Brass cage double row angular contact ball bearings Chrome steel
1. Angular Contact Bearing Specification :
Bearing type | Angular Contact Bearing |
Bearing Model | 3202A |
Brand | SKF/ FAG / GQZ / AAA |
Size (mm) | 15*35*15.9 |
Weight (kg) | 0.072 KG |
Stock | Enough |
Lubrication | Oil |
Application | Automobiles, Rolling Mill, Mining, Metallurgy |
2. Angular contact ball bearings features :
Angular contact ball bearings: 7000C-type (α = 15 °), 7000AC-type (α = 25 °) and 7000B (α = 40 °) of several types. The kinds of bearings in the outer ring lock port, the general separation of inside and outside the ring can not be combined radial and axial load and axial load in one direction. Axial load capacity of the decision by the contact angle, contact angle is greater, the ability to withstand high axial loads. This kind of bearing shaft or housing to limit axial displacement in one direction.
3. The type of angular contact ball bearing
Single Row Angular contact ball bearing: 7100series, 7200series, 7300series, 7400series
Double Row Angular contact ball bearing: 52series, 53series,3200series,3300series
Combined angular contact ball bearing
Four point contact ball bearing
4 . Competitive Advantage:
1. Ring 's Material: Bearing Steel ZGCr15/GCr15
2. Balls' Material: Carbon chromium steel/Si3N4
3. Cage Material: Phenolic,Nylon,Plastic,Brass etc.
4. Angle: C -15°contact angle, AC-25°contact angle, B-40°contact angle
5. Tolerance Class: ABEC7,ABEC9 (P4,P2)
6. Preload: A-Light Preload , B-Medium Preload, C-Heavy Preload
7. OEM service
5 . Specifications:
1. High Speed
2. High Precision
3. Long Life
4. Higher Radial and Axial Loads
6 . We also can offer following bearings :
Bearing No. | Dimensions(mm) | ( KN) | Weight | |||||
New Model | ZZ | 2RS | d | D | B | Cr | Cor | Mass(kg) |
3200A | 3200zz | 32002RS | 10 | 30 | 14.3 | 7 | 3.8 | 0.049 |
3201A | 3201zz | 32012RS | 12 | 32 | 15 9 | 9 2 | 5 1 | 0.057 |
3202A | 3202zz | 32022RS | 15 | 35 | 15.9 | 10 | 6.1 | 0.064 |
3203A | 3203zz | 32032RS | 17 | 40 | 17.5 | 12 8 | 7 9 | 0 096 |
3204A | 3204zz | 32042RS | 20 | 47 | 20.6 | 19 | 12.1 | 0.153 |
3205A | 3205zz | 32052RS | 25 | 52 | 20.6 | 20.6 | 14 3 | 0 175 |
3206A | 3206zz | 32062RS | 30 | 62 | 23.8 | 28.6 | 20.4 | 0.286 |
3207A | 3207zz | 32072RS | 35 | 72 | 27 | 38 | 27.8 | 0.436 |
3208A | 3208zz | 32082RS | 40 | 80 | 30.2 | 42.5 | 32.5 | 0.59 |
3209A | 3209zz | 32092RS | 45 | 85 | 30.2 | 48 0 | 37 | 0.64 |
3210A | 3210u | 32102RS | 50 | 90 | 30.2 | 51 | 42.O | 0.689 |
3211A | 3211zz | 32112RS | 55 | 100 | 33.3 | 63 0 | 53 | 0 986 |
3212A | 3212zz | 32122RS | 60 | 110 | 36.5 | 71.5 | 58.5 | 1.27 |
3213A | 3213zz | 32132RS | 65 | 120 | 38 1 | 83.5 | 72.5 | 1.57 |
3214A | 3214zz | 32142RS | 70 | 125 | 39.7 | 87.5 | 79.5 | 1.8 |
3215A | 3215zz | 32152RS | 75 | 130 | 41.3 | 90 | 80.5 | 1 900 |
3216A | 3216zz | 32162RS | 80 | 140 | 44.4 | 106 | 95.5 | 2.39 |
3217A | 3217zz | 32172RS | 85 | 150 | 49.2 | 112 | 106 | 3.06 |
3218A | 3218zz | 32182RS | 90 | 160 | 52.4 | 140 | 129 | 3.73 |
3219A | 3219zz | 32192RS | 95 | 170 | 55 6 | 163 | 184 | 5 100 |
3220A | 3220zz | 32202RS | 100 | 180 | 60.3 | 210 | 240 | 6.14 |
3300A | 3300zz | 33002RS | 10 | 35 | 19 | 9.2 | 5.1 | 0.092 |
3301A | 3301zz | 33012RS | 12 | 37 | 19 | 10 | 6.1 | 0.109 |
3302A | 3302zz | 33022RS | 15 | 42 | 19 | 12 8 | 7.9 | 0.132 |
3303A | 3303zz | 33032RS | 17 | 47 | 22.2 | 20.4 | 12.1 | 0.181 |
3304A | 3304zz | 33042RS | 20 | 52 | 22 2 | 20.6 | 127 | 227 |
3305A | 3305zz | 33052RS | 25 | 62 | 25.4 | 30.5 | 20.5 | 0.362 |
3306A | 3306zz | 33062RS | 30 | 72 | 302 | 39.5 | 27.5 | 0 553 |
3307A | 3307zz | 33072RS | 35 | 80 | 34.9 | 49.5 | 35.O | 0.766 |
3308A | 3308zz | 33082RS | 40 | 90 | 36.5 | 60 5 | 44 | 1.01 |
3309A | 3309zz | 33092RS | 45 | 100 | 39.7 | 72.5 | 54 | 1.34 |
3310A | 3310zz | 33102RS | 50 | 110 | 44.4 | 85.5 | 64.5 | 1.81 |
3311A | 3311zz | 33112RS | 55 | 120 | 49.2 | 106 | 82 | 2.32 |
3312A | 3312zz | 33122RS | 60 | 130 | 54 | 122 | 95.5 | 3.05 |
3313A | 3313zz | 33132RS | 65 | 140 | 58.7 | 138 | 109 | 3,960 |
3314A | 3314zz | 33142RS | 70 | 150 | 63.5 | 155 | 125 | 4.74 |
3315A | 3315zz | 33152RS | 75 | 160 | 68.3 | 168 | 141 | 5.65 |
3316A | 3316zz | 33162RS | 80 | 170 | 68.3 | 175 | 151 | 7.21 |
3317A | 3317zz | 33172RS | 85 | 180 | 73 | 196 | 240 | 8.3 |
3318A | 3318zz | 33182RS | 90 | 190 | 73 | 225 | 266 | 9 01 |
