7203BECBP Precision Ball Bearings Size 17*40*12 P0 - P2 Skf

1
MOQ
1 USD
Price
7203BECBP Precision Ball Bearings Size 17*40*12 P0 - P2 Skf
Features Gallery Product Description Request A Quote
Features
Specifications
Bearing Type: Angular Contact Bearing
OD: 40 MM
Precsion Level: P0/P6/P5/P4/P2
ID: 17 Mm
Brand: SKF / GQZ / AAA
Material: GCr15
High Light:

Angular Contact Bearing

,

Steel Cage Bearing

Basic Infomation
Brand Name: SKF / GQZ / AAA
Certification: ISO 9001
Model Number: 7203BECBP
Payment & Shipping Terms
Packaging Details: single packing + standard export packing
Payment Terms: T/T, Western Union
Supply Ability: 1000 pcs / month
Product Description



7203BECBP Precision Ball Bearings Size 17*40*12 P0 - P2 Skf



1. Angular  Contact  Bearing  Specification :



Bearing type  Angular Contact Bearing
Bearing Model 7203BECBP
Brand SKF / GQZ / AAA
Size (mm) 17*40*12
Weight (kg) 0.064  KG
Stock  Enough
Lubrication Oil
Application Automobiles, Rolling Mill, Mining, Metallurgy



2.Destription :


Type A: outer diameter greater than the standard design of the 90 mm bearing.Side with ball gap, equipped with z steel plate stamping cage or entity brass cage.
E: reinforced structure, the side with the ball gap, can hold more ball, therefore higher bearing capacity.
Sides with dust cover and two sides with seals, type A and type E design of double row angular contact ball bearings can carry dust cover (non-contact) or sealing ring on both sides (contact).The interior of the sealed bearing have rust lithium grease filling, operating temperature generally between 30 degrees to 110 degrees.Don't need to use lubrication, no longer heating before installation.
Double row angular contact ball bearing should be paid attention to when installation, although the bearing can be subject to bi-directional load, but if one side has put the ball gap, should be paid attention to, don't let the noise of main axial load through a gap on the side of the river bank.





3 . Types :



The characteristics of double row angular contact ball bearing can be also bear the combined load of radial and axial load, limit shaft of both axial displacement.Compared with bidirectional thrust ball bearing, this kind of bearing limit rotational speed is higher, the contact Angle is 32 degrees, good rigidity, affordable overturn torque, widely used in the car of the front wheel hub (some models with same size also double row circular cone roller bearings).





4 . Competitive Advantage:


· Competitive Price
· Big Production Ability
· Fast Delivery
· Excellent Sale and After-sale Service
· OEM Available



5. APPLICATION:

Papermaking machinery, reducer, railway vehicle axle, gear box bearing, rolling mill rolling mill rolls, crusher, vibrating screen, printing machinery, woodworking machinery, all kinds of industrial reducer, Papermaking machinery, deceleration devices, railway vehicle axles, gear box bearing rolling mill, rolling mill rolls, crusher, vibrating screen, printing machinery, woodworking machinery, all kinds of industrial gear, vertical seat belt aligning bearings


6 . We have enough stock , following is our products in stock .


Designation Principal dimensions Basic load ratings Fatigue load limit Speed ratings Mass
        dynamic static Reference speed Limiting speed
  d D B C C0 Pu
- mm     kN   kN r/min   kg
7200BEP 10 30 9 7,02 3,35 0,14 30000 30000 0,03
7200BECBP 10 30 9 7,02 3,35 0,14 30000 30000 0,03
7201BEP 12 32 10 7,61 3,8 0,16 26000 26000 0,036
7201BECBP 12 32 10 7,61 3,8 0,16 26000 26000 0,036
7201BEGAP 12 32 10 7,61 3,8 0,16 26000 26000 0,036
7301BEP 12 37 12 10,6 5 0,208 24000 24000 0,063
7202BEP 15 35 11 8,84 4,8 0,204 24000 24000 0,045
7202BECBP 15 35 11 9,5 5,1 0,216 26000 26000 0,045
7202BEGAP 15 35 11 9,5 5,1 0,216 26000 26000 0,045
7202BEGBP 15 35 11 9,5 5,1 0,216 26000 26000 0,045
7302BEP 15 42 13 13 6,7 0,28 20000 20000 0,081
7302BECBP 15 42 13 13 6,7 0,28 20000 20000 0,081
7203BEP 17 40 12 10,4 5,5 0,236 20000 20000 0,064
7203BEY 17 40 12 11,1 6,1 0,26 20000 20000 0,064
7203BECBP 17 40 12 11 5,85 0,25 22000 22000 0,064
7203BEGAP 17 40 12 11 5,85 0,25 22000 22000 0,064
7203BECBM 17 40 12 11 5,85 0,25 22000 22000 0,07
7303BEP 17 47 14 15,9 8,3 0,355 19000 19000 0,11
7303BECBP 17 47 14 15,9 8,3 0,355 19000 19000 0,11
7303BEGAP 17 47 14 15,9 8,3 0,355 19000 19000 0,11
7204BEP 20 47 14 13,3 7,65 0,325 18000 18000 0,11
7204BECBM 20 47 14 13,3 7,65 0,325 18000 19000 0,11
7204BECBY 20 47 14 14 8,3 0,355 18000 18000 0,11
7204BECBP 20 47 14 14,3 8,15 0,345 19000 19000 0,11
7204BEGAP 20 47 14 14,3 8,15 0,345 19000 19000 0,11
7204BEGBP 20 47 14 14,3 8,15 0,345 19000 19000 0,11
7304BEP 20 52 15 17,4 9,5 0,4 16000 16000 0,14
7304BEY 20 52 15 19 10,4 0,44 16000 16000 0,15
7304BECBY 20 52 15 19 10,4 0,44 16000 16000 0,15
7304BECBP 20 52 15 19 10 0,425 18000 18000 0,14
7304BEGAP 20 52 15 19 10 0,425 18000 18000 0,14
7304BEGBP 20 52 15 19 10 0,425 18000 18000 0,14
7304BECBPH 20 52 15 19 10 0,425 18000 18000 0,14
7304BECBM 20 52 15 19 10 0,425 18000 18000 0,15
7205BEP 25 52 15 14,8 9,3 0,4 15000 15000 0,13
7205BEY 25 52 15 15,6 10,2 0,43 15000 15000 0,13
7205BECBY 25 52 15 15,6 10,2 0,43 15000 15000 0,13
7205BEGAY 25 52 15 15,6 10,2 0,43 15000 15000 0,13





7203BECBP Precision Ball Bearings Size 17*40*12 P0 - P2 Skf 0

7203BECBP Precision Ball Bearings Size 17*40*12 P0 - P2 Skf 1
