bearings

Thin Section Ball Bearings

Product Description

Slim Section Bearings Slewing Bearing with four point Four Point Contact

Packaging & Delivery

Packaging Details:	Inner packing: Single boxes or Industrial Package Outer packing: Solid cartons / pallets
Delivery Detail:	within 2 weeks after deposit

Specifications

Slewing Bearing:
1) High quality and good service
2) Durable
3) ISO9001 certificate
4) OEM service is available

Slewing bearings is a kind of large-size bearing with special configuration which can bear axial load, radial load and tilting moment. Generally, a slewing bearing has mounting holes, lubricating holes and sealing system which can meet different needs of different machines under different working conditions.

Our slewing bearings include the following types:

4 point contact ball slewing bearing;

Double-row angular contact ball slewing bearing;

Crossed cylindrical roller slewing bearing;

Three-row cylindrical roller slewing bearing;

Ball and cylindrical roller combined slewing bearing.

These bearings can be divided with no-gear, external gear and internal gear.

Application: widely used in industries such as metallurgy,vessel oil,chemistry,mine coat,hydroelectric power,port machinery,heavy machinery and so on.

Bearing No.	Boundary Dimension			Mounting hold size						Gear Data					Basic Load Rating	Mass
Bearing No.	D	d	H	D1	D2	n1	n2	φ1	φ2	m	Da	Z	b	x	Coa	Kg
D178794	694	470	77	630	500	18	18	M16	18	6	696	114	60	0	157	93.1
1787/600G	786	600	72	740	636	20	24	M18*2.5	19	6	789	131	50	0	107	94.1
1787/674G2	853	674	70	825	709	34	23	20	M20	7	889	125	50	0	183	89
1787/674G2K	853	674	70	825	709	34	24	18	18	7	889	125	50	0	179	88.6
1787/710G2	894	710	67	845	744	8	8	M10	M10	6	924	152	55	0	179	107
1787/710G2K	894	710	67	875	760	8	12	M12	M12	6	924	152	55	0	179	107
1787/710G2K1	894	710	67	865	744	20	20	13	13	6	924	152	55	0	215	107
1787/800G	4050	800	90	1012	838	30	30	20	20	6	1092	180	60	0	215	217
1787/800GK	4050	800	90	1012	838	30	30	20	20	6	1092	180	60	0	297	217
1787/1040G2	-	1040	80	1220	1080	30	30	M16	17.5	10	1314	125	70	0	501	251
1787/1060G	1335	1060	109	1295	1105	24	24	M20	22	10	1388	138	80	-1	463	407
1787/1075	1365	1075	120	1310	1130	36	36	26	26	8	1424	176	90	0	463	463
1787/1075K	1365	1075	130	1310	1130	36	36	24	24	10	1420	140	120	0	463	550
1787/1075G2	1365	1075	120	1310	1130	36	36	24	24	10	1425	138	90	1	463	463
1787/1075G2K	1365	1075	120	1310	1130	36	36	M24	26	8	1424	176	90	0	463	463
1787/1330G2	1475	1330	82.4	1510	1362	24	24	18.5	18.5	9	1584	174	70	0	353	280
1788/1410G2		1410	85	1590	1454	36	36	M16	17.5	10	1676	160	70	0	395	312
