81176M Bearing 380x460x65 mm Cylindrical roller thrust bearings 81176M high quality thrust Cylindrical roller bearing
Thrust Roller Bearing:
Thrust roller bearings are separable bearings, can only withstand axial load and a slight impact, to limit the shaft (or shell) of the axial displacement in one direction, it can be used as single-axis to the position. But its carrying capacity is far greater than the thrust ball bearings.
Thrust roller bearings are mainly used for heavy-duty machine tools, power marine gear boxes, oil rig, electrical and other machinery in the vertical.
Specifications:
1.high precision ball bearing
2.ISO standard bearing
3.High quality & competitive price
4.Many famous brand is available
5.Low noise &long life
6. Chrome Steel ,stainless steel
The Application of Thrust Roller Bearing
Thrust roller bearing is mainly used in heavy duty machine tools,high-power marine gearbox,petroleum drilling machine vertical machine and other machinery
| Product | 81176 M Bearing 380x460x65 mm Cylindrical roller thrust bearings 81176M |
| Precision Rating | ABEC1,ABEC3,ABEC5 |
| Clearance | C0,C2,C3,C4,C5 is available |
| Sealed Cap | Open |
| Paypal | Acceptable |
| OEM | Accept |
| Vibration Level code | V1,V2.V3 |
| Material | Gcr15 |
| Seals Type | ZZ/ZRS.RZ/RS. Open |
| Number of row | single row |
| Bore Size(d) | 380 MM |
| Outside Diameter | 460MM |
| Thickness | 65 MM |
| Regular export packing | Plastic drum+White box+ carton |
| industrial packaging or as your requiremen. | |
| MOQ | 1 pcs |
| Delivery Time | 3-7 days after receiving your payment |
| Payment Terms | L/C,T/T,Western Union,MoneyGram,Paypal |
| Port of shippment by sea | Shanghai,guangzhou,qingdao |
| Place of Origin | Wuxi, China |
| Samples | Available |
Product show:
| designation | Dimensions | |||
| Complete bearing | roller and cage thrust assembly | d (mm) | D (mm) | H (mm) |
| 81244 M | K 81244 M | 220 | 300 | 63 |
| 89444 M | K 89444 M | 220 | 420 | 122 |
| 81148 M | K 81148 M | 240 | 300 | 45 |
| 81248 M | K 81248 M | 240 | 340 | 78 |
| 89448 M | - | 240 | 440 | 122 |
| 81152 M | K 81152 M | 260 | 320 | 45 |
| 81252 M | K 81252 M | 260 | 360 | 79 |
| 89452 M | - | 260 | 480 | 132 |
| 81156 M | K 81156 M | 280 | 350 | 53 |
| 81256 M | K 81256 M | 280 | 380 | 80 |
| 89456 M | - | 280 | 520 | 145 |
| 81160 M | K 81160 M | 300 | 380 | 62 |
| 81260 M | K 81260 M | 300 | 420 | 95 |
| 89460 M | - | 300 | 540 | 145 |
| 81164 M | K 81164 M | 320 | 400 | 63 |
| 81264 M | - | 320 | 440 | 95 |
| BGSB 358345 | - | 330 | 495 | 89 |
| 81168 M | K 81168 M | 340 | 420 | 64 |
| 81268 M | - | 340 | 460 | 96 |
| 89172 M | - | 360 | 440 | 48 |
| 81172 M | - | 360 | 440 | 65 |
| 81272 M | - | 360 | 500 | 110 |
| 89176 M | - | 380 | 460 | 48 |
| 81176 M | - | 380 | 460 | 65 |
| 81276 M | - | 380 | 520 | 112 |
| 89180 M | - | 400 | 480 | 48 |
| 81180 M | - | 400 | 480 | 65 |
| 81280 M | - | 400 | 540 | 112 |
| 89184 M | - | 420 | 500 | 48 |
| 81184 M | - | 420 | 500 | 65 |
