C 6915 V CARB Toroidal Roller Bearing Full Complement 75x105x54mm

1. Product Overview

C6915V is CARB self-aligning full complement cylindrical roller bearing, also known as ring roller bearing. Suffix V stands for cage-free full roller construction. Standard metric dimensions: inner bore d=75mm, outer diameter D=100mm, overall width B=60mm.

It adopts exclusive curved roller plus symmetrical arc raceway self-align design, which can simultaneously compensate shaft bending deformation, assembly parallel offset and axial thermal expansion. It effectively eliminates roller edge stress, abnormal noise and premature seizure caused by installation errors and temperature fluctuation. The full roller layout maximizes the number of rolling elements inside the bearing, delivering far stronger radial load capacity than caged cylindrical roller bearings, perfectly suited for continuous low-speed heavy-load working conditions.

Inner ring, outer ring and cylindrical rollers are all made of fully quenched GCr15 bearing steel with ultra-precision mirror grinding curved raceway, featuring stable rolling performance and outstanding wear resistance. Widely applied to printing press main rollers, heavy bulk material conveyor rollers, papermaking calender rollers, textile heavy calendaring equipment, light lifting and construction heavy transmission machinery.

2. Technical Specifications

Model: C6915V
Boundary dimensions: d=75mm, D=100mm, B=60mm
Minimum fillet radius r1=r2=1.1mm
Structure: CARB self-align full complement cylindrical roller bearing, cage-free full roller design
Raw material: GCr15 high carbon chromium bearing steel for all rolling components
Basic dynamic radial load Cr: 305kN
Basic static radial load C0r: 468kN
Fatigue limit load Pu: 49.8kN
Grease limited rotating speed: 1400 r/min
Single piece net weight: 1.85kg
Mounting shoulder reference: da min=79.8mm, da max=83mm, Da max=95.2mm
Operating temperature range: -30℃ ~ 120℃
Custom pre-filled high/low temperature grease, complete installation drawings and long-cycle heavy load durability test reports are available upon customer request.

3. Core Advantages

• Unique CARB curved roller self-aligning mechanism, three-dimensional compensation for shaft deflection, mounting offset and thermal axial elongation, preventing local edge abrasion and roller jamming.
• Cage-free full complement roller structure, fills maximum quantity of rollers inside bearing cavity, ultra-high radial rigidity and heavy load bearing capacity, ideal for equipment running under long-term sustained heavy load.
• All rolling parts adopt integral quenching and mirror superfinishing process, high surface hardness, stable precision retention during long-time low-speed heavy rotation, greatly extending service life.
• Symmetrical arc inner & outer raceway, evenly distributed contact stress on each roller, smooth stable rotation with low noise even with slight assembly misalignment.
• Wide compact integrated bearing design, single bearing replaces combined cylindrical + spherical roller bearing sets, simplifying shaft structure and reducing equipment assembly cost.
• Large internal grease storage cavity, stores sufficient lubricating grease to extend refueling maintenance cycle, suitable for low-maintenance industrial workshop environments.
• Standard metric universal installation dimensions, fully interchangeable with international standard CARB series bearings, no modification required for shafts and housings.
• Comprehensive customized services: stainless steel anti-rust material, OEM laser marking on outer ring, neutral export carton anti-rust packaging, special grease filling for extreme temperature conditions.

4. Application Scenarios

C6915V CARB full roller self-align bearing is core heavy-load deviation compensation transmission spare part for industrial heavy machinery:

• Large printing machine main pressure roller, heavy paper feeding tension roller support bearing assemblies
• Heavy bulk material conveyor drive roller, roller kiln transport roller rotary support positions
• Papermaking machinery calender roller, wet paper press heavy load rotary transmission structures
• Textile heavy fabric calender, non-woven production line large transmission roller bearings
• Light lifting machines, small construction heavy roller drive assemblies

Interchangeable aftermarket 75mm bore CARB series self-align full roller bearing
Cost-effective multi-direction misalignment compensation heavy radial load bearing solution for printing OEM, papermaking, textile and heavy conveyor equipment bulk procurement.

5. Why Choose GQZ Bearing

25 years professional manufacturing experience of full CARB self-align ring roller bearings including C6915V
C6915V fully dimensionally interchangeable with global standard CARB bearings, consistent self-compensation range, load rating and assembly tolerance standards.
Complete OEM & ODM customization service supporting stainless steel anti-corrosion material, special high/low temperature grease filling and custom surface marking.
Strict full pre-delivery inspection flow: GCr15 raw material hardness test, roller dimensional sorting screening, long-cycle heavy load rotation aging test, repeated misalignment fatigue wear test.
Professional CARB bearing engineering team provides one-on-one shaft deflection matching, lubricant selection and installation technical guidance within 24 working hours.
Stable mass production workshop with competitive factory bulk wholesale price for long-term printing, papermaking, textile and heavy conveyor machinery manufacturers.
We specialize in CARB curved roller self-compensation structure, full roller heavy-load layout, universal compact mounting design and long-term win-win cooperation with global industrial heavy transmission spare parts buyers.

6. Quality Control

• Raw material chemical composition and hardness inspection for GCr15 bearing steel inner ring, outer ring and roller blanks
• Precision forging, quenching & tempering, ultra-mirror curved raceway finish grinding processing for bearing rings
• Cylindrical roller high-temperature quenching, superfinishing and automatic dimensional sorting production line
• Cage-free full roller assembly process, strictly control internal roller clearance and assembly preload
• Targeted classified performance testing: C6915V long-cycle heavy radial load aging test, repeated misalignment compensation fatigue test, thermal expansion deformation wear detection
• Full dimensional tolerance and surface defect recheck before anti-rust oil coating and export carton packaging shipment

Every production batch of C6915V bearings undergoes full sampling heavy-load rotation test to ensure stable long-term self-align heavy-load support performance in printing, papermaking, textile and heavy conveyor industrial equipment.

7. Get A Quote Now

If you need C6915V CARB self-align full complement cylindrical roller bearings for printing presses, papermaking calenders, textile heavy machinery and heavy conveyor equipment maintenance & OEM bulk matching, send your purchase inquiry directly.
You will receive full professional supporting services after submitting inquiry:
Fast official factory formal quotation reply within 24 hours
One-on-one misalignment matching, grease grade selection and shaft housing installation technical guidance from professional CARB series bearing engineers
Customized bearing performance solutions including high-temperature resistant grease and stainless steel upgrade options
Competitive direct factory bulk wholesale price for large-volume spare parts orders
Provide your required purchase quantity, equipment heavy load condition and operating temperature environment to obtain detailed sealed formal quotation document.

8. FAQ

Q1: What does suffix V of C6915V represent?
A1: V means cage-free full complement roller structure, maximizes roller quantity to achieve ultra-heavy radial load carrying capacity.
Q2: What core advantage does CARB bearing have compared with ordinary cylindrical roller bearings?
A2: Unique curved roller self-align structure can compensate shaft bending, parallel offset and thermal expansion at the same time, avoiding edge pressure abrasion and bearing seizure.
Q3: What equipment is C6915V widely applied to?
A3: Mainly matched with printing press rollers, papermaking calender rollers, textile heavy calender and heavy industrial conveyor roller transmission components.
