1. cam follower needle roller bearing Specification :
| Bearing type | Needle Roller Bearing |
| Bearing Model | NATR5 |
| Brand | INA |
| Size (mm) | 5*16*12 |
| Weight (kg) | 0.014 KG |
| Stock | Enough |
| Lubrication | Oil,Grease |
| Application | Automobiles, Rolling Mill, Mining, Metallurgy |
2.Types of bearings:
Needle roller bearings have a high load carrying capacity in addition to their low cross-section and stiffness. They are
especially suitable for bearing arrangements where radial space is limited. Because needle roller bearings only carry
pure radial load and can not limit the axial displacement of shaft relative to the housing. It is important to ensure that inner
ring axis and outer ring axis must be aligned during mounting the bearings.
3. Features :
1.Chrome steel, GCr15 material
2.Steel cage,single row
3.Huge stocks,OEM service
4.ISO9001
4 . Competitive Advantage:
· Competitive Price
· Big Production Ability
· Fast Delivery
· Excellent Sale and After-sale Service
· OEM Available
5 . We have enough stock , following is our products in stock .
| diameter | Model | weight | Model | weight | dimension | ||||||
| d | D | B | C | d1 | |||||||
| mm | g | g | mm | ||||||||
| 5 | NATR5 | 14 | NATR5PP | 14 | 5 | 16 | 12 | 11 | 12 | ||
| NATV5 | 15 | NATV5PP | 15 | 5 | 16 | 12 | 11 | 12 | |||
| 6 | NATR6 | 20 | NATR6PP | 20 | 6 | 19 | 12 | 11 | 14 | ||
| NATV6 | 21 | NATV6PP | 21 | 6 | 19 | 12 | 11 | 14 | |||
| 8 | NATR8 | 41 | NATR8PP | 41 | 8 | 24 | 15 | 14 | 19 | ||
| NATV8 | 42 | NATV8PP | 42 | 8 | 24 | 15 | 14 | 19 | |||
| 10 | NATR10 | 64 | NATR10PP | 64 | 10 | 30 | 15 | 14 | 23 | ||
| NATV25 | 285 | NATV25PP | 285 | 25 | 52 | 25 | 24 | 42 | |||
| 30 | NATR30 | 470 | NATR30PP | 470 | 30 | 62 | 29 | 28 | 51 | ||
| NATV30 | 481 | NATV30PP | 481 | 30 | 62 | 29 | 28 | 51 | |||
| 35 | NATR35 | 635 | NATR35PP | 635 | 35 | 72 | 29 | 28 | 58 | ||
| NATV35 | 647 | NATV35PP | 647 | 35 | 72 | 29 | 28 | 58 | |||
| 40 | NATR40 | 805 | NATR40PP | 805 | 40 | 80 | 32 | 30 | 66 | ||
| NATV40 | 890 | NATV40PP | 890 | 40 | 80 | 32 | 30 | 66 | |||
| 45 | NATR45 | 910 | NATR45PP | 910 | 45 | 85 | 32 | 30 | 72 | ||
| NATV45 | 935 | NATV45PP | 935 | 45 | 85 | 32 | 30 | 72 | |||
| 50 | NATR50 | 960 | NATR50PP | 960 | 50 | 90 | 32 | 30 | 76 | ||
| NATV50 | 990 | NATV50PP | 990 | 50 | 90 | 32 | 30 | 76 | |||
