1. Cylindrical Roller Bearing Specification :
Bearing type | Cylindrical Roller Bearing |
Bearing Model | NJ207E.M1 |
Brand | FAG / NSK / GQZ / AAA |
Size (mm) | 35*72*17 |
Weight (kg) | 0.34 KG |
Stock | Enough |
Lubrication | Oil |
Application | Automobiles, Rolling Mill, Mining, Metallurgy |
2. Cylindrical Roller Bearing :
We can supply many kinds of cylindrical roller bearings.
Single row: N, NU, NJ, NF, NUP, NCF and NJG
Double row: NNU, NN, NNC, NNCF and NNCL.
Four rows:SL series
3 . Cylindrical Roller Bearing Features :
1) Prompt delivery
2) Chrome steel and Carbon steel
3) Hardness: HRC60-HRC65
4) Single packing with plastic paper and carton
4 . Competitive Advantage:
1. Bearing manufacturer
2. ISO 9000/9001/9004/19011: 2000
3. Produce by customer's needs
4. High speed, low noise
5. Bearing steel
6. The most competitive price
5. APPLICATION:
Bearing can be used for: Annealing furnace, special machine, conveyor, mixer, rock drill, corrosion-resistant pumps, welding machines, monitoring equipment, ceramic building materials processing equipment, packaging auxiliary equipment, sewing machine parts, machine tool rest, forestry machinery, reaction equipment, hot-pressing machine, screw refrigerating machine, printing machines, cars, and so on.
6 . We also can offer following bearings :
Designations | Principal Dimensions (mm) | Basic load rating (kN) | Speed ratings (rpm) | Weight(kg) | ||||
d | D | B | Dynamic | Staitc | Grease | Oil | ||
NNU4920 | 100 | 140 | 40 | 125 | 244 | 4300 | 5100 | 1.88 |
NN3020 | 100 | 150 | 37 | 146 | 245 | 4000 | 4800 | 1.96 |
NNU4921 | 105 | 145 | 40 | 132 | 270 | 4100 | 4800 | 1.96 |
NN3021 | 105 | 160 | 41 | 192 | 310 | 3800 | 4100 | 2.96 |
NNU4922 | 110 | 150 | 40 | 132 | 258 | 3900 | 4600 | 2.04 |
NN3022 | 110 | 170 | 45 | 226 | 365 | 3600 | 4300 | 3.76 |
NNU4924 | 120 | 165 | 45 | 170 | 328 | 3600 | 4200 | 2.76 |
NNU4124 | 120 | 200 | 80 | -- | -- | -- | -- | 11 |
NN3024 | 120 | 180 | 46 | 232 | 390 | 3300 | 3900 | 4.1 |
NNU4926 | 130 | 180 | 50 | 187 | 368 | 3300 | 3900 | 3.79 |
NN3026 | 130 | 200 | 52 | 284 | 475 | 3100 | 3600 | 6.04 |
NNU4928 | 140 | 190 | 50 | 188 | 394 | 3000 | 3600 | 4.11 |
NN3026 | 140 | 210 | 53 | 297 | 515 | 2800 | 3300 | 6.48 |
NNU4930 | 150 | 210 | 60 | 325 | 655 | 2800 | 3300 | 6.2 |
NN3030 | 150 | 225 | 56 | 330 | 570 | 2600 | 3100 | 7.88 |
NNU4932 | 160 | 220 | 60 | 330 | 653 | 2500 | 2900 | 6.53 |
NN3032 | 160 | 240 | 60 | 369 | 635 | 2600 | 3100 | 9.57 |
NNU4934 | 170 | 230 | 60 | 336 | 672 | 2500 | 2900 | 6.85 |
NN3034 | 170 | 260 | 67 | 440 | 775 | 2300 | 2700 | 13 |
NNU4936 | 180 | 250 | 69 | 380 | 830 | 2300 | 2700 | 10.2 |
NN3036 | 180 | 280 | 74 | 561 | 994 | 2200 | 2600 | 17 |
NNU4938 | 190 | 260 | 69 | 402 | 856 | 2200 | 2600 | 10.6 |
NN3038 | 190 | 290 | 75 | 580 | 1040 | 2000 | 2400 | 18 |
NNU4940 | 200 | 280 | 80 | 484 | 1010 | 2100 | 2400 | 14.9 |
NN3040 | 200 | 310 | 82 | 644 | 1140 | 1900 | 2300 | 23 |
NNU4944 | 220 | 300 | 80 | 510 | 1140 | 1900 | 2200 | 16.2 |
NN3044 | 220 | 340 | 90 | 800 | 1460 | 1700 | 2100 | 32.9 |
NNU4948 | 240 | 320 | 80 | 528 | 1160 | 1700 | 2000 | 17.4 |
NNU4148 | 240 | 400 | 160 | -- | -- | -- | -- | 85 |
NN3048 | 240 | 360 | 92 | 835 | 1688 | 1600 | 1900 | -- |
NNU4176 | 240 | 620 | 243 | -- | -- | -- | -- | 285 |
NNU4952 | 260 | 360 | 100 | 745 | 1800 | 1600 | 1800 | 30.2 |
NN3052 | 260 | 440 | 104 | -- | -- | -- | -- | 110 |
NN3052 | 260 | 400 | 104 | 1020 | 1910 | 1500 | 1700 | 48 |
NNU4956 | 280 | 380 | 100 | 764 | 1710 | 1400 | 170 | 32.2 |
