Excavator Tapered Roller Bearing R196Z -4 R196Z -4SA 196.85x241.3x23.812mm

1. Product Overview

1.Product Overview
R196Z-4 and R196Z-4SA are inch standard single row separable tapered roller bearings, widely matched for excavator final drive travel mechanisms, construction machinery differential and heavy agricultural equipment. Unified core mounting dimension: bore d=196.85mm, outer diameter D=241.3mm, overall assembly width T=23.812mm, interchangeable installation space for both versions.

Suffix technical difference explanation:

• R196Z-4: Standard base model, open type steel stamping cage, conventional raceway heat treatment, cost-effective for general heavy-load normal temperature working conditions;
• R196Z-4SA: Upgraded reinforced SA grade variant, optimized logarithmic roller contact curve, strengthened inner/outer ring surface quenching treatment, improved wear resistance, anti-vibration and high-temperature tolerance, lower running noise, longer service life under continuous heavy impact load.

Fully separable split structure: cone assembly (inner ring + tapered rollers + cage) and outer cup can be disassembled separately, greatly simplifying on-site installation, disassembly and maintenance of excavator travel reduction boxes. All rings and rolling elements adopt integral quenched GCr15 high-carbon chrome bearing steel, high hardness, strong impact resistance and wear resistance, stable bearing performance under alternating radial and axial combined load.

2. Technical Specifications

Unified Universal Base Parameters

Inner bore d: 196.85 mm
Outer diameter D: 241.3 mm
Total assembly width T: 23.812 mm
Inner ring width B: 23.017 mm
Outer ring width C: 17.462 mm
Fillet radius r: 2.1 mm
Structure: Single row separable tapered roller bearing, open without seal
Raw material: GCr15 bearing steel
Standard clearance: C0 normal clearance, C3 enlarged clearance customizable
Precision grade optional: P0 / P6 / P5
Working temperature range: -30℃ ~ 110℃ (R196Z-4SA up to 130℃)
Net weight: 2.107 kg

R196Z-4 Standard Version

Basic dynamic load rating Cr: 312 kN
Basic static load rating C0r: 408 kN
Grease limited rotating speed: 2850 r/min
Core feature: Standard heat treatment, cost control, suitable for intermittent heavy load construction equipment

R196Z-4SA SA Upgraded Version

Basic dynamic load rating Cr: 336 kN
Basic static load rating C0r: 435 kN
Grease limited rotating speed: 3100 r/min
Core feature: SA reinforced surface treatment, optimized roller contact, anti-wear, high temperature resistant, low noise, for 24h continuous heavy impact excavator final drive
Complete installation drawings, load characteristic curves and accelerated wear fatigue test reports can be provided upon customer request.
