AS8112WE Elastic Spiral Roller Bearing / AS8112WB High Temperature Roller Bearing

AS8112WE and AS8112WB belong to 8112 single direction axial cylindrical roller thrust bearings, unified boundary dimensions d=60mm, D=95mm, T=26mm. The two models differ only in retainer material and structure.

AS series thrust roller bearing consists of shaft washer, housing washer and dense cylindrical roller assemblies. Short cylindrical rollers form line contact with raceway surface, delivering extremely high static and dynamic axial load capacity, ideal for equipment bearing large one-way axial thrust load. The inner shaft washer fits the rotating shaft, outer housing washer matches stationary housing seat, allowing pure axial load transmission with limited radial positioning function.

All washers and cylindrical rollers adopt fully quenched GCr15 bearing steel with ultra-precision mirror grinding raceway, low friction loss and stable anti-fatigue performance. Widely used for vertical lathe spindle, heavy press ram, vertical hydraulic cylinder, mining heavy lifting vertical shaft and heavy-duty reduction equipment.

Model: AS8112WE, AS8112WB
Boundary dimensions(mm): Inner bore d=60, Outer diameter D=95, Thickness T=26
Min fillet radius r: 1.0mm
Structure: Single direction axial cylindrical roller thrust bearing, separable three-piece structure
Raw material: GCr15 high carbon chromium bearing steel for shaft washer, housing washer and rollers
Core cage distinction:

• AS8112WE: Solid machined brass cage, high temperature resistant, anti-deformation under long continuous heavy load
• AS8112WB: Stamped steel cage, lightweight, cost-efficient for general heavy axial load working conditions

Basic dynamic axial load Ca: 148kN
Basic static axial load C0a: 432kN
Limiting rotating speed: Grease 1600 r/min, Oil 2200 r/min
Single set net weight: 0.53kg
Standard clearance: Normal CN clearance, customized special clearance available
Operating temperature range: -30℃ ~ 120℃
Mounting shoulder reference: da max=68mm, Da min=87mm
Complete vertical shaft installation drawings, load matching guide and long-cycle axial thrust durability test reports can be provided on customer request.

1. Separable three-piece split structure, shaft washer, roller cage assembly and housing washer can be installed separately, greatly simplify vertical shaft disassembly and maintenance work.
2. Two cage versions for differentiated working condition matching: brass WE cage adapts high-temperature, continuous heavy axial thrust; steel WB cage controls cost for standard general machinery.
3. Dense short cylindrical roller line contact layout, ultra-high axial bearing capacity, excellent resistance to instantaneous impact thrust generated by presses and vertical machine tools.
4. Ultra-smooth superfinished raceway surface, low friction coefficient, effectively restrain temperature rise under long-time continuous axial load rotation, avoid seizure failure.
5. Full integral quenching heat treatment reaches HRC60–65 high hardness, outstanding wear and fatigue resistance, extend overhaul cycle of heavy vertical equipment.
6. Pure one-way axial load design, stable load distribution on all rollers, effectively disperse vertical gravity and pressing thrust of machine tool spindles.
7. Standard metric universal mounting dimension, fully interchangeable with global standard 8112 thrust roller bearings, no modification to existing shaft and housing.
8. Complete customized service: P4/P5 high precision upgrade, OEM laser marking on washer surface, neutral export carton anti-rust packaging, high temperature resistant special grease pre-filling.

AS8112WE / AS8112WB single direction thrust cylindrical roller bearings are core heavy axial load spare parts for vertical industrial machinery:

• Vertical lathe, vertical machining center main spindle axial support bearing assemblies
• Hydraulic punching press, forging machine ram one-way thrust matching units
• Heavy hydraulic cylinder, metallurgical extrusion equipment vertical load bearing positions
• Mine lifting vertical transmission shaft, large crane vertical rotating support components
• Heavy-duty gear reducer, wind power small vertical shaft thrust bearing parts

Aftermarket interchangeable 8112 series axial thrust roller bearing
Cost-effective high axial load vertical equipment bearing solution for machine tool manufacturers, hydraulic press OEM and heavy machinery maintenance factories bulk procurement.

25 years professional manufacturing experience of AS8110 series axial cylindrical roller thrust bearings including AS8112WE and AS8112WB
AS8112WE & AS8112WB fully dimensionally interchangeable with international standard thrust bearings, consistent axial load rating, speed tolerance and assembly tolerance standards.
Complete OEM & ODM customization service supporting P4 high precision grade and special high temperature grease filling.
Strict full pre-delivery inspection flow: GCr15 raw material hardness test, roller dimensional sorting screening, long-cycle constant axial thrust aging test, repeated impact fatigue wear test.
Professional thrust roller bearing engineering team provides one-on-one axial load calculation, cage type selection and vertical shaft installation technical guidance within 24 working hours.
Stable mass production workshop with competitive factory bulk wholesale price for mixed orders of brass cage WE and steel cage WB models, long-term cooperation with global vertical machine tool and hydraulic equipment spare parts buyers.
We specialize in separable three-piece thrust roller structure, dual brass/steel cage options, heavy axial load resistance design and long-term win-win cooperation with heavy industrial equipment suppliers.

Raw material chemical composition and hardness inspection for GCr15 bearing steel shaft washer, housing washer and roller blanks
Precision forging, quenching & tempering, ultra-mirror finish raceway grinding processing for thrust washers
Short cylindrical roller high-temperature quenching, superfinishing and automatic dimensional sorting production line
Independent cage production lines: brass cage precision machining / steel cage stamping forming, strictly control roller assembly clearance
Targeted classified performance testing: AS8112 long-cycle constant axial thrust aging test, repeated vertical impact fatigue test, high-temperature thermal deformation wear detection
Full dimensional tolerance and surface defect recheck before anti-rust oil coating and export carton packaging shipment
Every production batch of AS8112WE and AS8112WB bearings undergoes full sampling axial thrust simulation rotation test to guarantee stable long-term heavy one-way axial load support performance in vertical machine tools and hydraulic press equipment.

If you need AS8112WE brass cage and AS8112WB steel cage single direction thrust roller bearings for vertical lathe spindle, hydraulic forging press and vertical transmission equipment OEM bulk matching and maintenance, send your purchase inquiry directly.
You will receive full professional supporting services after submitting inquiry:

• Fast official factory formal quotation reply within 24 hours
• One-on-one axial load calculation, cage model selection and vertical shaft housing installation technical guidance from professional thrust bearing engineers
• Customized bearing performance solutions including P4 high precision upgrade and high-temperature resistant grease options
• Competitive direct factory bulk wholesale price for mixed WE and WB cage orders

Provide your required purchase quantity, equipment maximum axial thrust and continuous operating temperature environment to obtain detailed sealed formal quotation document.

Q1: What is the difference between AS8112WE and AS8112WB?
A1: The difference is retainer material. AS8112WE adopts solid machined brass cage, suitable for high temperature and long-time continuous heavy axial load; AS8112WB uses stamped steel cage, cost-saving for general medium-load vertical machinery.
Q2: What load can AS8112 thrust roller bearing bear?
A2: It is single direction thrust bearing, mainly bear large one-way axial load, can only bear tiny incidental radial force, not suitable for equipment with big radial load.
Q3: What is the advantage of three-piece separable structure?
A3: Shaft washer, roller assembly and housing washer can be separated freely, convenient to assemble the shaft and bearing seat respectively, greatly reduce maintenance difficulty of vertical spindle equipment.
