HK 2820 28x35x20 mm Drawn Cup Needle Roller Bearing High Precision HK2820
Specifications of needle roller bearing HK2820
| Shaft Diameter(mm) | 28 |
| Bearing Designation | HK2820 |
| Mass Approx(g) | 14.8 |
| Fw(mm) | 28 |
| D(mm) | 35 |
| C(mm) | 20 |
| Cr Dynamic(N) | 196 |
| Cor Static(N) | 446 |
| Oil(rpm) | 13500 |
Physical Characteristic of needle roller bearing HK2820
| 1) needle bearing can be separated by single row. | |
| 2) This kind of bearing can be submitted to high radial load and some axial load. | |
|
3) The rolling element of needle roller bearing is needle,the two ends of the external lines have the corrective slope which can eliminate the contact stress. |
|
|
4) Moreover, we can manufacture these bearings according to customer's drawings and samples |
needle roller bearing HK2820
Applications:
- Transmissions,transfer cases,engines & valve trains needle roller bearing HK2820
-Steering and braking systems needle roller bearing HK2820
- Axle support
-Outboard engines needle roller bearing HK2820
| Bearing Classification | Bearing No. Size | Range | |
| Drawn Cup Needle Roller Bearings | Caged Type | HK BK HK..RS HK..2RS BK..RS | ID4-50mm |
| One Way Type | HF HFL | ID4-35mm | |
| Full Complement Type | FFH MF MFH FY MFY | ID6-60mm | |
| Radial Needle and Cage Assemblies | Single & double row type | K/KS KK/KKS KZK KBK | ID5-110mm |
| Long cylindrical roller Type | KNL | ID19.051-74mm | |
| Needle Roller Bearings | With Ribs | NK NKS RNA49 RNA48 | ID5-160mm |
| NKI NKIS NA49 NA48 | ID8-140mm | ||
| RNA69 NA69 | ID5-140mm | ||
| RNA49..RS RNA49..2RS NA49..RS NA49..2RS | ID5-140mm | ||
| Without Ribs | RNAO NAO | ID5-100mm | |
| Aligning | RPNA PNA | ID15-45mm | |
| Full Complement | RNAV NAV | ID15-04.8mm | |
| Yoke Type Track Rollers | Without Axial Guidance | RSTO RSTO..X STO STO..X RNA22..2RS RNA22..2RSX NA22..2RS NA22..2RSX | ID5-50mm |
| With Axial Guidance | NATR NATR..PP NATV NATV..PP NUTR NUTR..X | ID5-50mm | |
| Stud Type Track Rollers | With Axial Guidance | KR KRE KR..PP KRE..PP | ID6-30mm |
| KRV KRVE KRV..PP KRVE..PP | ID6-30mm | ||
| NUKR NUKRE | ID16-30mm | ||
| Combined Radial Axial Bearings | Needle Roller Arugula Contact Ball Bearing | NKIA | ID12-70mm |
| NKIB | ID12-70mm | ||
| Needle Roller Axial Cylindrical Roller Bearing | ZARN | ID15-50mm | |
| ZARN..L | ID15-50mm | ||
| NARF | ID15-50mm | ||
| NARF..L | ID15-50mm | ||
| NKXR | ID15-50mm | ||
| NKXR..Z | ID15-50mm | ||
| Needle Roller Axial Ball Bearing | NX NX..Z | ID7-35mm | |
| NKX NKX..Z | ID7-35mm | ||
| Inner Ring | IR LR | ID5-160mm | |
| Axial Bearings | Axial Needle Roller And Cage Assembly | AXK AXW | ID4-160mm |
| Axial Bearings | Axial Cylindrical Roller And Cage Assembly | K811 K812 K893 K874 K894 | ID15-160mm |
| Axial Bearing Washers | Shaft Locating Washers | AS WS811 | ID4-160mm |
| Housing Locating | Washers GS811 | ID15-160mm | |
| Bearing Washers | LS | ID6-160mm | |
| Center Washers | ZS | ||
