80x160x45mm X-Life Taper Precision Roller Bearing T7FC080-XL T7FC 080/QCL7C

1.Product Overview

1.Product Overview
T7FC080-XL and T7FC080/QCL7C belong to ISO355 standard T7FC series single row separable tapered roller bearing, unified core dimension inner bore d=80mm, outer diameter D=160mm, total assembly width T=45mm, inner ring width B=41mm, outer ring width C=31mm, built-in 30° large contact angle design for strong axial bearing capacity迈埃肯(上....
Suffix technical differentiation explanation:

• XL: X-life premium upgraded version, ultra-precision mirror superfinished raceway, strictly classified uniform tapered rollers, optimized internal contact geometry and dedicated stress relief heat treatment, 70% longer service life than standard models, specially matched for 24-hour non-stop continuous heavy-duty production linesschaeffler...;
• QCL7C: Explorer high-performance grade, Q optimized logarithmic contact curve + CL7C special surface strengthening treatment, ultra-low friction torque, stable low-temperature rise and low-noise rotation, stronger anti-vibration performance under alternating shock load, ideal for high-precision heavy transmission gearboxes.

Full separable split construction: the integrated assembly of inner ring, tapered rollers and cage can be fully detached from outer ring, greatly simplifying shaft installation, disassembly and field maintenance. All rings and tapered rollers adopt integral quenched GCr15 high-carbon chrome bearing steel, high hardness, excellent wear resistance and impact resistance. Widely matched for heavy industrial gear reducers, construction machinery drive axles, metallurgical auxiliary transmission shafts, mining conveyor equipment and wind power auxiliary speed reduction boxes.

2.Technical Specifications

Unified Base Standard Parameters

• Inner bore d: 80 mm
• Outer diameter D: 160 mm
• Inner ring width B: 41 mm
• Outer ring width C: 31 mm
• Total assembly width T: 45 mm
• Contact angle: 30° large axial thrust angle
• Structure: Single row separable tapered roller bearing, open non-seal type
• Rolling element & ring material: GCr15 bearing steel
• Cage: Stamped low carbon steel cage, solid brass cage optional
• Standard radial clearance: CN normal clearance, C3 enlarged clearance customizable
• Operating temperature range: -30℃ ~ 120℃
• Net weight: 3.95 kg
• Minimum fillet radius r=3mm
• Calculation coefficient e=0.88, axial factor Y=0.68, static axial factor Y0=0.40迈埃肯(上...

T7FC080-XL

• Basic dynamic radial load Cr: 260 kN
• Basic static radial load C0r: 315 kN
• Fatigue limit load Cur: 42 kN
• Grease limiting rotation speed: 4600 r/min
• Thermal reference continuous operating speed: 3400 r/min
• Core feature: X-life anti-fatigue upgrade, long service life for uninterrupted heavy cycle operation

T7FC080/QCL7C

• Basic dynamic radial load Cr: 229 kN
• Basic static radial load C0r: 315 kN
• Fatigue limit load Cur: 35.5 kN
• Grease limiting rotation speed: 4000 r/min
• Thermal reference continuous operating speed: 2800 r/min
• Core feature: Q optimized contact + CL7C surface treatment, ultra-low friction, low noise high precision rotation

Complete installation dimension drawings, load characteristic curves and differentiated grade fatigue cycle test reports can be provided upon customer request.

3.Key Advantages

1. Two high-performance interchangeable versions with identical installation outline sizes, customers can freely select according to equipment continuous operation cycle and precision speed requirements
2. 30° large contact angle tapered roller layout, outstanding comprehensive bearing capacity to withstand heavy combined radial load + unidirectional large axial thrust load, stable low-vibration operation under frequent forward/reverse impact loads
3. Fully separable split construction, inner roller-cage assembly detached from outer ring, easy mounting and removal on heavy-duty shafts without scratching bearing race surfaces during assembly and maintenance
4. Exclusive differentiated technical upgrades: XL version enhances fatigue resistance for long-cycle uninterrupted equipment; QCL7C optimizes contact friction to reduce heat generation and running noise for high-precision transmission systems
5. Dual cage selections: stamped steel cage cost-effective for general heavy load scenarios; brass cage anti-deformation for long-time high-temperature continuous production lines
6. Customizable options: C3 enlarged radial clearance, P5 high precision grade, OEM laser marking, special high-temperature anti-oxidation grease filling

Effectively extend overhaul intervals of heavy gearbox, construction and metallurgical transmission equipment, cutting production downtime maintenance losses

4.Applications

This T7FC080 dual-model high-performance tapered roller bearing set serves as core replacement wear part for heavy industrial rotary equipment:

• Heavy-duty industrial gear reducers, mining belt conveyor head transmission shaft supporting assemblies
• Large loader, road roller, excavator heavy drive axle positioning bearing units
• Metallurgical rolling mill auxiliary transmission shafts, steel plant heavy transport roller spare parts
• Small wind power auxiliary speed reduction box, port lifting machinery rotary positioning components
• Heavy agricultural harvester, large industrial mixer main drive system wear spare parts
• Aftermarket interchangeable 80mm bore high-performance single row tapered roller bearing
• Dual-grade cost-effective heavy-load separable tapered bearing solution for long-cycle or high-precision industrial equipment maintenance

5.Why Choose GQZ Bearing

• 25 years of professional manufacturing experience for T7FC series X-life & QCL7C high-performance tapered roller bearings
• T7FC080-XL & T7FC080/QCL7C fully dimensionally interchangeable with international standard T7FC series bearings, consistent installation size and assembly tolerance indicators
• Complete OEM & ODM customization service supporting brass cage, C3 clearance upgrade, high precision grade and special high/low temperature lubricant customization
• Strict full-process pre-delivery inspection: raw material hardness testing, cone raceway grinding precision detection, differentiated grade heavy load reciprocating fatigue cycle testing
• Professional tapered bearing engineering team provides heavy shaft and housing tolerance matching installation guidance within 24 hours
• Stable mass production lines with favorable bulk wholesale prices for long-term gearbox, construction and metallurgy machinery manufacturers
• We focus on dual differentiated high-performance design, heavy radial-axial load bearing capacity, separable easy-maintenance structure and long-term win-win cooperation with global industrial equipment spare parts buyers

6.Quality Control

• Raw material chemical composition and surface hardness inspection of GCr15 chrome bearing steel
• Precision turning, quenching & tempering, mirror superfinishing processing for inner and outer ring cone raceways
• Differentiated targeted heat treatment: XL version X-life stress relief strengthening process; QCL7C exclusive CL7C surface optimized strengthening treatment
• Classified performance testing: T7FC080-XL long-cycle accelerated fatigue aging test; T7FC080/QCL7C high-speed low friction torque temperature rise test
• Tapered roller classification, steel/brass cage assembly, full dimensional and appearance re-inspection before anti-rust oil packaging and shipment
• Each batch of T7FC080 series bearings undergoes full sampling heavy-load reciprocating rotation fatigue testing to ensure stable long-term operation inside heavy industrial transmission equipment

7.Get a Quote Now

If you need dual high-performance T7FC080-XL long-life and T7FC080/QCL7C low-friction tapered roller bearings for heavy gearbox, construction and metallurgical non-stop equipment maintenance, send your inquiry to us directly.
You will receive complete professional supporting services after submitting your inquiry:

• Fast official factory quotation reply within 24 hours
• One-on-one technical guidance on heavy shaft & housing matching tolerance installation from professional high-performance tapered bearing engineers
• Customized bearing scheme suggestions including brass cage and C3 enlarged clearance upgrade options
• Competitive direct factory bulk wholesale price for mixed two-model bulk orders of heavy machinery spare parts
• Send your required purchase quantity of each model and equipment continuous operation speed & heavy-load working environment to get detailed formal quotation

8.FAQ

• Q1: What is the core difference between T7FC080-XL and T7FC080/QCL7C?
  A1: Same installation overall dimensions; T7FC080-XL is X-life anti-fatigue upgraded version, optimized raceway and roller matching for 24h uninterrupted heavy load production equipment with longer service life; T7FC080/QCL7C adopts Q logarithmic contact curve + CL7C surface treatment, ultra-low friction torque, low noise and low temperature rise, suitable for high-precision heavy transmission gearboxes.
• Q2: What loads can T7FC080 series bearings bear?
  A2: It bears heavy radial load plus unidirectional axial thrust load; bidirectional axial positioning requires two bearings installed back-to-back or face-to-face with reasonable preload.
• Q3: What is the advantage of separable tapered roller bearing structure?
  A3: The inner ring with roller and cage assembly can be separated from outer ring, convenient for assembly on heavy-duty shafts and prevents scratches on bearing raceways during installation and disassembly.
