SER 204 204-12 Spherical Radial Ball Super Precision Bearings 12 - 150 Mm

SER 204 204-12 Spherical Radial Ball Super Precision Bearings 12 - 150 Mm
SER 204 204-12 Spherical Radial Ball Super Precision Bearings 12 - 150 Mm

Large Image :  SER 204 204-12 Spherical Radial Ball Super Precision Bearings 12 - 150 Mm Get Best Price

Product Details:
Place of Origin: CHINA
Brand Name: OEM
Certification: ISO9000:2000
Model Number: SER 204 204-12
Payment & Shipping Terms:
Minimum Order Quantity: 10 PIECES
Packaging Details: cartons, plywood case
Payment Terms: Western Union, MoneyGram, T/T,
Detailed Product Description
Bore Size:: 12 - 150 Mm Vibration:: V1,V2,V3,V4
Clearance:: C2,C0,C3,C4,C5 Package:: Cartons, Plywood Case
High Light:

high precision bearings

,

precision spindle bearings







Item: SER 204 204-12 spherical radial ball bearing
Size: 12-200mm
Material chrome steel,bearing steel
Series: SER etc.
Hardness HRC58-62
Precision P2 P4 P5 P6 P0
Clearance C2 C3 C4 C5
Certificate ISO9001:2008
Production capacity 200000 pieces/Week
Quality We have complete process for the production and quality assurance to make sure our products can meet your requirement.
1.Assembly
2.Windage test
3.Cleaning
4.Rotary test
5.Greasing and gland
6.Noise inspection
7.Appearance inspection
8.Rust prevention
9.Product packaging
Brand: MBY or OEM
Material: chrome steel/stainless steel/bearing steel/carbon steel/plastic/ceramic
Application: oil industry, Mine, Paper-making, reduction gear, railway, vehicle, rolling mill
Packing

A:Polybag+single box+Carton

B:Polybag+Box+wooden case

C.As your requiremnt

Delivery time usually within 3-15 working days after payment
Payment Term L/C,T/T, paypal, western union

SER 204 204-12 Spherical Radial Ball Super Precision Bearings 12 - 150 Mm 0

SER 204 204-12 Spherical Radial Ball Super Precision Bearings 12 - 150 Mm 1

Specification of SER 204 204-12 spherical radial ball bearing



Bearing No. Bore Dia Diamension(mm)/(in.) Basic Load Rating (N) Weight(kg)
d D B C S a b p G h ds Dynamic Cr Static Cor
(in.) (mm)
SER202   15 47 31 15.9 10.3 2.38 1.07 52.7 4.7 4.4 M6X1 12800 6650 0.24
SER202-10 5/8 15.876 47 31 15.9 10.3 2.38 1.07 52.7 4.7 4.4 1/4-28UNF 12800 6650 0.24
SER203   17 47 31 15.9 10.3 2.38 1.07 52.7 4.7 4.4 M6X1 12800 6650 0.24
SER203-11 11/16 17.4625 47 31 15.9 10.3 2.38 1.07 52.7 4.7 4.4 1/4-28UNF 12800 6650 0.24
SER204-12 3/4 19.05 47 31 15.9 10.3 2.38 1.07 52.7 4.7 4.4 1/4-28UNF 12800 6650 0.24
SER204   20 47 31 15.9 10.3 2.38 1.07 52.7 4.7 4.4 M6X1 12800 6650 0.24
SER205-14 7/8 22.225 52 34.9 19 13.1 2.38 1.07 57.9 5.5 4.5 1/4-28UNF 14000 7880 0.27
SER205-15 15/16 23.8125 52 34.9 19 13.1 2.38 1.07 57.9 5.5 4.5 1/4-28UNF 14000 7880 0.27
SER205   25 52 34.9 19 13.1 2.38 1.07 57.9 5.5 4.5 M6X1 14000 7880 0.27
SER205-16 1 25.4 52 34.9 19 13.1 2.38 1.07 57.9 5.5 4.5 1/4-28UNF 14000 7880 0.27
SER206-18 1-1/8 28.575 62 38.1 22.2 15.9 3.18 1.65 67.7 5.5 5.3 1/4-28UNF 19500 11200 0.39
SER206   30 62 38.1 22.2 15.9 3.18 1.65 67.7 5.5 5.3 M6X1 19500 11200 0.39
SER206-19 1-3/16 30.1625 62 38.1 22.2 15.9 3.18 1.65 67.7 5.5 5.3 1/4-28UNF 19500 11200 0.39
SER206-20 1-1/4 31.75 62 38.1 22.2 15.9 3.18 1.65 67.7 5.5 5.3 1/4-28UNF 19500 11200 0.39
SER207-20 1-1/4 31.75 72 42.9 23.8 17.5 3.18 1.65 78.6 6.5 5.8 5/16-24UNF 25700 15200 0.61
SER207-21 1-5/16 33.3375 72 42.9 23.8 17.5 3.18 1.65 78.6 6.5 5.8 5/16-24UNF 25700 15200 0.61
SER207-22 1-3/8 34.925 72 42.9 23.8 17.5 3.18 1.65 78.6 6.5 5.8 5/16-24UNF 25700 15200 0.61
SER207   35 72 42.9 23.8 17.5 3.18 1.65 78.6 6.5 5.8 M8X1 25700 15200 0.61
SER207-23 1-7/16 36.5125 72 42.9 23.8 17.5 3.18 1.65 78.6 6.5 5.8 5/16-24UNF 25700 15200 0.61
SER208-24 1-1/2 38.1 80 49.2 27.8 19 3.18 1.65 86.6 8 6.3 5/16-24UNF 29600 18200 0.81
SER208-25 1-9/16 39.6875 80 49.2 27.8 19 3.18 1.65 86.6 8 6.3 5/16-24UNF 29600 18200 0.81
SER208   40 80 49.2 27.8 19 3.18 1.65 86.6 8 6.3 M8X1 29600 18200 0.81
SER209-26 1-5/8 41.275 85 49.2 27.8 19 3.18 1.65 91.6 8 7.5 5/16-24UNF 31850 20800 0.9
SER209-27 1-11/16 42.8625 85 49.2 27.8 19 3.18 1.65 91.6 8 7.5 5/16-24UNF 31850 20800 0.9
SER209-28 1-3/4 44.45 85 49.2 27.8 19 3.18 1.65 91.6 8 7.5 5/16-24UNF 31850 20800 0.9
SER209   45 85 49.2 27.8 19 3.18 1.65 91.6 8 7.5 M8X1 31850 20800 0.9
SER210-30 1-7/8 47.625 90 51.6 28.6 19 3.18 2.41 96.5 9 6.8 3/8-24UNF 35100 23200 0.96
SER210-31 1-15/16 49.2125 90 51.6 28.6 19 3.18 2.41 96.5 9 6.8 3/8-24UNF 35100 23200 0.96
SER210   50 90 51.6 28.6 19 3.18 2.41 96.5 9 6.8 M10X1.25 35100 23200 0.96
SER211-32 2 50.8 100 55.6 30.2 22.2 3.18 2.41 106.5 9 7.6 3/8-24UNF 43550 29200 1.41
SER211-34 2-1/8 63.5 100 55.6 30.2 22.2 3.18 2.41 106.5 9 7.6 3/8-24UNF 43550 29200 1.41
SER211   55 100 55.6 30.2 22.2 3.18 2.41 106.5 9 7.6 M10X1.25 43550 29200 1.41
SER211-35 2-3/16 55.5825 100 55.6 30.2 22.2 3.18 2.41 106.5 9 7.6 3/8-24UNF 43550 29200 1.41
SER212-36 2-1/4 57.15 110 65.1 31.8 25.4 3.18 2.41 116.6 10.5 8.4 3/8-24UNF 47800 32800 1.95
SER212   60 110 65.1 31.8 25.4 3.18 2.41 116.6 10.5 8.4 M10X1.25 47800 32800 1.95
SER212-38 2-3/8 60.325 110 65.1 31.8 25.4 3.18 2.41 116.6 10.5 8.4 3/8-24UNF 47800 32800 1.95
SER212-39 2-7/16 61.9125 110 65.1 31.8 25.4 3.18 2.41 116.6 10.5 8.4 3/8-24UNF 47800 32800 1.95
SER214-40 2-1/2 63.3 125 74.6 35 30.2 3.96 2.77 134.7 12 9 7/16-20UNF 60800 45000 2.52
SER214-43 2-11/16 68.2625 125 74.6 35 30.2 3.96 2.77 134.7 12 9 7/16-20UNF 60800 45000 2.52
SER214   70 125 74.6 35 30.2 3.96 2.77 134.7 12 9 M12X1.25 60800 45000 2.52
SER215-46 2-7/8 73.025 130 77.8 38.1 33.3 3.96 2.77 139.7 12 9.5 7/16-20UNF 66000 49500 2.89
SER215-47 2-15/16 74.6125 130 77.8 38.1 33.3 3.96 2.77 139.7 12 9.5 7/16-20UNF 66000 49500 2.89
SER215   75 130 77.8 38.1 33.3 3.96 2.77 139.7 12 9.5 M12X1.25 66000 49500 2.89
SER201   12 47 31 15.9 10.3 2.38 1.07 52.7 4.7 4.4 M6X1 12800 6650 0.24
SER201-8 1/2 12.7 47 31 15.9 10.3 2.38 1.07 52.7 4.7 4.4 1/4-28UNF 12800 6650 0.24
