140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device
  • name
  • name
  • name

140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device

MOQ: 1 pcs
Price: negotiation
Standard Packaging: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Period: 3 working days after received your payment
Payment Method: T/T or western Union or PayPal
Supply Capacity: 3,000pcs per month
Details Information
Product Description
Detail Information
Place of Origin
Sweden
Brand Name
SKF
Certification
ISO9001:2008
Model Number
H3032
Product Name:
H3032
Shaft Diameter:
140 Mm
OD:
160 Mm
Width:
93 Mm
Material:
Gcr15
Type:
Metric Series Adapter Sleeve
Lubrication:
Oil Or Grease
Lead Time:
Within 3 Days
Highlight:

axial thrust bearing

,

roller thrust bearing

Product Description

140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device



1. Specification:

Bearing No. H3032
Type Adapter sleeve
ID 140 mm
OD 160 mm
Height 93 mm



2. Feature:

(1) Single row

(2) With locking nut

(3) chrome steel material

(4) Sweden origin

(5) Competitive price

(6) Fast delivery



3. Bearing Picture:

140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device 0

140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device 1

140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device 2



4. We also supply following adapter sleeves:

Dimensions Abutment dimensions   Designations
d1(mm) D(mm) B(mm) da Max db Min Ba Min Mass(kg) Designations Adapter sleeve
17 47 14 28,5 23 5 0,16 1204 EKTN9 H 204
20 52 15 33 28 5 0,21 1205 EKTN9 H 205
20 52 18 31 28 5 0,23 2205 E-2RS1KTN9 H 305E
20 52 18 32 28 5 0,23 2205 EKTN9 H 305
20 62 24 35,5 29 5 0,42 2305 EKTN9 H 2305
25 62 16 40 33 5 0,32 1206 EKTN93) H 206
25 62 20 36,5 33 5 0,36 2206 E-2RS1KTN9 H 306E
25 62 20 38 33 5 0,36 2206 EKTN9 H 306
25 72 27 40 35 5 0,62 2306 E-2RS1KTN9 H 2306
30 72 17 47 38 5 0,44 1207 EKTN93) H 207
30 72 23 42,5 39 5 0,55 2207 E-2RS1KTN9 H 307E
30 72 23 45 39 5 0,54 2207 EKTN9 H 307
30 80 31 43,5 40 5 0,86 2307 E-2RS1KTN9 H 2307E
30 80 31 46 40 5 0,84 2307 EKTN9 H 2307
35 80 18 53 43 6 0,58 1208 EKTN93) H 208
35 80 23 49 44 6 0,67 2208 E-2RS1KTN9 H 308E
35 90 23 61 44 6 0,85 1308 EKTN9 H 308
35 90 33 55 45 6 1,2 2308 E-2RS1KTN9 H 2308
40 85 19 57 48 6 0,68 1209 EKTN93) H 209
40 85 23 53 50 8 0,76 2209 E-2RS1KTN9 H 309E
40 85 23 55 50 8 0,78 2209 EKTN9 H 309
40 100 36 60 50 6 1,4 2309 EKTN9 H 2309
45 90 20 62 53 6 0,77 1210 EKTN93) H 210
45 90 23 58 55 10 0,84 2210 E-2RS1KTN9 H 310E
45 110 27 70 55 6 1,45 1310 EKTN9 H 310
45 110 40 65 56 6 1,9 2310K H 2310
50 100 21 70 60 7 0,99 1211 EKTN93) H 211
50 100 25 65,5 60 11 1,1 2211 E-2RS1KTN9 H 311E
50 100 25 67 60 11 1,15 2211 EKTN9 H 311
50 120 43 72 61 7 2,4 2311K H 2311



If you want to buy this bearing,just send email directly to tommy@gqbearing.com
