FC3856200 Cylindrical Roller Bearings four Row 190mm Bore 280mm OD 200mm Width

1 pcs
MOQ
negotiation
Price
FC3856200 Cylindrical Roller Bearings four Row 190mm Bore 280mm OD 200mm Width
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: FC3856200
Lubrication: Grease Lubrication
Cage: Brass,Steel Or Nylon
Vibration: V1 V2 V3 V4
High Light:

Cam Follower Bearing

,

axial thrust bearing

Basic Infomation
Place of Origin: China
Brand Name: OEM
Certification: ISO
Model Number: FC3856200
Payment & Shipping Terms
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 3 working days after received your payment
Payment Terms: T/T or western Union or PayPal
Supply Ability: 3,000pcs per month
Product Description



FC3856200 Cylindrical Roller Bearings four Row 190mm Bore 280mm OD 200mm Width



Cylindrical roller bearings introduction :



Cylindrical Roller Bearings are bearing in which cylinders are used as the rolling elements as opposed to balls in ball bearings. As such, the rollers have a greater (linear) contact area with the outer ring and are distribute loads across a broader surface. Subsequently, they have a relatively high radial load capacity and are suitable for high speeds. Double-row cylindrical roller bearings have high radial rigidity and are used primarily for precision machine tools.



There are different types designated NU, NJ, NUP, N, NF for single-row bearings, and NNU, NN for double-row bearings depending on the design or absence of side ribs. AST’s cylindrical roller bearings come in the following series with various cage designs and Metric dimensions:


Model Boundary Dimensions
Inside Diameter Outer Diameter Width Fw r 2max r 1max
FC182870 90 140 70 105 1.5 1.1
FC2028104 100 140 104 111 1.5 1.1
FC202970 100 145 70 113 1.5 1.1
FC2030106 100 150 106 113 1.5 1.1
FC2234120 110 170 120 127 2 2
FC2436105 120 180 105 135 2 2
FC2640125 130 200 125 149 2 2
FC2842125 140 210 125 158 2 2
FC2842155 140 210 155 158 2 2
FC2942155 145 210 155 166 2 2
FC2945156 145 225 156 169 2 2
FC3045120 150 225 120 169 2 2
FC3046156 150 230 156 174 2 2
FC3248168 160 240 168 183 2.1 2.1
FC3248124 160 240 124 183 2.1 2.1
FC3450170 170 250 170 192 2.1 2.1
FC3452120 170 260 120 195 2.1 2.1
FC3652168 180 260 168 202 2.1 2.1
FC3656180 180 280 180 207 2.1 2.1
FC3852168 190 260 168 208 2.1 2.1
FC3854200 190 270 200 212 2.1 2.1
FC3856200 190 280 200 214 2.1 2.1
FC4056200 200 280 200 222 2.1 2.1
FC4058192 200 290 192 226 2.1 2.1
FC4064216 200 320 216 233 2.1 2.1
FC4260210 210 300 210 234 2.1 2.1
FC4462192 220 310 192 246 2.1 2.1
FC4464210 220 320 210 248 2.1 2.1
FC4666206 230 330 206 260 2.1 2.1
FC4668260 230 340 260 261 2.1 2.1
FC4866220 240 330 220 264 2.1 2.1
FC4872220 240 360 220 272 2.1 2.1
FC5070220 250 350 220 278 3 3
FC5274220 260 370 220 292 3 3
FC5276280 260 380 280 294 3 3
FC5476230 270 380 230 298 3 3
FC5678220 280 390 220 312 3 3
FC5684280 280 420 280 318 4 4
FC5882240 290 410 240 320 4 4
FC5884300 290 420 300 327 4 4
FC6084218 300 420 218 332 4 4
FC6084240 300 420 240 332 4 4
FC6490240 320 450 240 355 4 4
FC6496290 320 480 290 364 4 4
FC6692340 330 460 340 365 4 4
FC6892260 340 460 260 370 4 4



Tractor cylindrical roller Bearing FC3856200



Product Name High Quality Long Life Cylindrical roller Bearing FC3856200
Precision Rating ABEC1,ABEC3,ABEC5
Clearance C0,C2,C3,C4,C5 is available
Sealed Cap Rubber or Metal
Paypal Acceptable
OEM Accept
Vibration Level code V1,V2.V3
Material Gcr15
Seals Type ZZ/ZRS.RZ/RS. Open
Regular export packing Plastic drum+White box+ carton
  industrial packaging or as your requiremen.
MOQ 1 pcs
Delivery Time 3-7 days after receiving your payment
Payment Terms L/C,T/T,Western Union,MoneyGram,Paypal
Port of shippment by sea Shanghai,guangzhou,qingdao
Place of Origin Wuxi, China
Samples Available



Trading information :



Price terms EXW FOB CNF CFR, CIF
Payment terms L/C ,T/T ,Western Union, Paypal
Express way DHL FEDEX TNT UPS
Shipping port shanghai ,qingdao ,nongbo, guangzhou
Packing

1.Industrial packaging: plastic bag + kraft paper + carton + plywood pallets;

plastic tube + carton + plywood pallets;

2. Commercial packing: 1pc/plastic bag + color box + carton + plywood pallets





FC3856200 Cylindrical Roller Bearings four Row 190mm Bore 280mm OD 200mm Width 0

FC3856200 Cylindrical Roller Bearings four Row 190mm Bore 280mm OD 200mm Width 1
