RB11012UU C0 Clearance RB 11012 Crossed Cylindrical Roller Bearing 110x135x12 Mm

1 pcs
MOQ
negotiation
Price
RB11012UU C0 Clearance RB 11012 Crossed Cylindrical Roller Bearing 110x135x12 Mm
Features Gallery Product Description Request A Quote
Features
Specifications
Structure: Cylindrical
Type: Roller
Application: Vibration Machinary,CNC Machine And So On
HS CODE: 84825000
High Light:

axial thrust bearing

,

roller thrust bearing

Basic Infomation
Place of Origin: Japan
Brand Name: OEM
Certification: ISO9001:2008
Model Number: RB11012UU
Payment & Shipping Terms
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 3 working days after received your payment
Payment Terms: T/T or western Union or PayPal
Supply Ability: 3,000pcs per month
Product Description

Slew machine Cross roller bearing RB11012UU C0 clearance RB 11012 Bearing 110x135x12 mm cross roller bearing RB11012



Product Description

Crossed roller bearing is based on cylindrical roller being arranged vertically to each other in a 900 V groove rolling surface through the isolation piece, so cross roller bearing can withstand load from multi-direction, like: Radial, axial and torque. Since the cross roller ring achieves high rigidity and the precision can reach up to P2, P4, despite the mininum possible dimensions of the inner and outer rings, it is optimal for applications such as industrial robot, rotation of the machining center, precision rotary worktable, medical machine, calculator, military industry, IC manufacturing devices and other equipments.



Slew machine Cross roller bearing RB11012UU C0 clearance Features



1.Bearing RB11012 manufacturer ------ Favorable prices

2.Own factory ------ Dicountable on large quantity

3.High quality ------ ISO9001:2008 proved

4.OEM service ------ Design to your own demands

5.Good after-sale service ------ Help you to track your goods

6.Sample available ------ Make sure the quality

7.Good location in shanghai ------ Convenient transportation





Our range of products:
• Angular Contact Ball Bearing
• Ball Bearing
• Cylindrical Roller Bearing
• Deep Groove Ball Bearing
• Double Row Ball Bearing
• Extra Large Size Ball Bearing
• Linear Bushing
• Miniature Ball Bearing
• Needle Roller Bearing
• Pillow Block
• Precision Ball Bearing
• Radial Ball Bearing
• Roller Bearing
• Self-Aligned Ball Bearing
• Single Row Ball Bearing
• Spherical Roller Bearing
• Super Precision Ball Bearing
• Tapered Roller Bearing
• Thrust Ball Bearing
• Thrust Roller Bearing
• Wider Inner Ring Ball Bearing
• Etc.



Slew machine Cross roller bearing RB11012UU C0 clearance design draft :

RB11012UU C0 Clearance RB 11012 Crossed Cylindrical Roller Bearing 110x135x12 Mm 0





Slew machine Cross roller bearing RB11012UU C0 clearance models series :

Model d/mm D/mm dp/mm B/mm Weight/kg
RB10020 100 150 123 20 1.45
RB11012 110 135 121.8 12 0.4
RB11015 110 145 126.5 15 0.75
RB11020 110 160 133 20 1.56
RB12016 120 150 134.2 16 0.72
RB12025 120 180 148.7 25 2.62
RB13015 130 160 144.5 15 0.72
RB13025 130 190 158 25 2.82
RB14016 140 175 154.8 16 1
RB14025 140 200 168 25 2.96
RB15013 150 180 164 13 0.68
RB15025 150 210 178 25 3.16
RB15030 150 230 188 30 5.3
RB16025 160 220 188.6 25 3.14
RB17020 170 220 191 20 2.11
RB18025 180 240 210 25 3.44
RB19025 190 240 211.9 25 2.99
RB20025 200 260 230 25 4
RB20030 200 280 240 30 6.7
RB20035 200 295 247.7 35 9.6
RB22025 220 280 250.1 25 4.1
RB24025 24 300 269 25 4.5
RB25025 250 310 277.5 25 5
RB25030 250 330 287.5 30 8.1
RB25040 250 355 300.7 40 14.8
RB30025 300 360 328 25 5.9
RB30035 300 395 345 35 13.4
RB30040 300 405 351.6 40 17.2
RB35020 350 400 373.4 20 3.9
RB40035 400 480 440.3 35 14.5
RB40040 400 510 453.4 40 23.5



Pictures of cylindrical roller bearings



RB11012UU C0 Clearance RB 11012 Crossed Cylindrical Roller Bearing 110x135x12 Mm 1

RB11012UU C0 Clearance RB 11012 Crossed Cylindrical Roller Bearing 110x135x12 Mm 2

RB11012UU C0 Clearance RB 11012 Crossed Cylindrical Roller Bearing 110x135x12 Mm 3
