Automobiles / Rolling Mill Angular Contact Ball Bearing 7214ACM   / Z1V1, Z2V2 , Z3V3

Automobiles / Rolling Mill Angular Contact Ball Bearing 7214ACM / Z1V1, Z2V2 , Z3V3

  • High Light

    Metric Ball Bearings

    ,

    Angular Contact Bearing

  • Bearing Type
    Angular Contact Bearing
  • Clearance
    C0,C2,C3,C4,C5
  • Material
    Bearing Steel
  • D
    100
  • D
    55
  • Vibration Level
    V1, V2, V3
  • Brand Name
    SKF/ FAG / GQZ / AAA
  • Certification
    ISO 9001
  • Model Number
    7214ACM
  • Minimum Order Quantity
    1
  • Price
    1 USD
  • Packaging Details
    single packing + standard export packing
  • Payment Terms
    T/T, Western Union
  • Supply Ability
    1000 pcs / month

Automobiles / Rolling Mill Angular Contact Ball Bearing 7214ACM / Z1V1, Z2V2 , Z3V3



1. Angular  Contact  Bearing  Specification :



Bearing type  Angular Contact Bearing
Bearing Model  7214ACM
Brand SKF/ FAG / GQZ / AAA
Size (mm) 70*125*24
Weight (kg)  1.12 KG
Stock  Enough
Lubrication Oil
Application Automobiles, Rolling Mill, Mining, Metallurgy



2. Angular contact ball bearings ​:


According to angular contact ball bearings manufacturers, single-row, and double-row angular contact ball bearings are both popular ones in the market. A single row angular contact ball bearings is suitable for carrying axial-load acting in one direction only; as a result, they are usually used in pairs or multi-arrangement in many applications. A double row angular contact ball bearing, however, is suitable for both an axial-load and a radial-load in both directions.



3 . Advantages:



 High temperature, cold ,wear out failure, corrosion resistance, anti magnetic insulation , oil-free self-lubricating,high speed ,long life,high precisions and others;



4 . Angular contact ball bearings features :


1) Quality level: reach the same level as the Japanese and European bearings
2) Less coefficient of friction
3) High limiting speed
4) Large size range
5) variations of structure



5. APPLICATION:

Automobile, tractor, machine tool, electrical machine,
water pump, agriculture machine, textile machine, etc.


6 .  We also can offer following Angular contact ball bearings  :



Dimension Bearing No.
d (mm) D (mm) B (mm)
10 19 5 71800C
10 22 6 71900C
10 26 8 7000C
10 30 9 7200C
10 30 14.287 5200
12 21 5 71801C
12 24 6 71901C
12 28 8 7001C
12 32 10 7201C
12 32 15.875 5201
15 24 5 71802C
15 28 7 71902C
15 32 9 7002C
15 35 11 7202C
15 35 15.875 5202
17 26 5 71803C
17 30 7 71903C
17 35 10 7003C
17 40 12 7203C
17 40 17.462 5203
20 32 7 71804C
20 37 9 71904C
20 42 12 7004C
20 47 14 7204C
20 47 20.638 5204
20 52 22.225 5304
25 37 7 71805C
25 42 9 71905C
25 47 12 7005C
25 52 15 7205C
25 52 20.638 5205
25 62 25.4 5305
30 42 7 71806C
30 47 9 71906C
30 55 13 7006C
30 62 16 7206C
30 62 23.812 5206
30 72 30.16 5306
35 47 7 71807C
35 55 10 71907C
35 62 14 7007C
35 72 17 7207C
35 72 26.99 5207
35 80 34.93 5307
40 52 7 71808C
40 62 12 71908C
40 68 15 7008C
40 80 18 7208C
40 80 30.163 5208
40 90 36.513 5308
45 58 7 71809C
45 68 12 71909C
45 75 16 7009C
45 85 30.163 5209
45 85 19 7209C
50 110 44.45 5310
50 65 7 71810C
50 72 12 71910C
50 80 16 7010C
50 90 20 7210C
50 90 30.163 5210
55 100 33.338 5211
55 100 21 7211C
55 120 49.213 5311
55 72 9 71811C
55 80 13 71911C
55 90 18 7011C
60 110 22 7212C
60 110 36.513 5212
60 130 53.975 5312
60 78 10 71812C
60 85 13 71912C
60 95 18 7012C
65 100 18 7013C
65 120 23 7213C
65 120 38.1 5213
65 140 58.738 5313
65 85 10 71813C
65 90 13 71913C
